Connect X200
CXG3.X200
A6V11974867_en--_c
2022-08-12
Connect X200 for the cloud integration of Siemens Smart infrastructure as well
as third-party systems
●
2-port Ethernet switch for LAN (incl. Daisy Chaining)
●
1-port Ethernet for WAN
●
2 EIA-485 interfaces
●
USB interface for 4G dongles
●
Operating voltage AC 24 V or DC 24 V
●
Mounting on standard rails or on the wall
●
Plug-in screw terminal blocks
●
Multi-site management (depending on firmware)
●
Remote operation & monitoring (depending on firmware)
●
Alarm treatment (depending on firmware)
●
Remote tool access, update and configuration via Siemens Cloud Services
(depending on firmware)
Smart Infrastructure
Advertisement
Related Manuals for Siemens Connect X200
Summary of Contents for Siemens Connect X200
- Page 1 Connect X200 CXG3.X200 Connect X200 for the cloud integration of Siemens Smart infrastructure as well as third-party systems ● 2-port Ethernet switch for LAN (incl. Daisy Chaining) ● 1-port Ethernet for WAN ● 2 EIA-485 interfaces ● USB interface for 4G dongles ●...
- Page 2 Functions Connect X200 is a gateway and edge device for small or medium size installations serving as the point of integration for Building Automation and Control Systems smart devices and cloud applications. A broad range of devices can be integrated at the system level, for applications such as HVAC, security, fire safety, power and lighting applications.
- Page 3 RUN LED is steady green and then release device first) button. A factory reset will be performed. All configuration data/installed apps are deleted. Short press IP address 169.254.169.254 will be assigned to LAN port for the duration of 15 min. Siemens A6V11974867_en--_c Smart Infrastructure 2022-08-12...
- Page 4 IEC 60332-1-2 and IEC 60332-1-3 or IEC TS 60695-11-21. Commissioning / service NOTICE When using a 4G dongle Reboot the device after a 4G dongle has been connected. For details see 4G Dongle Setup (A6V12059208). Siemens A6V11974867_en--_c Smart Infrastructure 2022-08-12...
-
Page 5: Function Data
10Base-T / 100Base-TX, IEEE 802.3 compatible Bit rate 10/100 Mbps, autosensing Protocol BACnet on UDP/IP and HTTPs on TCP/IP Cabling, cable type 10 Mbps: Min. CAT3, shielded cable is recommended 100 Mbps: Min. CAT5, shielded cable is recommended Cable length Max. 100 m (330 ft) Siemens A6V11974867_en--_c Smart Infrastructure 2022-08-12... - Page 6 Mechanical ambient conditions ● Transport per IEC/EN 60721-3-2 ● Class 2M4 ● Operation as per IEC/EN 60721-3-3 ● Class 3M11 Standards, directives and approvals Product standards EN 60730-1 and EN 62368-1 Product family standard EN 50491-x Siemens A6V11974867_en--_c Smart Infrastructure 2022-08-12...
- Page 7 1. This device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation FCC Caution: Changes or modifications not expressly approved by Siemens Switzerland Ltd. could void user authority to operate the equipment. United States representative https://new.siemens.com/us/en/products/buildingtechnologies/home.html Industry Canada statement This device complies with ISED’s license-exempt RSSs.
-
Page 8: Connection Terminals
Interfaces EIA-485 68, 69, 70 COM2 Warranty The application-specific technical data is guaranteed only in combination with the Siemens products listed in the 'Device combinations' section. If third-party products are used, any guarantee provided by Siemens will be invalidated. Dimensions... - Page 9 4 (0.16") 26.5 (1.04") 45 (1.77") 49 (1.91") 129 (5.08") 69.5 (2.73") 144 (5.67") 74.5 (2.93") Siemens A6V11974867_en--_c Smart Infrastructure 2022-08-12...
- Page 10 Issued by © Siemens Switzerland Ltd, 2022 Siemens Switzerland Ltd Technical specifications and availability subject to change without notice. Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug +41 58 724 2424 www.siemens.com/buildingtechnologies Document ID A6V11974867_en--_c Edition 2022-08-12...
