Power considerations

Power cords

enclosures, DAEs, and control station inverters.
Figure 1 DPE/DAE power cord
Table 5 Cabling pinout (Positronics)
6 DC-Powered VNX™ Series Enclosures Installation and Operation Guide
Figure 1 shows the power cord provided by EMC for DC-powered disk processor
P1 designation
1
2
3
Table 5
Description Wire color
DC positive (+) Black
DC negative (-) Brown
Chassis ground Green/Yellow
describes the pin outs.
P1
2
P1
Positronic
1
3
CL4928
