Installation Instructions
Tracer Concierge
Small Buildings
Pre-Packaged Control Panel and Display
Model Numbers:
Only qualified personnel should install and service the equipment. The installation,
starting up, and servicing of heating, ventilating, and air-conditioning equipment can
be hazardous and requires specific knowledge and training. Improperly installed,
adjusted or altered equipment by an unqualified person could result in death or
serious injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the equipment.
September 2021
®
BMTC015ABC012000
BMTC030ABC012000
BMTC015CBC012000
SAFETY WARNING
BAS-SVN141D-EN
System for
BMTC030CBC012000
BMTC015CAC012000
BMTC030CAC012000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tracer Concierge BMTC015ABC012000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Trane Tracer Concierge BMTC015ABC012000

  • Page 1 Installation Instructions ® Tracer Concierge System for Small Buildings Pre-Packaged Control Panel and Display Model Numbers: BMTC015ABC012000 BMTC030CBC012000 BMTC030ABC012000 BMTC015CAC012000 BMTC015CBC012000 BMTC030CAC012000 SAFETY WARNING Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
  • Page 2 Chlorine, Fluorine and Carbon (CFCs) and those containing Hydrogen, Chlorine, Fluorine and Carbon (HCFCs). Not all refrigerants containing these compounds have the same potential impact to the environment. Trane advocates the responsible handling of all refrigerants-including industry replacements for CFCs and HCFCs such as saturated or unsaturated HFCs and HCFCs.
  • Page 3 Non-Trane personnel should always follow local regulations. Copyright This document and the information in it are the property of Trane and may not be used or reproduced in whole or in part, without the written permission of Trane. Trane reserves the right to revise this publication at any time and to make changes to its content without obligation to notify any person of such revision or change.
  • Page 4: Table Of Contents

    Wireless (Optional) ....6 ® Step 3: Install the UC400 2H/2C and Air-Fi Wireless for Non-Trane RTUs . 7 ® Step 4: Install the UC210 Bypass Damper and Air-Fi Wireless .
  • Page 5: Step 1: Verify Package Content

    Step 1: Verify Package Content Table 1. Packaged contents Part Number Package Contents ® BMTC015ABC012000 System Controller with 15 device license, Air-Fi Wireless Communication Interface (WCI), mounting kit (4 anchors/4 screws) ® BMTC030ABC012000 System Controller with 30 device license, Air-Fi Wireless Communication Interface (WCI), mounting kit (4 anchors/4 screws) ®...
  • Page 6: Step 2: Install Bci-R And Air-Fi

    ® Step 2: Install BCI-R and Air-Fi Wireless (Optional) ® Step 2: Install BCI-R and Air-Fi Wireless (Optional) ® If required for this site, install the BCI-R and Air-Fi Wireless. Use the wiring harness provided with the BCI-R to wire from the RTRM(J-4, 5-pin connector) to BCI-R(J-1, 4-pin ®...
  • Page 7: Step 3: Install The Uc400 2H/2C And Air-Fi ® Wireless For Non-Trane Rtus

    Step 3: Install the UC400 2H/2C and Air-Fi Wireless for Non-Trane RTUs If required for this site, install the UC400 2H/2C and Air-Fi Wireless on Non-Trane equipment. For more information, see Tracer UC400 Pre-programmed for RTU or Heat Pump (X39641251-01B). The point list below is for your convenience.
  • Page 8: Step 4: Install The Uc210 Bypass Damper And Air-Fi ® Wireless

    ® Step 4: Install the UC210 Bypass Damper and Air-Fi Wireless Step 4: Install the UC210 Bypass Damper and ® Air-Fi Wireless If required for this site, install the UC210 Bypass Damper. See the installation documentation. The point list below is for your convenience. Table 5.
  • Page 9: Step 5: Install Tracer Concierge System Panel

    Step 5: Install Tracer Concierge System Panel On WCS zone sensors, set: • GRP and NET to 1 and 1 • Address the WCS to match the corresponding unit controller To enter the WCS address settings, press and hold the address button for 3 seconds. Figure 5.
  • Page 10 Pollution: U.L. 840: Degree 2 Important: The Tracer Concierge System Panel enclosure must be installed indoors. Trane recommends locating the enclosure: • Where service personnel have easy access. • In areas that restrict public access to minimize tampering or vandalism.
  • Page 11 Step 5: Install Tracer Concierge System Panel Note: Use wall anchors if the mounting surface is dry wall or masonry. 3. Secure the enclosure to the mounting surface with the enclosed #10 screws and #10 wall anchors. 4. Remove the tie wraps that secure the modules to the DIN rail during shipping. Wiring High Voltage AC Power Read all WARNINGS, CAUTIONS, and NOTICES prior to wiring high-voltage AC power.
  • Page 12 Step 5: Install Tracer Concierge System Panel Note: The ground wire should be continuous back to the circuit breaker panel. WARNING Hazardous Voltage! Failure to replace the cover plate could result in death or serious injury. The cover plate must be in place when the controller is operating.
  • Page 13: Step 6: Wire I/O

    Step 6: Wire I/O 3. Align the hinge pegs on the door with the hinge holes on the enclosure and gently lower the door until it rests securely in the hinge holes. 4. Verify that the door swings freely on the hinges and that the magnetic latches hold the door securely when it is closed.
  • Page 14: Step 7: Mount The Display

    Step 7: Mount the Display Step 7: Mount the Display Note: The display is designed for conditioned indoor environments only. The display mounts to the wall using a VESA mount. The required VESA mounting bracket size is 75 mm x 75 mm. A VESA mount is included with the display, but any standard VESA mount should be acceptable.
  • Page 15: Step 8: System Startup

    Step 8: System Startup Step 8: System Startup ® Important: Ensure all equipment and Air-Fi Wireless are powered and operating before proceeding. This is because the network will be formed on power up of Tracer System Controller. 1. Apply power to the panel.Close the supply power disconnect switch that was locked open when connecting the 120 Vac Power Wires.
  • Page 16: Step 9: Display Setup

    Step 9: Display Setup Step 9: Display Setup 1. Power on the display by pressing the power button on the back of the display. 2. Follow the steps in the Setup Wizard. See the Tracer Concierge Installation, Operation, and Maintenance Guide (BAS-SVX074) for details. Figure 12.
  • Page 17: Step 10: Project Commissioning Checklist

    Step 10: Project Commissioning Checklist Step 10: Project Commissioning Checklist Verify that hardware installation is complete: Verify the Concierge System Controller panel is attached to the wall and power is wired to it. ® Verify System Controller Air-Fi Wireless is addressed properly per the submittal and/ or the Air-Fi Wireless Network Best Practice guide BAS-SVX55*-EN.
  • Page 18: Agency Listing And Compliance

    Agency Listing and Compliance Agency Listing and Compliance United States Compliance (Enclosure and modules are UL Listed separately) UL Listed — UL 916 Energy Management Accessory Canadian Compliance (Enclosure and modules are CUL Listed separately) CUL Listed — CSA C22.2 No. 205 BAS-SVN141D-EN...
  • Page 19 Notes BAS-SVN141D-EN...
  • Page 20 For more information, please visit trane.com or tranetechnologies.com. Trane has a policy of continuous product and product data improvement and reserves the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
