WOOD GAMER READY 70" TV STAND WITH "X" FRONT DOORS
MUEBLE DE TV DE 70 "LISTO PARA JUEGOS DE MADERA CON PUERTAS
MEUBLE TV EN BOIS 70" GAMER READY AVEC PORTES AVANT "X"
6536-882
6537-882
6538-882
Made in Malaysia
Hecho en Malaysia
Fabriqué en Malaysia
FRONTALES" X "
Examine all packaging material for small parts that may have come loose during shipment. Periodic checks are
recommended to ensure that a components are in proper position, tight and free from damage. Keep this
asembly instruction for future reference. Adult assembly is required.
Examine el material de embalaje en busca de piezas pequeñas que puedan haberse aflojado durante el
transporte. Se recomienda realizar verificaciones periódicas para asegurar que todos los componentes estén
en la posición correcta, apretados y libres de daños. Guarde estas instrucciones de ensamblaje para
referencias futuras. El ensamblaje debe ser realizado por un adulto.
Examinez tous les matériaux d'emballage por les petites pièces qui peuvent avoir été lâche pendant le
transport. Des contrôles périodiques sont recommandées afin d'assurer que tous les composants sont en
bonne position, tendu et sans dommages. Gardez ces instructions de montage pour référence future.
Assemblage par un adulte est requise.
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Living Essentials 6536-882 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hillsdale Furniture Living Essentials 6536-882

  • Page 1 WOOD GAMER READY 70" TV STAND WITH "X" FRONT DOORS MUEBLE DE TV DE 70 "LISTO PARA JUEGOS DE MADERA CON PUERTAS FRONTALES" X " MEUBLE TV EN BOIS 70" GAMER READY AVEC PORTES AVANT "X" 6536-882 Examine all packaging material for small parts that may have come loose during shipment. Periodic checks are recommended to ensure that a components are in proper position, tight and free from damage.
  • Page 2 ATTENTION Before getting started, if you purchase this unit with fireplace option, please refer to the Assembly Instructions supplied in fireplace box. ATENCIÓN Antes de comenzar, si compra esta unidad con chimenea opción, consulte las instrucciones de montaje suministradas en chimenea caja. ATTENTION FIREPLACE Avant de commencer, si vous achetez...
  • Page 3 Page 3...
  • Page 4 DO NOT EXCEED RECOMMENDED LOAD. Use with products heavier than the maximum sizes and weights indicated may result instability causing possible injury. Do not allow children under 10 year to move unit. Manufactured for : HILLSDALE FURNITURE, LLC SKU# : 6536−882, 6537−882, 6538−882 Manufactured date :...
  • Page 5 PARTS CONTENTS Before getting started, ensure the package contains the following components: CONTENIDO Antes de comenzar, asegúrese de que el paquete contenga los siguientes componentes: CONTENU Avant de commencer, assurez-vous que l'emballage contient les composants suivants: Page 5...
  • Page 6 HARDWARE 1. Unitar Screw M6.3 x 40mm 2. Screw M4 x 38mm 3. Cam Bolt 29 x 4. Wooden Dowel M8 x 30mm 6. Screw M3.1 x 20mm 5. Screw M4 x 20mm 28 x 20 x 7. Screw M4 x 22mm 8.
  • Page 7 HARDWARE 16. Cam Nut 17. Handle 18. Back Ply Stopper 29 x 18 x 19. Magnet Catch 20. Metal Plate 21. Hinges 22. PVC Block 35mm 23. Plastic Leg 78mm 24. USB Dual Port with Adaptor 25. Hook 2 x 45 x 60 x 15mm 26.
  • Page 8 HARDWARE FURNITURE TIPPING RESTRAINT 30. Safety Bracket 31. Restraint Strap 32. Screw 2" 33. Screw 5/8" 34. Wall Plug TOOLS REQUIRED FOR ASSEMBLY (NOT INCLUDED) 3.5m/12' DO NOT USE POWER TOOLS TO ASSEMBLE THIS PRODUCT. USE OF POWER TOOLS WILL INVALIDATE ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE.
  • Page 9 Assembly / Montaje / Assemblage STEP 1 / ETAPA 1 / ÉTAPE 1 STEP 2 / ETAPA 2 / ÉTAPE 2 Page 9...
  • Page 10 STEP 3 / ETAPA 3 / ÉTAPE 3 STEP 4 / ETAPA 4 / ÉTAPE 4 11 x Page 10...
  • Page 11 STEP 5 / ETAPA 5 / ÉTAPE 5 STEP 6 / ETAPA 6 / ÉTAPE 6 Page 11...
  • Page 12 STEP 7 / ETAPA 7 / ÉTAPE 7 STEP 8 / ETAPA 8 / ÉTAPE 8 Page 12...
  • Page 13 STEP 9 / ETAPA 9 / ÉTAPE 9 STEP 10 / ETAPA 10 / ÉTAPE 10 Page 13...
  • Page 14 STEP 11 / ETAPA 11 / ÉTAPE 11 STEP 12 / ETAPA 12 / ÉTAPE 12 Page 14...
  • Page 15 STEP 13 / ETAPA 13 / ÉTAPE 13 STEP 14 / ETAPA 14 / ÉTAPE 14 Page 15...
  • Page 16 STEP 15 / ETAPA 15 / ÉTAPE 15 STEP 16 / ETAPA 16 / ÉTAPE 16 Page 16...
  • Page 17 STEP 17 / ETAPA 17 / ÉTAPE 17 STEP 18 / ETAPA 18 / ÉTAPE 18 Page 17...
  • Page 18 STEP 19 / ETAPA 19 / ÉTAPE 19 STEP 20 / ETAPA 20 / ÉTAPE 20 Page 18...
  • Page 19 STEP 21 / ETAPA 21 / ÉTAPE 21 STEP 22 / ETAPA 22 / ÉTAPE 22 Page 19...
  • Page 20 STEP 23 / ETAPA 23 / ÉTAPE 23 STEP 24 / ETAPA 24 / ÉTAPE 24 18 x 18 x Page 20...
  • Page 21 STEP 25 / ETAPA 25 / ÉTAPE 25 STEP 26 / ETAPA 26 / ÉTAPE 26 Page 21...
  • Page 22 STEP 27 / ETAPA 27 / ÉTAPE 27 STEP 28 / ETAPA 28 / ÉTAPE 28 Page 22...
  • Page 23 STEP 29 / ETAPA 29 / ÉTAPE 29 STEP 30 / ETAPA 30 / ÉTAPE 30 Page 23...
  • Page 24 STEP 31 / ETAPA 31 / ÉTAPE 31 STEP 32 / ETAPA 32 / ÉTAPE 32 Page 24...
  • Page 25 STEP 33 / ETAPA 33 / ÉTAPE 33 STEP 34 / ETAPA 34 / ÉTAPE 34 Page 25...
  • Page 26 STEP 35 / ETAPA 35 / ÉTAPE 35 STEP 36 / ETAPA 36 / ÉTAPE 36 Page 26...
  • Page 27 IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT. IMPORTANTE: ESTA UNIDAD DEBE ESTAR SEGURA A LA PARED PARA AYUDAR A PREVENIR EL TIPOVER. SIGA ESTAS INSTRUCCIONES PARA INSTALAR EL SOPORTE DE SEGURIDAD ANTI-TIPPING PROPORCIONADO CON ESTE PRODUCTO.
  • Page 28 STEP 37 / ETAPA 37 / ÉTAPE 37 Drywall anchor that supplied with this product is general purpose wall plug only. Consult your local hardware store for appropriate anchors for the type of wall you intend to securely attach the safety bracket. Ancla de paneles de yeso que se suministra con este producto es enchufe de pared de propósito general solamente.
  • Page 29 OPTION 1: Attachment into a wall stud (preferred method) Using a stud finder, locate a stud in the wall. Place your unit against the wall, locate the position of another bracket on the wall, 2 inches below the bracket secured to the unit. Move your unit aside. Drive the screw through the smaller hole of the safety bracket into the wall stud.
  • Page 30 STEP 38 / ETAPA 38 / ÉTAPE 38 STEP 39 / ETAPA 39 / ÉTAPE 39 Place the furniture into position so both safety brackets are vertically in line. Lace the end of the restraint strap through the larger hole in each safety bracket. Confirm that the strap is securely laced and locked.
  • Page 31 STEP 40 / ETAPA 40 / ÉTAPE 40 72 lbs 11 lbs 25 lbs 25 lbs This product is designed to withstand the weight indicated on the plan. We are not responsible for the breakage of parts or any injury caused by failure to comply with this recommendation. Este producto está...
