  • Page 1 Cordless Comparison Scope Instruction Manual T-1924C...

  • Page 2: Packing List

    Thank you for purchasing a Cordless Comparison Scope. Packing List Dust Cover Instruction Manual Power Supply / Charger Warranty Card & Sheet Allen Wrench Application The Ken-A-Vision Cordless Comparison Scope is a useful addition to a forensic curriculum, the teaching of Embryology, Histology, Geology or any subject involving the comparison of two specimens, side-by-side.
  • Page 3 Catalog Number T-1924C Sub-Stage Transmitted Lighting (Below-Stage Light) x/y Floating Stage Powered by Ken-A-Vision Cool Lighting Power source- NiMH Batteries Light Rheostat to adjust lighting Contour Base Specifications subject to change without notice 1. Seidentopf Binocular Head 2. Eyepiece Tubes 3.

  • Page 4: Operation

    Step 2. At the top of the head socket of each microscope base find three screw holes. There are "saftey screws" in each hole, removable using a small screwdriver. Underneath these "saftey screws" there are set screws. Using the small Allen wrench provided, back off the set screws two or three turns, until flush with the inside rim of the head socket of the base.
  • Page 5 through the condenser for a standard microscope slide. Depressing the left side switch turns on the supra-stage light for macro and opaque objects. Built-in Illuminator(s) T-1924C - There are two illuminators built into to each of the microscope bases, one is sub-stage and one is supra-stage. The supra-stage illuminator is necessary for macro or opaque specimens where light from the sub-stage illuminator can not come through.

  • Page 6: Care And Maintenance

    Now using the X-axis knob set for split screen, one can view the left microscope specimen on the left, the right microscope specimen on the right, or roll the knob and see only the left or the right specimens. Specimen Manipulation The T-1924C comes with a "floating stage".
  • Page 7 Equipment Rating: Description Input Output Connection This is a 2.5 mm barrel style center pin, with a 5.5 volt, 300mA, output supply which may be used with 110v, 220v, 230v, or 240v input systems. The power supply /charger is made exclusively for the Ken-A-Vision Cordless Microscope.
  • Page 8 Batteries The supplied batteries (3) type is a 1.2V 2000mA NiMH (Nickel Metal Hydride). Should you need battery replacement visit the Ken-A-Vision Web site, http://store.kenavision.com/catalog/ or contact your local Ken- A-Vision Dealer for (Cordless Comprehensive Scope Replacement batteries). USE OF NON-RECHARGEABLE BATTERIES WILL VOID ANY WARRANTY.
