SET COMMUNICATION:

By Pressing the "Set Communication" button from the main window for SW67F33 (Fig. 2)
the window "Set Communication" appears (Fig. 3).
The means of the fields for the "Ethernet Connection" section are:
In the field "Device Name
defined;
If the field "Obtain an IP Address Automatically (DHCP for Cable
is checked, DHCP for LAN connection is enabled;
If the field "Obtain an IP Address Automatically (DHCP for Wi-Fi
is checked, DHCP for Wi-Fi connection is enabled;
If the field "Enable DNS" is checked, DNS protocol is enabled;
In the field "Primary DNS" the IP Address of the primary DNS server is defined;
In the field "Secondary
defined.
The means of the fields for the "LoRaWAN" section are:
In the field "RF Band" the wireless band used for LoRaWAN communication is
defined;
In the field "Network Type" the type of LoRaWAN network is defined;
In the field "Diagnostic
memory array where the status of the LoRaWAN end devices configured is saved.
The diagnostic is made bit to bit, so each bit will represent a status of a single end
device:
1  End device connected;
o
0  End device not connected.
o
The bits' order will be the same of the end devices' definition inside the LoRaWAN
Access section;
In the field "RX2 Datarate" the data rate on RX2 window is defined.
ADFweb.com S.r.l.
(Hostname)" the Hostname to assign to the converter is
DNS" the IP Address of the secondary DNS server is
Position" it is possible to define an offset into the internal
User Manual PROFINET Slave / LoRaWAN Gateway
Document code: MN67F33_ENG
Connection)"
Connection)"
Figure 3: "Set Communication" window
