AXEL
2038 DINING CHAIR - SKU # 42420389, 42520381, 42620383, 42720385
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts.
Which may have come loose inside the carton during shipment. Identify and count all parts and compare with
the hardware list as below :
Hardware List
Parts List
PARTS DETAILS
No.
1
2
3
4
No.
A
Back Rest
Front Leg (L & R)
B
Cushion Seat
C
D
Side Stretcher
Description
JCBC M6 with washer
JCBC M6 with washer
Allen Wrench (M4)
Pan Head Screw M4
Description
(L)
Dimension
6 x P1.0 x 50mm
6 x P1.0 x 80mm
4 x 60mm
4 x 38mm
(R)
B
Page 1 of 2
MODEL : 2038
Qty
6 Pcs
4 Pcs
1 Pc
4 Pcs
Qty
1 Pc
2 Pcs
1 Pc
2 Pcs
A
C
D
Advertisement
Table of Contents
Related Manuals for ROOMS TO GO AXEL 2038
Summary of Contents for ROOMS TO GO AXEL 2038
- Page 1 Page 1 of 2 MODEL : 2038 AXEL 2038 DINING CHAIR - SKU # 42420389, 42520381, 42620383, 42720385 Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts. Which may have come loose inside the carton during shipment. Identify and count all parts and compare with the hardware list as below : Description Picture...
- Page 2 Page 2 of 2 Assembly step STEP 1 Assemble SEAT to BACKREST as illustration shown. DO NOT TIGHTEN THE SCREWS UNTIL FULLY SET UP. STEP 2 Assemble FRONT LEG to SEAT together with STRETCHER as illustration shown. DO NOT TIGHTEN THE SCREWS UNTIL FULLY SET UP. NOTE: To ensure that chair is level, assemble the chair on flat &...
