Industrial Electronic Devices

User Manual

Revision 1.000

English

Gateway

CAN from/to Modbus Slave

(Order Code: HD67412-Exx-xxx)

for Website information:

www.adfweb.com?Product=HD67412

for Price information:

www.adfweb.com?Price=HD67412-E4V

www.adfweb.com?Price=HD67412-E7V

www.adfweb.com?Price=HD67412-E4R

www.adfweb.com?Price=HD67412-E7R

Benefits and Main Features:

Easy to configure

Metal enclosure with fixing lugs

Varnished / Resined (optionally)

Wide supply input range

Triple isolation

Industrial temperature range:

-40°C / 105°C (-22°F / 158°F)

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual CAN from/to Modbus Slave

Document code: MN67412_ENG

For other Gateways / Bridges:

CAN from/to Modbus

Need help?

Do you have a question about the HD67412-E Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ADF Web HD67412-E Series

Page 1 User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 1 of 25 Industrial Electronic Devices User Manual Revision 1.000 English Gateway CAN from/to Modbus Slave (Order Code: HD67412-Exx-xxx) for Website information: www.adfweb.com?Product=HD67412 for Price information: www.adfweb.com?Price=HD67412-E4V www.adfweb.com?Price=HD67412-E7V For other Gateways / Bridges: www.adfweb.com?Price=HD67412-E4R CAN from/to Modbus...
Page 2: Table Of Contents
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 2 of 25 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that you need to check that the following document is: Page Updated INDEX...
Page 3: Connection Scheme
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 3 of 25 Industrial Electronic Devices CONNECTION SCHEME: Figure 1-1: Connection scheme for HD67412-E4x-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 4 User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 4 of 25 Industrial Electronic Devices Figure 1-2: Connection scheme for HD67412-E7x-xxx ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 5: Power Supply
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 5 of 25 Industrial Electronic Devices POWER SUPPLY: The devices can be powered between a wide range of tensions. For more details see the two tables below. Vmin Vmax Vmin Vmax...
Page 6: Rs485
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 6 of 25 Industrial Electronic Devices RS485: The connection of the RS485 in the HD670412-E4x-xxx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page.
Page 7: Can
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 7 of 25 Industrial Electronic Devices CAN: The connection of the CAN in the HD67412-E4x-xxx device must be made with a 3way MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of the page.
Page 8: Characteristics
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 8 of 25 Industrial Electronic Devices CHARACTERISTICS: The “CAN from/to Modbus Slave” Gateway has the following characteristics: Two-directional information between networks CAN and Modbus; Metal Enclosure with four fixing lugs; Triple isolation between CAN - Power supply and between CAN –...
Page 9: New Project / Open Project
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 9 of 25 Industrial Electronic Devices NEW PROJECT / OPEN PROJECT: “New Project” button creates the folder which contains the entire device configuration. A device configuration can also be imported and exported: To clone the configurations of a Programmable “CAN from/to Modbus Slave”...
Page 10: General Parameter
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 10 of 25 Industrial Electronic Devices GENERAL PARAMETER: This section defines the fundamental communication parameters of two buses, CAN and Modbus. By pressing the “Set Communication” button from the main window for SW67412 (Fig. 2) the window “Set Communication”...
Page 11: Receive Cob
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 11 of 25 Industrial Electronic Devices RECEIVE COB: By pressing the “Receive COB” button from the main window for SW67412 (Fig. 2) the window “Receive CAN Frame” appears (Fig. 4). A user who has to read a CANbus frame from CANbus to Modbus needs to insert the coordinates of the CANbus frame in order to be transmitted in the field “Receive COB”...
Page 12: Define Cob
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 12 of 25 Industrial Electronic Devices DEFINE COB: By pressing the “Define COB” button from the main window for SW67412 (Fig. 2) the window “Receive CAN Frame Info” appears (Fig. 5): In the field “COB-ID Frame”...
Page 13: Transmitcon
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 13 of 25 Industrial Electronic Devices TRANSMIT COB: By pressing the “Transmit COB” button from the main window for SW67412 (Fig. 2) the window “Transmit CAN Frame” appears (Fig. 6). A user who has to write a CANbus frame from Modbus to CANbus needs to insert the coordinates of the CANbus frame in order to be transmitted in the field “Trasmit COB”...
Page 14: Define Cob
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 14 of 25 Industrial Electronic Devices DEFINE COB: By pressing the “Define COB” button from the main window for SW67412 (Fig. 2) the window “Transmit CAN Frame Info” appears (Fig. 7). In the field “COB-ID Frame”...
Page 15: Update Device
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 15 of 25 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update by CAN” button from the main window for SW67412 (Fig. 2) the right window appears (Fig. 8). Note: For updating the device you need the programmer “AC67400 - CAN Interface to configure devices”.
Page 16: Mechanical Dimensions
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 16 of 25 Industrial Electronic Devices MECHANICAL DIMENSIONS: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 17 User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 17 of 25 Industrial Electronic Devices Type A ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 18 User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 18 of 25 Industrial Electronic Devices Type B ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 19 User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 19 of 25 Industrial Electronic Devices Type C ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
Page 20: Ordering Informations
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 20 of 25 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67412 – E y z – s d f Fixing lugs A: Type 1 B: Type 2...
Page 21 User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 21 of 25 Industrial Electronic Devices Order Code: HD67412-E4V-NNA CAN from/to Modbus Slave with MiniFit connectors, electronic board varnished, RS485 not terminated, CAN not terminated and fixing lugs “Type A” Order Code: HD67412-E4V-NNB CAN from/to Modbus Slave with MiniFit connectors, electronic board varnished, RS485 not terminated, CAN not terminated and fixing lugs “Type B”...
Page 22 User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 22 of 25 Industrial Electronic Devices Order Code: HD67412-E4R-NNC CAN from/to Modbus Slave with MiniFit connectors, electronic board resined, RS485 not terminated, CAN not terminated and fixing lugs “Type C” Order Code: HD67412-E4R-NYA CAN from/to Modbus Slave with MiniFit connectors, electronic board resined, RS485 terminated, CAN not terminated and fixing lugs “Type A”...
Page 23 User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 23 of 25 Industrial Electronic Devices Order Code: HD67412-E7V-NYB CAN from/to Modbus Slave with SuperSeal 1.5 connectors, electronic board varnished, RS485 terminated, CAN not terminated and fixing lugs “Type B” Order Code: HD67412-E7V-NYC CAN from/to Modbus Slave with SuperSeal 1.5 connectors, electronic board varnished, RS485 terminated, CAN not terminated and fixing lugs “Type C”...
Page 24: Accessories
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 24 of 25 Industrial Electronic Devices Order Code: HD67412-E7R-YNA CAN from/to Modbus Slave with SuperSeal 1.5 connectors, electronic board resined, RS485 not terminated, CAN terminated and fixing lugs “Type A” Order Code: HD67412-E7R-YNB CAN from/to Modbus Slave with SuperSeal 1.5 connectors, electronic board resined, RS485 not terminated, CAN terminated and fixing lugs “Type B”...
Page 25: Warranties And Technical Support
User Manual CAN from/to Modbus Slave Document code: MN67412_ENG Revision 1.000 Page 25 of 25 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: 1) Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
