MIXER FUNCTION
1.INPUT....................................RCA (LINE/PHONO Unbalance) x 1 pair
2.OUTPUT.................................RCA (MASTER1/MASTER2) x 2 pair
3.Replaceable Xfader
4.7 segment meter LED's for each channel and separate 2x7 segment for master
AUDIO OUTPUT STANDARD
OUTPUT LEVEL..............................7 ± 0 .5Vrms (1KHz 0dB)
S/N RATIO..............................MORE THAN 80dB
FREQUENCY RESPONSE............20Hz~20KHz ± 2 dB
CHANNEL SEPARATION............MORE THAN 60dB
CHANNEL BALACE.................. ± 1 dB
HARMONIC DISTORTION...........LESS THAN 0.09%
1/4" TRS JACK (MIC) x 1 pair
1/4" TRS JACK (MASTER Balance) x 1 pair
1/4" TRS JACK (PHONE) x 1 pair
1/8" JACK (PHONE) x 1 pair
