Summary of Contents for Hoover H-WASH 300 PRO
-
Page 3: Table Of Contents
Thank you for choosing this product. WEEE contains both polluting substances (which We are proud to offer the ideal product for can cause negative consequences for the you and the best complete range of home environment) and basic components (which can appliances for your daily routine. -
Page 4: General Safety Rules
1. GENERAL SAFETY in a safe way and understand the hazards involved. RULES Children shall not play with the This appliance is intended to appliance. Cleaning and user be used in household and maintenance shall not be made similar applications such as: by children without supervision. - Page 5 Items such as foam rubber WARNING: (latex foam), shower caps, never stop a washer dryer before waterproof textiles, rubber the end of the drying cycle backed articles and clothes or unless all items are quickly pillows fitted with foam rubber removed and spread out so that pads should not be dried in the the heat is dissipated.
- Page 6 To consult the product technical Do not pull on the power cord specification please refer to the or appliance to unplug the manufacturer website. machine. Make sure there is no water in Electrical connections the drum before opening the safety instructions door.
-
Page 7: Installation
2. INSTALLATION Remove the 2 or 4 transportation screws (A) on the back and remove the 2 or 4 flat washers, rubber bungs and plastic spacer tubes (B) as illustrated in figure 1. If the washing machine is built- ... - Page 8 Instructions for mounting the furniture door Position the template onto the reverse of the furniture door. It is possible to mount the hinges and closure magnet on the right or left-hand side depending on your requirements. Mark the screw hole positions, then drill out these positions.
- Page 9 Mount the furniture door to the front of the washer using the hinges. Fix the spacers (I) in place with the 2 screws (J) and then fix the hinges with 2 screw (H). We suggest mounting the furniture door so that it opens towards the left, which is the same direction as the porthole door.
- Page 10 Hydraulic connections Connect the water hose to the water supply tap (fig. 3) only using the hose supplied with the appliance (do reuse old hose-sets). SOME MODELS may include one or more of the following features: HOT&COLD (fig. 4): ...
- Page 11 Setting The washing machine should be installed in its final position such that the water fill hose is not kinked or trapped. The corrugated drain hose should be inserted into suitable drain pipe of between 50 cm and 85 cm height above the floor using the curved drain hose support.
-
Page 12: Detergent Drawer
3. DETERGENT DRAWER WARNING: detergent draw split into some detergents are not designed for compartments as illustrated in figure 9: use in the dispenser drawer but are supplied with their own dispenser that compartment "1": for prewash detergent; is placed in the drum directly. compartment “... -
Page 13: Practical Hints
4. PRACTICAL HINTS Maximise the load size Achieve the best use of energy, water, Load tips detergent time using recommended maximum load size. When sorting laundry, make sure: Save up to 50% energy by washing a full load instead of 2 half loads. - have eliminated metallic objects such as hair clips, pins, coins, from laundry;... - Page 14 The use of ecological detergents without When washing heavily soiled whites, phosphates cause following we recommend using cotton programs of effects: 60°C or above and a normal washing powder (heavy duty) that contains - cloudier rinse drain water: This effect is bleaching agents that at medium/high tied to the suspended zeolites which do temperatures provide excellent results.
-
Page 15: Cleaning And Maintenance
5. CLEANING AND Remove and clean the filter; when finished, replace it turning it clockwise. MAINTENANCE The filter handle will be locked when it is not possible to turn any further and the Looking after your appliance correctly can handle is horizontal. -
Page 16: Quick User Guide
6. QUICK USER GUIDE 7. CONTROLS AND PROGRAMMES This washing machine automatically adjusts the level of the water to the type and quantity of washing. This system gives a reduction in energy consumption and a saving in washing times. Program selection Turn on the washing machine and select ... - Page 17 PROGRAMME selector with OFF When the START/PAUSE button has position been pressed, the appliance can take few seconds before it starts working. When the programme selector is turned the display lights up to show the settings PAUSING THE MACHINE for the programme selected. Keep the START/PAUSE button pressed ...
- Page 18 - Press the delay start button once to If you exceed the maximum dryable activate it (h00 appears on the display) load of laundry indicated in the and then press it again to set a 1 hour programme table, the laundry may not delay (h01 appears on the display).
- Page 19 RAPID / STAIN LEVEL button To prevent damage to the fabrics, it is not possible to increase the speed This button allows you to choose between over the maximum allowed for the two different options, depending on the programme. selected programme. - RAPID ...
- Page 20 3) DOOR LOCKED INDICATOR LIGHT Digital Display The indicator light is illuminated when the door is fully closed. The display’s indicator system allows you to be constantly informed about the status of the machine. Close the door BEFORE selecting the START/PAUSE button.
- Page 21 - adjusts the rhythm of drum rotation for 6) WASH TEMPERATURE INDICATOR the type of fabric being washed; LIGHTS This shows the washing temperature of the - recognises the presence of too much selected programme that can be changed soap suds, and if necessary, adjust the (where allowed) by the relevant button.
- Page 22 Table of programmes (MAX.) PROGRAMME (see control panel) (MAX.) 30° Shirts 90° Cottons 60° Cottons + Prewash 60° ECO 40-60 Wash and Dry (ECO 40-60 + 20° 20°C 60° Mixed Drain & Spin Rinse 30° Wool & Soft Care 60° Allergy Care 60°...
- Page 23 Please read these notes: INFORMATION FOR THE TEST Maximum load capacity of dry clothes, LABORATORIES according to the model used (see control panel). STANDARD PROGRAMMES ACCORDING TO When a programme is selected, Directive 96/60/CE on the display is shown the display shows the recommended WASHING: wash temperature that can be...
- Page 24 ECO 40-60 Description of programmes The ECO 40-60 programme is able to clean normally soiled cotton laundry declared to To clean different types of fabrics and be washable at 40°C or 60°C, together in various levels of dirt, the washing machine the same cycle.
- Page 25 Wool & Soft Care Dry Wool This programme performs a wash cycle Low temperature drying programme, ideal dedicated to the "Machine Washable" Wool to dry woollen clothes with maximum care fabrics, to the articles to be washed by hand and softness, reducing rubbing of fabrics and to treat delicate garments and precious and avoid possible felting.
-
Page 26: Drying Cycle
8. DRYING CYCLE The correct way to dry Drying guidance advice is general, but Open the door. practical experience of using the product will help you to achieve the best drying results. Fill with the laundry, not exceeding the ... - Page 27 When the programme is finished the word selecting wool drying "End" will appear on the display. After programme, it's not possible to select 5 minutes the appliance will go into a degree of dryness different from the standby mode (on certain models, the default one.
-
Page 28: Automatic Washing/Drying Cycle
9. AUTOMATIC WASHING/ At the end of the wash phase the display will show the drying time remaining. DRYING CYCLE The drying programme indicator will be You cannot exceed the maximum on, until the cool down phase begins and dryable load of laundry indicated in the corresponding indicator is on. -
Page 29: Troubleshooting And Warranty
10. TROUBLESHOOTING AND WARRANTY If you believe the washing machine is not working correctly, consult the quick guide provided below which includes some practical tips on how to fix the most common problems. ERROR CODE FORMAT Models with a display: the error is shown by a number preceded by the letter “E” ... - Page 30 OTHER ANOMALIES Problem Possible causes and practical solutions The washing machine Make sure the product is plugged into a working supply socket. Make sure power is on. does not work / start Make sure the wall socket is working, testing it with another appliance such as a lamp.
- Page 31 It is always recommended to use original By placing the mark on this spare parts, that are available at our product, we are confirming compliance Authorised Customer Service Centres. to all relevant European safety, health and environmental requirements which are applicable in legislation for this Warranty product.
- Page 32 - HBD D A E (21) -...
Need help?
Do you have a question about the H-WASH 300 PRO and is the answer not in the manual?
Questions and answers
I dont think there is any detergent coming out of the drawer despite the compartment being topped up when i first got it, about three weeks ago. Clothes are coming out, but dont have that distinctive smell of Fairy?
There are several possible reasons why no detergent is coming out of the drawer in your Hoover H-Wash 300 Pro:
1. Blocked Detergent Drawer – Detergent residue may have built up in the drawer, preventing proper flow. Clean the drawer regularly with a microfibre cloth and avoid using acidic or aggressive cleaning products.
2. Clogged Dispenser Nozzle – The internal parts of the dispenser may be blocked by detergent residue or limescale. Running an empty wash cycle at 90 degrees once a month and using a washing machine cleaner every few months can help prevent build-up.
3. Low Water Pressure – If the water pressure is too low, it may not be flushing the detergent properly. Check your household water supply.
4. Pump Filter Issues – A clogged pump filter might affect water flow. The filter should be cleaned 5–6 times a year to prevent drainage problems.
5. Installation Issues – If the washing machine is not installed correctly, water may not be reaching the detergent drawer properly. Ensure proper installation and check for kinks in the water supply hose.
Cleaning the detergent drawer and ensuring proper maintenance should resolve most issues.
This answer is automatically generated
@Mr. Anderson thank you. My washer is less than four weeks old. I have had the drawer out, the two ‘exits’ for the washing liquid and the conditioner are clear. I did put a little extra liquid in the front of the draw, that powders normally go into, and I found the clothes came out smelling slightly of the Fairy washing liquid. I never have seen any ‘sudsy’ water in the drum, when I’m using the washer. Should I not expect that with the ‘A’ rating of the machine? Many thanks.
You say firmly but gently to remove drawer for proper cleaning, can I please have a more precise direction since this washer is not mine?
To properly remove the drawer for cleaning on a Hoover 300 PRO washer:
1. Gently but firmly remove the detergent drawer.
2. Clean the drawer under running water.
3. Put the drawer back into its compartment.
This answer is automatically generated
Sorry I meant I pressed the start button but the washing machine does not start
The Hoover H-WASH 300 PRO washing machine may not start after pressing the start button due to the following reasons:
1. The machine is not plugged into a working power socket.
2. The power is off or the wall socket is not working.
3. The door is not correctly closed.
4. The required program was not correctly selected.
5. The machine is in pause or delay start mode.
This answer is automatically generated
I press the start button but the machines ne does not stary
The Hoover H-WASH 300 PRO may not start when the START/PAUSE button is pressed for the following reasons:
1. The appliance may take a few seconds to start after pressing START/PAUSE.
2. The door is not properly closed. If the door is not fully shut, the DOOR LOCKED indicator will flash for about 7 seconds and the start command will be deleted. The door must be fully closed before pressing START/PAUSE.
3. The DOOR LOCKED light must be illuminated to confirm the door is locked. If it is not, the machine will not start.
4. A delay start may have been set. If so, the machine will start only after the countdown ends.
5. The machine is paused. Pressing START/PAUSE again will resume the cycle.
Ensure the door is closed properly and check for any delay start or pause status.
This answer is automatically generated
What is the rapid care button. 14,30,44 ?
The Rapid Care button on the Hoover H-WASH 300 PRO allows the selection of a rapid washing program when the RAPID CARE program is chosen on the knob.
This answer is automatically generated
