CAUTION: Make all connections before plugging the System into an AC power outlet.

Connecting the FM Antenna

L
R
Connecting the AM (MW/LW) Antenna
L
R
CAUTION: To avoid noise, keep antennas away
from the System, the connecting cord and the AC
power cord.
Using the Supplied Wire Antenna
OPTICAL
DIGITAL OUT
Using the Coaxial Type Connector (Not Supplied)
A 75-ohm antenna with coaxial type connector (IEC or DIN45 325)
should be connected to the FM 75-ohm COAXIAL terminal.
R L
If reception is poor, connect the outside antenna.
Note: Before attaching a 75 ohm coaxial lead (the kind with a
OPTICAL
DIGITAL OUT
R L
FM wire antenna (supplied)
Coaxial cable
round wire going to an outside antenna), disconnect the sup-
plied FM Wire Antenna.
AM loop antenna (Supplied)
Attach the AM loop to its base by snapping the tabs on the
loop into the slot in the base.
FM (75 )
AM EXT
AM LOOP
Turn the loop until you have the best reception.
FM outdoor antenna
(Not supplied)
3
