Homematic IP Compact Plus Mounting Instruction And Operating Manual page 47

First set up your Homematic IP Access Point via the Homematic IP
app to enable operation of other Homematic IP devices within your
system. For further information, please refer to the Access Point op-
erating manual.
You can pair the device with either the access point or the Homemat-
ic Central Control Unit CCU3. For detailed information, please refer
to the Homematic IP User Guide, available for download in the
download area of www.homematic-ip.com.
To integrate the device into your system and to enable control via the free
Homematic IP app, you must first add the device to your Homematic IP
Access Point.
To add the device, please proceed as follows:
• Open the Homematic IP app on your smartphone.
• Select "Add device".
• Open the battery compartments by pulling the cover (F) first
downwards and then forwards (see figure 3).
• Pull both insulation strips out of the battery compartment. The
pairing mode is active for 3 minutes. The device LED (D) starts to
flash orange (see figure 5).
You can manually start the pairing mode for another 3 minutes by
briefly pressing the system button (D). Select "INCL" and confirm
your selection by briefly pressing the menu button.
• Your device will automatically appear in the Homematic IP app.
• To confirm, enter the last four digits of the device number (SG-
TIN) in your app or scan the QR code. The device number can be
found on the sticker supplied or attached to the device.
• Wait until pairing is completed.
• If pairing was successful, the LED (D) lights up green. The device
is now ready for use.
Start-up
47
