Congratulations on purchasing XP-8000-Atom-CE6 - the most popular automation
solution for remote monitoring and control application. This Quick Start Guide intends
to provide information for getting started with XP-8000-Atom-CE6. Please also consult
the User Manual for detailed information on the setup and use of XP-8000-Atom-CE6.
In addition to this guide, the package includes the following items:
XP-8000-Atom-CE6 Module
XP-8141-Atom-CE6
XP-8341-Atom-CE6
XP-8741-Atom-CE6
● XP-8000-Atom-CE6 User Manual
CD:\XPAC-ATOM-CE6\Document\User_Manual\
http://ftp.icpdas.com/pub/cd/xpac-atom-ce6/document/user_manual/
● XP-8000-Atom-CE6 Website
http://www.icpdas.com.tw/product/solutions/pac/xpac-atom/xpac-atom_introduction.html
Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved.
XP-8000-Atom-CE6 Quick Start Guide
2 GB CF card
Version 1.0.3, June 2012
Software Utility CD Screw Driver
E-mail: service@icpdas.com
(1C016)
2.4 mm
- 1
Advertisement
Table of Contents
Related Manuals for ICP DAS USA XP-8000-Atom-CE6
Summary of Contents for ICP DAS USA XP-8000-Atom-CE6
- Page 1 This Quick Start Guide intends to provide information for getting started with XP-8000-Atom-CE6. Please also consult the User Manual for detailed information on the setup and use of XP-8000-Atom-CE6. In addition to this guide, the package includes the following items:...
- Page 2 -------------------------------------------------------------------------------- Configuring the boot mode Before starting any installation, be sure that the switch is placed in the “0” position. -------------------------------------------------------------------------------- Connecting to PC, Monitor and Power Supply i. Connect the LAN port to a router (or hub). the USB mouse and USB keyboard to the USB port. Connect iii.
- Page 3 -------------------------------------------------------------------------------- Changing the User Interface Language The "Regional Settings" is a Windows CE functionality that allows users to easily change the XP-8000-Atom-CE6 user interface with your native language. Click “Start” >> “Settings” >> “Control Panel”, and then click Step 1 “Regional Options”...
- Page 4 Click “User Interface Language” tab, choose your local language Step 2 from drop-down menu, and then click “OK” Click “OK”, and then reboot the XP-8000-Atom-CE6 for changes Step 3 to take effect -------------------------------------------------------------------------------- Configure the XP-8000-Atom-CE6 The XPAC Utility is a tool kit designed to quickly control and configure XP-8000-Atom-CE6.
- Page 5 DCON Utility is a tool kit designed to quickly control and configure I-87K series expansion I/O modules on XP-8000-Atom-CE6. Step 1 On XP-8000-Atom-CE6 side, double-click the server program, “DCON_CE_Vxxx” The “DCON_CE_Vxxx” are pre-installed on the XP-8000-Atom-CE6, located under \System_Disk\Tools\DCON_CE Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
- Page 6 On PC side, double-click the “DCON Utility “ Step 2 The “DCON Utility” can be installed from the CD that was provided with the package or by downloading the latest version from ICP DAS web site. CD:\XPAC-ATOM-CE6\PC_Tools\DCON_Utility\ http://ftp.icpdas.com/pub/cd/xpac-atom-ce6/pc_tools/dcon_utility/ Click the “WINCE” common button Step 3 Copyright ©...
- Page 7 Click the “XPAC_CE” tab, type the IP address of the XP-8000-Atom-CE6, Step 4 and then click the “Connect to XPAC_CE” button Tips & Warnings If the DCON Utility cannot connect to XP-8000-Atom-CE6, the Ethernet connection between the host PC and the XP-8000-Atom-CE6 might be rejected by fire wall, please contact with MIS to open the Ethernet port.
- Page 8 COM port occupied. After you have finished configuring your module(s), you may start to develop your own applications. For detailed instructions and more applications, please refer to XP-8000-Atom-CE6 User Manual. Copyright © 2012 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
