Cordless Comparison
Scope
Instruction Manual
T-1922C
T-1924C

Advertisement

Table of Contents
loading

Related Manuals for Ken A Vision T-1922C

Summary of Contents for Ken A Vision T-1922C

  • Page 1 Cordless Comparison Scope Instruction Manual T-1922C T-1924C...

  • Page 2: Packing List

    Both are shipped as cordless units, with an enclosed charger/power cord adapter. The T-1922C has 4x, 10x, and 40xR DIN objectives, with an Abbé condenser, iris diaphragm and mechanical stage. comparison has an independent light rheostat for light control.
  • Page 3 Light Rheostat to adjust lighting Contour Base Specifications subject to change without notice 1. Seidentopf Binocular Head 3. Bridge Assembly 5. Fine & Coarse Focusing 7. Microscope L 2. Eyepiece Tubes 4. Bridge Assembly Head Socket 6. Stage 8. Microsocpe R T-1922C T-1924C...
  • Page 4 Tighten the set screw. Step 6. Insert eyepieces into the eyetubes. Step 7. Plug both microscopes into wall socket and allow them to charge overnight. Your Cordless Comparison Scope is now ready to use. Microscope Use and Instructions Visit the Ken-A-Vision Web site, http://www.ken-a-vision.com/pdf/...

  • Page 5: Operation

    Built-in Illuminator(s) T-1922C - There is an in-base illuminator built into each base of the microscope. Each has an independent rheostat control, which will adjust the light intensity of the illuminator.
  • Page 6 Specimen Manipulation The mechanical stage of the T-1922C Cordless Comparison Microscope, allows the user to control the movement of the specimen slide on the X - Y axis. It consists of a slide holder and two sub-stage knobs, one of which moves in the X direction (left &...

  • Page 7: Care And Maintenance

    Painted surfaces can be cleaned with a moistened cloth. Ken-A-Vision has quality technicians on staff to repair or service your microscopes. Ken-A-Vision recommends service every two years for optimal life of the product. Extension 5620 for more details.
  • Page 8 Batteries The supplied batteries (3) type is a 1.2V 2000mA NiMH (Nickel Metal Hydride). Should you need battery replacement visit the Ken-A-Vision Web site, http://store.kenavision.com/catalog/ or contact your local Ken- A-Vision Dealer for (Cordless Comprehensive Scope Replacement batteries). USE OF NON-RECHARGEABLE BATTERIES WILL VOID ANY WARRANTY.

This manual is also suitable for:

T-1924c
