Page 1: Table Of Contents
CONTENTS INTRODUCTION............1 FEATURES..............1 SPECIFICATIONS..........1-2 EXPLANATION OF FEATURES......3-5 INSTALLATION.............6 BD-25 OPTIONAL ADAPTORS......7-8 PRECAUTIONS............9-10 CONNECTION DIAGRAMS........11-12 OPERATION............13 BD-25 BOOSTER AMP. BLOCK CIRCUIT...14 WARRANTY............15... -
Page 2: Introduction
INTRODUCTION The BD-25 is a dual band power linear amplifier designed for the 144/430 MHz band. It has a maximum output power of 30W. The BD-25 incorporates a cross-band full duplex function that is the first of its kind in the industry. This compactly designed amplifier employs the new “two band/ one RF power... - Page 3 Accessory Circuits: 1. Automatic frequency selection controlled circuit. 2. Reverse DC power polarity protection circuit. 3. VHF/UHF ‘On Air’ indicator. Semiconductor Components: RF Power Transistor X 1, Transistors X 2, IC X1, Diodes X 8, LED X 5 Accessories: 1. Mobile mounting bracket 2.
-
Page 4: Explanation Of Features
EXPLANATION OF FEATURES -- --... - Page 5 VHF INDICATOR The VHF Indicator LED indicates the amplifier is transmitting on the VHF Band. UHF INDICATOR The UHF Indicator LED indicates the amplifier is transmitting on the UHF Band. PWR INDICATOR The Power Indicator LED indicates the amplifier is ON and standing by to transmit.
- Page 6 There are various adaptors suitable for different models of handy-transceivers. MOUNTING BRACKET The mounting bracket allows easy attachment of your BD-25 to your car. ADAPTER POWER SWITCH The adaptor power can be turned OFF (middle position) when the amplifier is not in use. You can select the adaptor to be 10.8V (left position) for new HT models or...
-
Page 7: Installation
INSTALLATION -- --... -
Page 8: Optional Adaptors
BD-25 OPTIONAL ADAPTORS HAM RADIO ADAPTOR COMPATIBLE TRANSCEIVER MODEL MAKER MODEL ICOM MI-1 IC-2N, 02N, 3N, 03N, 12N, 2G, 3G, 12G, 23, etc. ICOM MI-2 IC-2S, 2SAT, 2SR, 3S, 3SAT, 3SR, 24, W2, X2, etc. ICOM MI-3 IC-W21, X21, W21T, X21T etc. - Page 9 ADAPTORS and ADAPTOR POWER SETTING HAM RADIO ADAPTOR ADAPTOR POWER MAKER MODEL SETTING ICOM MI-1 13.8 ICOM MI-2 13.8 ICOM MI-3 13.8 ICOM MI-4 10.8 YAESU MY-1 10.8 YAESU MY-2 13.8 YAESU MY-3 10.8 YAESU MY-4 10.8 KENWOOD MK-1 10.8 KENWOOD MK-2 10.8...
-
Page 10: Precautions
PRECAUTIONS To avoid malfunctions and damages, and to achieve full performance, please pay careful attention to the following matters: During transmission, the heat sink may reach a high temperature (approx. 50°C-80°C). Set the amplifier in a well- ventilated place. Do not place objects on top of the amplifier. - Page 11 When utilizing a mono band antenna, check before operation that the antenna is identical with the transceiver operating frequency. When inserting the coaxial switch to either or both of the input and output sides of the amplifier unit in order to operate two sets of transceivers and antennas which have different frequencies, carefully check the position of the coaxial switch.
-
Page 12: Connection Diagrams
CONNECTION DIAGRAM Diagram 1 Diagram 2 -- --... - Page 13 Diagram 3 -- --...
-
Page 14: Operation
OPERATION Turn the power switch on. When switching to 144 MHz band (or 440 MHz band) transmitting mode, the power amplifier of this unit will operate and a high power signal is sent out through the antenna. Re-confirm the SWR and power at this time by checking a SWR or power meter. -
Page 15: Booster Amp. Block Circuit
BD-25 BOOSTER AMP. BLOCK CIRCUIT -- --... -
Page 16: Warranty
ONE YEAR LIMITED WARRANTY Any Mirage Communications product found to be defective in materials or workmanship will be repaired or replaced (at Mirage’s option) for a period of one year from the date of original purchase. During the warranty period Mirage Communications will provide, free of charge, both parts and labor necessary to correct defects in material or workmanship.
