Marantz MM8077 Service Manual

7 channel power amplifier
Hide thumbs Also See for MM8077:
Table of Contents

Advertisement

Quick Links

Service
Manual
• For purposes of improvement, specifications and design are subject to change without notice.
• Please use this service manual with referring to the operating instructions without fail.
• Some illustrations using in this service manual are slightly different from the actual set.
S0652-0V02M/DG1304
MM8077
Copyright 2013 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.
MM8077/
7 Channel Power Amplifier
N1B/U1B/K1B
Ver. 2
Please refer to the
MODIFICATION NOTICE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MM8077 and is the answer not in the manual?

Questions and answers

Related Manuals for Marantz MM8077

Summary of Contents for Marantz MM8077

  • Page 1 Service MM8077/ N1B/U1B/K1B Manual 7 Channel Power Amplifier • For purposes of improvement, specifications and design are subject to change without notice. • Please use this service manual with referring to the operating instructions without fail. • Some illustrations using in this service manual are slightly different from the actual set.

  • Page 2: Table Of Contents

    CONTENTs ABOUT THIs MANUAL .............3 What you can do with this manual ..........3 Using Adobe Reader (Windows version) ........4 sAFETY PRECAUTIONs ............7 TECHNICAL sPECIFICATIONs ..........8 DIMENsION ................8 DIsAssEMBLY ................9 1. FRONT PANEL ASSY ............10 2. CPU PCB ASS'Y ..............10 3. TRANS ................10 4.

  • Page 3: About This Manual

    ABOUT THIs MANUAL Read the following information before using the service manual. What you can do with this manual search for a Ref. No. (phrase) Jump to the target of a schematic diagram (Ctrl+shift+F) connector You can use the search function in Acrobat Reader to Click the Ref.

  • Page 4: Using Adobe Reader (Windows Version)

    Using Adobe Reader (Windows version) Add notes to this data (sign) Magnify schematic / printed wiring board The Sign function lets you add notes to the data in this diagrams - 1 manual. (Ctrl+space, mouse operation) Save the file once you have finished adding notes. Press Ctrl+space on the keyboard and drag the mouse to select the area you want to view.
  • Page 5 Magnify schematic / printed wiring board Magnify schematic / printed wiring board diagrams - 2 diagrams - 3 (Pan & Zoom function) (Loupe Tool function) The Pan & Zoom function lets you see which part of a The Loupe Tool function lets you magnify a specific magnified diagram is being shown in a separate window.
  • Page 6 Parts for your equipment are generally available to our National Marantz Subsidiary or agent. ORDERING PARTS : Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.

  • Page 7: Safety Precautions

    sAFETY PRECAUTIONs The following items should be checked for continued protection of the customer and the service technician. LEAKAGE CURRENT CHECK Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis resistance check.

  • Page 8: Technical Specifications

    TECHNICAL sPECIFICATIONs n MM8077 150 W/ch, 8 Ω Rated power output (from 20 Hz to 20 kHz/THD = 0.08 %, 180 W/ch, 6 Ω two channels driven): Maximum effective output power 210 W/ch, 6 Ω (from 1 kHz, 6 Ω, 10% two channels driven): Output connectors: 6 –...

  • Page 9: Disassembly

    DIsAssEMBLY • Disassemble in order of the arrow of the figure of following flow. • In the case of the re-assembling, assemble it in order of the reverse of the following flow. • In the case of the re-assembling, observe "attention of assembling" it. •...

  • Page 10: Front Panel Assy

    About the photos used for descriptions in the DIsAssEMBLY" section. • The direction from which the photographs used herein were photographed is indicated at "Direction of photograph: ***" at the left of the respective photographs. • Refer to the table below for a description of the direction in which the photos were taken. •...

  • Page 11: Input Pcb-2

    5. INPUT PCB-2 Proceeding : TOP COVER INPUT PCB-2 → Disconnect the connector wire. CN20 CN21 CN22 CN31 Remove the screws. Direction of photograph: A...

  • Page 12: Input Pcb-1

    6. INPUT PCB-1 Proceeding : TOP COVER INPUT PCB-2 INPUT PCB-1 → → Disconnect the connector wire. CN70 Remove the screws. Direction of photograph: A 7. POWER PCB AssY Proceeding : TOP COVER INPUT PCB-2 INPUT PCB-1 POWER PCB ASS'Y →...

  • Page 13: Amp Unit

    8. AMP UNIT Proceeding : TOP COVER INPUT PCB-2 INPUT PCB-1 AMP UNIT → → → Remove the screws. View from bottom Remove the screws. Direction of photograph: C...
  • Page 14 Disconnect the connector wires, then remove the screws. CN61 CN62 CN63 CN64 CN67 CN60 CN65 CN66 CN44 Disconnect the connector wire. CN50 CN60 CN61 CN51 CN21 CN20 CN11 CN10 Please refer to "EXPLODED VIEW" for the disassembly method of each PCB included in AMP UNIT.

  • Page 15: Special Mode

    sPECIAL MODE special mode setting button b Enters the special mode when A button is pressed in normal power state. Mode Button A Contents CPU version displayed. Service mode Service Furthermore,this unit in a condition of the following by pushing the Button A. 1-1 Protection Log display Service Displayed protection history.

  • Page 16: Cpu Version Check

    1. CPU Version check The firmware version is displayed on LEDs as follows. V1(D407) V2(D406) V3(D405) Version Ver1 Ver2 Ver3 Ver4 Ver5 Ver6 Ver7 1.1. Protection Log display The last time protection log is displayed on LEDs as follows if the Service button is pushed(>5sec) in the Service mode.

  • Page 17: Cooling Fan Active

    2. Cooling FAN active The fan rotates according to the condition of the temperature sensor(IC51,52,53,54) as follows. T :IC51,52,53,54 temperature Fan rotate T < 0°C STOP 0°C ≦ T < 10°C Rotate Low speed 10°C ≦ T Rotate High speed 2.1.

  • Page 18: System Error

    3. sYsTEM ERROR The reason for the error can be presumed from Standby LED display when the error occurs and protection log display. Refer to [1-1.] for the method of confirming protection log. If the AC power supply is turned off, the state of all protection can be released. Protection log display Error Detection...

  • Page 19: Version Upgrade Procedure Of Firmware

    The following items are required for updating. • Windows PC (OS: Windows2000 or WindowsXP) with Serial port. • RS-232C Dsub-9 pin cable (female to female/straight type) • Update software to CPU. (FlashSta.exe, MM8077_yymmddvv.mot and MM8077_yymmddvv.id in CPU (MM8077) folder) • DATA UPDATE KIT (part no. 90M-SR4500JIG) Use DATA UPDATE KIT to connect PC and CN40 (FFC connector) in rear panel of the unit, when updating CPU Update CPU’s software to internal Flash-ROM...
  • Page 20 Double click the CPU (MM8077) folder. MM8077 MM8077 MM8077 MM8077 CPU(MM8077) CPU(MM8077) Double click the FlashSta.exe. And launch the M16C Flash Start. CPU （MM8077） CPU （MM8077） MM8077... Check the internal flash memory in the Select Program. Choose the COM Port number. And the click OK.
  • Page 21 Click the Refer..(10) Choose the MM8077_yymmddvv.mot. And click Open. NOTE : The yy is two digit of year. The mm is month. The dd is date. The vv is version. CPU （MM8077） MM8077_xxxxxxxx.mot MM8077_xxxxxxxx.mot (11) The FilePath and ID are inputted automatically, and the MCU Type is selected to R8C automatically.
  • Page 22 (12) Click the Setting..(13) Choose the 57600 in the Baud rate. (DO NOT choose the other one.) Choose the 40 in Program_intervals(ms). Click the OK.
  • Page 23 (14) Click the E.P.R..(15) Click the OK. (16) Software is written into the internal Flash-ROM of CPU. The updating of software takes about 20 seconds.
  • Page 24 (17) Click the OK. (18) Click the Exit. (19) Disconnect the mains cord from the unit. (20) Disconnect the RS-232C cable from the unit.

  • Page 25: Adjustment

    ADJUsTMENT Idling Current Alignment Each of the measurement points are provided with the two test points. Set a digital Voltage meter to DC voltage input, connect the meter to the test points at both contact points. After the setup above, turn on the main switch. Adjust variable resistors (VR20 - VR50) according to the digital voltmeter readings.

  • Page 26: Trouble Shooting

    TROUBLE sHOOTING 1. POWER 1.1. Power not turn on Power not turn on. When the AC line turned on, does the Is a DC 5V voltage supplied from the ON/STANDBY indicator on the front Confirm +5V regulator(IC31) circuit. STANDBY PCB to the μ-com? panel light? Is the "P_DOWN"...

  • Page 27: Audio

    2. AUDIO 2.1. No audio output No audio output Is the signal input terminal(Bal or IChange the input selector SW to Unbal) and the Input selentor SW correct setting. setting suitable? Confirm ±21V power supply and Is the speaker relay(RY10,11,12,13) control line"SPK ON1,2,3,4"...
  • Page 28 2.2. Power Amp (AMP PCB) No audio output (caused by power amp) Is the power transistor open or short circuit? Replace the power transistor. 2SC2922/2SA1216 Is the emitter resistance of the power transistor open? Replace the emitter resistance. (0.10Ω) Is the base resistance of the power transistor open? Replace the base resistance.
  • Page 29 Personal notes:...

  • Page 30: Block Diagram

    BLOCK DIAGRAM MAIN AMP SPK OUT V Ref. +18V 2SA1216/2SC2922 +21V +15V DC_AMP_DET. UNBAL FL_LEVEL_DET. FL_SIGNAL_DET. CURR_AMP_DET. SPK_ON4 DC_AMP_DET. +15V FR_LEVEL_DET. FR_SIGNAL_DET. -21V CURR_AMP_DET. +21V UNBAL DC_AMP_DET. SL_LEVEL_DET. SL_SIGNAL_DET. CURR_AMP_DET. +15V SPK_ON3 DC_AMP_DET. SR_LEVEL_DET. SR_SIGNAL_DET. -21V CURR_AMP_DET. UNBAL +21V DC_AMP_DET. SBL_LEVEL_DET.

  • Page 31: Level Diagram

    LEVEL DIAGRAM MM8077 UNBALANCED LEVEL DIAGRAM...
  • Page 32 MM8077 BALANCED LEVEL DIAGRAM...

  • Page 33: Printed Wiring Boards

    PRINTED WIRING BOARDs BALANCED INPUT (COMPONENT sIDE) CUP12070Y-1 JK50 JK51 JK60 JK61 JK70 JK71 JK80 JK81 C523 C524 C623 C624 C723 C724 C823 C824 BN37 BN36 BN35 BN34 BN33 BN32 BN31 BN30 ET20 1.FL 1.FR 1.SL 1.SR 1.SBL 1.SBR 1.CNT 1.OPT.
  • Page 34 UNBALANCED INPUT (COMPONENT sIDE) CUP12070Z CUP12070Y-2 SW10 SW11 SW20 SW21 SW30 SW31 SW40 SW41 JK10 JK11 JK20 JK21 JK31 JK41 JK30 C103 C104 C203 C204 C303 C304 C403 C404 JK40 C301 C302 C101 C102 C201 C202 C401 C402 CUP12070Z DIPPING C151 C150 OPT.
  • Page 35 ICT ADJ1 ADJ2 RP CUP12071Y COP12071B (COMPONENT sIDE) MM8003 MP AMP PWB CUP12071Y 2008.06.03 COP12071C CN72 CUP12071Y C201 R201 R202 C202 C204 D202 R204 CN63 C301 R301R302 C401 R401 R402 C501 C203 D201 R203 C302 C304 D302 R304 C403 D401 R403 C402 C404...
  • Page 36 POWER sPK POWER sPK (COMPONENT sIDE) (FOIL sIDE) CUP12072Y CUP12072Y 15.FAN_GND 14.GND C133 CN30 13.+18V CN40 C132 12.GND R128 R162 11.+5VL 10.FAN2 9.FAN1 R133 8.P_CON_CURR D106 7._HEAT_DET_3 R132 6._HEAT_DET_3 D105 5._HEAT_DET_2 4._HEAT_DET_1 R107 C114 3._P_CURR_FAIL D103 2._P_AMP_FAIL 1._HEAT_DET_P C115 D121 D123 D113 C112...
  • Page 37 DIsPLAY KEY sTBY LED sTBY LED (COMPONENT sIDE) (COMPONENT sIDE) FRONT (COMPONENT sIDE) (FOIL sIDE) CUP12337Z-2 CUP12337Z-3 CUP12337Z-1 CUP12337Z-3 DIsPLAY KEY (FOIL sIDE) CUP12337Z-2 FRONT (FOIL sIDE) CUP12337Z-1 sTBY LED sTBY LED (COMPONENT sIDE) (FOIL sIDE) CUP12337Z-4 CUP12337Z-4 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 38 CPU (COMPONENT sIDE) CPU (FOIL sIDE) CUP12497Z-1 CUP12497Z-1 R416 R418 SW40 R420 R423 CN42 C410 C412 R473 R426 BK41 R472 R421 BK40 R403 C430 JK41 JK42 JK40 C414 R481 C400 JK43 R441 R431 R435 R432 R417 ADJ1 ADJ2 BK47 C421 R442 D402 R419...
  • Page 39 sTAN BY (COMPONENT sIDE) CUP12497Z-1 sTAN BY (FOIL sIDE) CUP12497Z-1 CONNECT CONNECT (COMPONENT sIDE) (FOIL sIDE) RF301 RF300 "CAUTION : REPLACE CUP12497Z-3 CUP12497Z-3 ONLY WITH SAME FUSE" F300 N,K T6.3A L 250V U : USA N : EUROPE K : CHINA BK71 CN34 ADJ-1...

  • Page 40: Schematic Diagrams

    sCHEMATIC DIAGRAMs MM7025 ST-BY LED PCB FRONT PCB CUP12337Z-4 CUP12337Z-1 (PWR_button key) +5VD +5VD +5VL +5VL +5VD +5VL1 Q902 Q903 Q904 Q905 Q906 R901 1K SW91 SRA2202M SRA2202M SRA2202M SRA2202M SRA2202M Q901 SRA2202M 1.PWR_BTN 1.PWR_BTN 2.ST BY_LED 2.ST BY_LED +5VL1 3.+5VL 3.+5VL +5VL...
  • Page 41 FAN & PROTECTION. PART ST-BY PART D303 1SS133M IC30 S-80842CNY-B2-U Q203 FROM KTC3964 (HEAT SINK) CN22 CPU PCB CJP02GA01ZY R300 D300 5.P_DOWN R229 2.2K 1N4003SR 4.STANDBY2 4.7(1W) 3.STANDBY1 CFNRDH8025B1 2.+5VL D301 1.GND CN34 1N4003SR CN34 CJP05GA01ZY N,K Ver. AC250V T6.3AL IC31 U Ver.
  • Page 42 JK10 R101 C103 C109 R107 MM8003/MM8077 UNBALANCED INPUT RA2 22uF/50V ROA 22uF/25V -15V C106 OPEN CN31 CN31 CJP09GA19ZY 9.SW_FL INPUT_FL TO BN11 8.SW_FR INPUT_FR +15V +15V +15V +15V 7.SW_SL INPUT_SL C107 MM8003 6.SW_SR INPUT_SR OPEN FROM BAL INPUT 5.SW_SBL INPUT_SBL +15V 4.SW_SBR...
  • Page 43 MM8003/MM8077 BALANCED INPUT +15V +15V C701 R703 C501 R503 C725 UNBAL_SBL C525 25V/22UF 25V/22UF UNBAL_FL OUT00 22uF/25V C715 R715 C719 R721 C723 R729 C515 22uF/25V R515 C519 R521 C523 R529 JK70 JK50 WIMA OPEN WIMA +15V -15V WIMA OPEN WIMA...
  • Page 44 KTC3114A KTC3114A COP12071C,G SR CH BROWN COLOR Wire Q201 Q301 +VCC KSA992FTA +VCC KSA992FTA OUT1 OUT2 Q202 Q302 MM8077 Not Used OPT. CH COP12071B,F CNT CH -VCC -VCC KSC1845FTA KSC1845FTA SBR_SGND COP12071C,G SR CH SBL_SGND COP12071B,F OPT. CH VR20 VR30...
  • Page 45 IC20 MM8077 Not used. MM8077 NJM2901N Not used. OPT. CN11 CN10 CN21 CN20 CJP03GA90ZY CJP03GA90ZY CJP03GA90ZY CJP03GA90ZY +18V R200 D200 SR_LEVEL R158 47K C115 C111 C109 C113 C107 C105 C103 C101 SBL_LEVEL 1SS133M MM8077 100P 100P 100P 100P 100P 100P...
  • Page 46 CPU PART BK40 R433 100 R434 100 D400 IC44 IC43 SIR34ST3F RPM6936 NJM2831F33 R431 1K JK40 VOUT R432 1K D401 FROM 1SS355 C408 0.1uF POWER PCB C409 100/16V 1.SPK_ON4 IC41 SPK_ON4 2.SPK_ON3 AT24C04BN-SH-B C400 SPK_ON3 3.SPK_ON2 JK43 SPK_ON2 0.1uF 4.SPK_ON1 R435 0 D403 1SS355T SPK_ON1...
  • Page 47 FROM BALANCE PCB TO 2A BN31 BN32 BN33 BN34 BN35 BN36 BN37 2.5mm 2.5mm 2.0mm 2.5mm 2.0mm 2.0mm 2.5mm CN60 CN61 CN62 CN63 CN64 CN65 CN66 CN67 CN67 CJP02GA01ZY CJP02GA01ZY CJP02GA19ZY CJP02GA01ZY CJP02GA19ZY CJP02GA19ZY CJP02GA01ZY CJP05GA01ZY TO BN70 1.+15V R647 2.GND FROM 3.-15V...

  • Page 48: Wiring Diagram

    WIRING DIAGRAM *OPTION CN41 20P CUP12070Y-2 100/120V 230/220V POWER(2mm) CN31 9P CN22 9P CN21 9P CN20 3P BN34 5P BAL(2mm) BAL(2mm) BAL(2mm) BAL(2.5mm) INPUT UNBAL PCB ST-BY(2mm) CN44 3P SIGNAL_DET. CN40 11P CUP12070Y-1 CPU PCB FRONT(2mm) (2.0mm) CUP12497Z-1 INPUT UNBAL PCB BN11 11P BN22 9P BN21 9P...

  • Page 49: Exploded View

    EXPLODED VIEW WARNING: Parts marked with this symbol have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.  印の部分は安全を維持するために重要 な部品です。従って交換時は必ず指定の 部品を使用してください。...

  • Page 50: Parts List Of Exploded View

    PARTs LIsT OF EXPLODED VIEW Ref. No. Part No. Part Name Remarks Q'ty 943402103200M FRONT PANEL(AL) CKM1A234YC23 zParts for which "nsp" is indicated on this table cannot be supplied. BODY BRACKET CMD1A668 zP.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts. H/S BRACKET CMD1A666 zPart indicated with the mark "...

  • Page 51: Packing View

    PACKING VIEW PARTs LIsT OF PACKING & ACCEssORIEs zParts for which "nsp" is indicated on this table cannot be supplied. zPart indicated with the mark " ★ " is not illustrated in the exploded view. zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions. Note: The symbols in the column "Remarks"...

  • Page 52: Semiconductors

    R8C/24 Group, R8C/25 Group 1. Overview sEMICONDUCTORs Pin Assignments Only major semiconductors are shown, general semiconductors etc. are omitted to list. The semiconductor which described a detailed drawing in a schematic diagram are omitted to list. Figure 1.4 shows PLQP0052JA-A Package Pin Assignments (Top View). Figure 1.5 shows PTLG0064JA-A Package Pin Assignments.
  • Page 53 Block Diagram Figure 1.1 shows a Block Diagram. R5F21246sNFP Block Diagram I/O ports Port P0 Port P1 Port P2 Port P3 Port P4 Port P6 Peripheral functions System clock A/D converter generation circuit × (10 bits 12 channels) Timers XIN-XOUT High-speed on-chip oscillator Timer RA (8 bits) Low-speed on-chip oscillator...
  • Page 54 Port sTBY Port spec Act. Init Port Name Ext. R Description setting setting MODE VCC/ VCC/AVCC AVCC P27/YRDIOD1 SPK_ON1 47kPD SPK1 OUT ON/OFF Control P26/TRDIOC1 SPK_ON2 47kPD NO USE P25/TRDIOB1 SPK_ON3 47kPD NO USE Protection LED ON/OFF P24/TRDIOA1 Protection LED DTrPU LED ON:L/ OFF:H Version display LED bit3(MSB)
  • Page 55 Port sTBY Port spec Act. Init Port Name Ext. R Description setting setting MODE P42/VREF VREF VREF +3.3V Emergency Protection(Power Voltage P60/TREO __P_LINE_FAIL 10kPU Ditection) L:fail detect _STANDBY1 10kPD Standby Control 1 _STANDBY2 10kPD Standby Control 2 Sensor "Power AMP Heat detection 1 P03/AN4 _HEAT_DET_1 100kPD...
  • Page 56 AT24C04BN-sH-B (IC403) Features • Low-voltage and Standard-voltage Operation – 1.8 (V = 1.8V to 5.5V) • Internally Organized 512 x 8 (4K), or 1024 x 8 (8K) • Two-wire Serial Interface • Schmitt Trigger, Filtered Inputs for Noise Suppression • Bidirectional Data Transfer Protocol •...
  • Page 57 LM94022BIMG (IC406,IC407,IC408) December 6, 2007 LM94022/LM94022Q 1.5V, SC70, Multi-Gain Analog Temperature Sensor with Class-AB Output ■ General Description Disk Drives ■ Games The LM94022 is a precision analog output CMOS integrated- ■ Appliances circuit temperature sensor that operates at a supply voltage as low as 1.5 Volts.
  • Page 58 2sC2922 Y (Q114,Q214,Q314) 2SC2922 LAPT Application : Audio and General Purpose silicon NPN Epitaxial Planar Transistor (Complement to type 2SA1216) External Dimensions MT-200 Absolute maximum ratings (Ta=25°C) Electrical Characteristics (Ta=25°C) 2SC2922 Symbol Symbol Unit Conditions 2SC2922 Unit ±0.2 36.4 ±0.3 =180V µ...
  • Page 59 2sA1216 Y (Q115,Q215,Q315) 2SA1216 Y (Q115,Q215,Q315) 2SA1216 LAPT Silicon PNP Epitaxial Planar Transistor (Complement to type 2SC2922) Application : Audio and General Purpose External Dimensions MT-200 Electrical Characteristics ■ Absolute maximum ratings ■ (Ta=25°C) (Ta=25°C) Symbol 2SA1216 Unit SymboI 2SA1216 Unit Conditions ±0.2...

  • Page 60: Parts List Of P.c.b. Unit

    PARTs LIsT OF P.C.B. UNIT zParts for which "nsp" is indicated on this table cannot be supplied. zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions. Note: The symbols in the column "Remarks" indicate the following destinations. U1B : North America model N1B : Europe model FRONT P.W.B.

  • Page 61: Amp B P.w.b. Unit Ass'y

    AMP B P.W.B. UNIT Ass'Y Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New sEMICONDUCTORs GROUP D301,302 943202000940S DIODE , ZENER ,1/2W, 16V ZJ16B/HOMI(H.K) CVDZJ16BT COMPANY LTD D303,304 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) CVD1SS133MT COMPANY LTD D305 943202000950S DIODE , ZENER ,1/2W, 4.3V ZJ4.3B/HOMI(H.K) CVDZJ4.3BT COMPANY LTD D306...
  • Page 62 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New Q401 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, CVTKSA992FTA FAILCHILD KSA992FTA HFE F(300~600) Q402,403 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, CVTKSC1845FTA FAILCHILD KSC1845FTA HFE F(300~600) Q404,405 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, CVTKSA992FTA FAILCHILD KSA992FTA HFE F(300~600) Q406 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600,...
  • Page 63 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New C406 943133000600S CAP , POLYPROPYLENE (WIMA CCMP2A332JA02T 3300PF/100VDC) FKP2 3300PF 100VDC/6WIMA C407,408 00MOA10710020 CAP, ELECT(100V/100uF), ELNA/RA2 CCEA2ARA101E C409 00MOA22605020 CAP, ELECT(ELNA/RA-2, 50V/22UF) CCEA1HRA220T C410,411 CAP, CERAMIC(500V/47pF/J) CCCT2H470JT DCT470KSL050L5JT0(H) C412 CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT C413 CAP, CERAMIC(50V/2200pF/K) CCKT1H222KB C414...
  • Page 64 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New R403,404 nsp RES, M-OXIDE FILM(2W/1.5Kohm) CRG2SANJ152RT R405 RES, CARBON(1/5W,100ohm,J) CRD20TJ101T R406 RES, CARBON(1/5W,6.8Kohm,J) CRD20TJ682T R407,408 nsp RES, CARBON(1/5W,33ohm,J) CRD20TJ330T R409 RES, CARBON(1/5W,6.8Kohm,J) CRD20TJ682T R410 RES , FLAME RETARDANT(1/4W, 470ohm) CRG14SANCJ471T CFPS 1/4 KOA R411,412 RES, CARBON(1/5W,33ohm,J) CRD20TJ330T...
  • Page 65 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New R562,563 00D9430101101 WIRE, COPPER(D0.6) CU97.8/SN2.1,D0.6 C3A206 R564 RES, CARBON(1/5W,150Kohm,J) CRD20TJ154T R565 RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T RS30 943129000820S RES , CEMENT(5W/0.1 OHM, MULTI) CRF5EKR10X2 RS40 943129000820S RES , CEMENT(5W/0.1 OHM, MULTI) CRF5EKR10X2 RS50 943129000820S RES , CEMENT(5W/0.1 OHM, MULTI) CRF5EKR10X2 OTHERS PARTS...

  • Page 66: Amp C P.w.b. Unit Ass'y

    AMP C P.W.B. UNIT Ass'Y Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New sEMICONDUCTORs GROUP D201,202 943202000940S DIODE , ZENER ,1/2W, 16V ZJ16B/HOMI(H.K) CVDZJ16BT COMPANY LTD D203,204 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) CVD1SS133MT COMPANY LTD D205 943202000950S DIODE , ZENER ,1/2W, 4.3V ZJ4.3B/HOMI(H.K) CVDZJ4.3BT COMPANY LTD D206...
  • Page 67 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New Q208 90M-HT300820R T.R , PRE DRIVE KTC3423Y HVTKTC3423Y Q209 90M-HT800120R T.R , BIAS KTC3114A HVTKTC3114A Q210 90M-HT300820R T.R , PRE DRIVE KTC3423Y HVTKTC3423Y Q211 90M-HT100540R T.R , PRE DRIVE KTA1360Y HVTKTA1360Y Q212 90M-HT300940R T.R , DRIVER SANKEN HVT2SC4883A Q213 90M-HT100690R T.R , DRIVER SANKEN...
  • Page 68 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New Q511 90M-HT100540R T.R , PRE DRIVE KTA1360Y HVTKTA1360Y Q512 90M-HT300940R T.R , DRIVER SANKEN HVT2SC4883A Q513 90M-HT100690R T.R , DRIVER SANKEN HVT2SA1859A Q514 00MHT329222B0 T.R , POWER 2SC2922YP SANKEN CVT2SC2922YP Q515 00MHT112162B0 T.R , POWER 2SA1216YP SANKEN CVT2SA1216YP Q516 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600,...
  • Page 69 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New C506 943133000600S CAP , POLYPROPYLENE (WIMA CCMP2A332JA02T 3300PF/100VDC) FKP2 3300PF 100VDC/6WIMA C507,508 00MOA10710020 CAP, ELECT(100V/100uF), ELNA/RA2 CCEA2ARA101E C509 00MOA22605020 CAP, ELECT(ELNA/RA-2, 50V/22UF) CCEA1HRA220T C510,511 CAP, CERAMIC(500V/47pF/J) CCCT2H470JT DCT470KSL050L5JT0(H) C512 CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT C513 CAP, CERAMIC(50V/2200pF/K) CCKT1H222KB C514...
  • Page 70 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New R321,322 RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT R323,324 RES , FLAME RETARDANT(1/4W, 100ohm) CRG14SANCJ101T CFPS 1/4 KOA R325 RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT R326,327 RES, M-OXIDE FILM(1W/47ohm) SSD01R1J**** CRG1SANJ470RT R328 RES, M-OXIDE FILM(1W/220ohm) CRG1SANJ221RT R329,330 RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT R331 RES, CARBON(1/5W,15Kohm,J)
  • Page 71 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New R515,516 RES, CARBON(1/5W,330Kohm,J) CRD20TJ334T R517 90M-NB000010R RES , LINEAR POSITIVE TEMP KOA HRT16C1512000JT R518 RES, CARBON(1/5W,6.8Kohm,J) CRD20TJ682T R519 RES , FRAME(1K, 1/4W, 5%) 1K, 1/4W, 5% KOA CRG14SANCJ102T R521,522 RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT R523,524 RES , FLAME RETARDANT(1/4W, 100ohm) CRG14SANCJ101T...

  • Page 72: Input P.w.b. Unit Ass'y

    INPUT P.W.B. UNIT Ass'Y Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New SEMICONDUCTORS GROUP D501-503 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) CVD1SS355T COMPANY LTD D601-603 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) CVD1SS355T COMPANY LTD D701-703 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) CVD1SS355T COMPANY LTD D801...
  • Page 73 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New C550,551 00MOA10705020 CAP, ELECT(50V/100uF) CCEA1HH101T C601,602 00MOA22602520 CAP, ELECT(RA2, 25V/22UF, 5X11) RA2- CCEA1ERA220T 25V220ME3#-T2 C603 CAP, CHIP(1608, 50V/47pF) CCUS1H470JA C605,606 00MOA22602520 CAP, ELECT(RA2, 25V/22UF, 5X11) RA2- CCEA1ERA220T 25V220ME3#-T2 C607 CAP, CHIP(1608, 50V/47pF) CCUS1H470JA C609-614 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC...
  • Page 74 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New R518 RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T R519 00MNN05512610 RES, CHIP(1608/5%/5.1Kohm) CRJ10DJ512T R520,521 RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T R522 00MNN05512610 RES, CHIP(1608/5%/5.1Kohm) CRJ10DJ512T R523 RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T R524 00MNN05512610 RES, CHIP(1608/5%/5.1Kohm) CRJ10DJ512T R525,526 RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T R527,528 00MNN05473610 RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T R529-533 00MNN05101610 RES, CHIP(1608/5%/100ohm)
  • Page 75 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New CN70 WAFER/STRAIGHT/2.5mm/5P YMH025-05R/ CJP05GA01ZY YEONHO ET10 PLATE , EARTH CNE75-V1 ET20 PLATE , EARTH CNE75-V1 JK10,11 943646000840S JACK, 1P(BK),SEPA-GND,GOLD CJJ4M056W JK20,21 943646000840S JACK, 1P(BK),SEPA-GND,GOLD CJJ4M056W JK30,31 943646000840S JACK, 1P(BK),SEPA-GND,GOLD CJJ4M056W JK40 943646000840S JACK, 1P(BK),SEPA-GND,GOLD CJJ4M056W JK50,51 00D2051254007 JACK , XLR IN JY-5033U*030...

  • Page 76: Power P.w.b. Unit Ass'y

    POWER P.W.B. UNIT Ass'Y Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New sEMICONDUCTORs GROUP D100-103 00D9430209400 DIODE , RECT 1N4003 CVD1N4003SRT D105,106 00D9430209400 DIODE , RECT 1N4003 CVD1N4003SRT D108-117 00D9430209400 DIODE , RECT 1N4003 CVD1N4003SRT D119 00D9430182609 DIODE , SWITCHING 1SS133/HOMI(HK) CVD1SS133MT COMPANY LTD D120-123...
  • Page 77 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New C201-207 CAP, CERAMIC(50V/100pF/K) CCKT1H101KB C209 00MOA10702520 CAP, ELECT(25V/100uF) 100UF 25V CCEA1EH101T C210 CAP, ELECT(50V/1uF) CCEA1HH1R0T REsIsTORs GROUP R100 RES, M-OXIDE FILM(1W/390ohm) SSD01R1J**** CRG1SANJ391RT R101 RES, M-OXIDE FILM(1W/470ohm) SSD01R1J**** CRG1SANJ471RT R102 RES, M-OXIDE FILM(1W/390ohm) SSD01R1J**** CRG1SANJ391RT R103 RES, M-OXIDE FILM(1W/470ohm) SSD01R1J****...
  • Page 78 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New ET10 PLATE , EARTH CNE75-V1 F102,103 90M-FS001070R FUSE (2.5A) KBA2D2500TLET JK20 943646000860S JACK , 2P SPEAKER(RED/BLACK) CJJ5N013Z B-201AWG-02 JK30 943646000860S JACK , 2P SPEAKER(RED/BLACK) CJJ5N013Z B-201AWG-02 JK40 943646000860S JACK , 2P SPEAKER(RED/BLACK) CJJ5N013Z B-201AWG-02 JK50 943646000860S JACK , 2P SPEAKER(RED/BLACK)

  • Page 79: Cpu P.w.b. Unit Ass'y

    CPU P.W.B. UNIT Ass'Y Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New sEMICONDUCTORs GROUP D400 90M-HI200020R INFRARED L.E.D SIR-34ST3F ROHM BVDSIR34ST3F D401-404 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) CVD1SS355T COMPANY LTD D405-407 90M-HI101040R L.E.D , RED SLR342VCTB7T089 ROHM HVD342VCTB7T089 D601,602 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) CVD1SS355T COMPANY LTD...
  • Page 80 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New C621,622 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C623,624 CAP, ELECT(50V/10uF) CCEA1HH100T C625,626 CAP, CHIP(1608, 50V/100pF) CCUS1H101JA C627,628 CAP, ELECT(50V/10uF),ELNA/RA3,6.3X11 CCEA1HRA38P100T 100MF3#8P-T2 C631,632 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC C633 CAP, ELECT(50V/10uF) CCEA1HH100T C635 CAP, CHIP(1608, 50V/100pF) CCUS1H101JA C636 CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC...
  • Page 81 Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New R635 00MNN05223610 RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T R637,638 00MNN05105610 RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T R641 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T R642 RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T R643 00MNN05102610 RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T R644 00MNN05473610 RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T R645 RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T R646,647 RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T OTHERs PARTs GROUP...

  • Page 82: Standby P.w.b. Unit Ass'y

    sTANDBY P.W.B. UNIT Ass'Y Ref.No. PartNo. PartName Remarks (ANAM) Q'ty New sEMICONDUCTORs GROUP D209 90M-HD302410R DIODE , ZENER ,1/2W, 8.2V ZJ8.2B/HOMI(H.K) CVDZJ8.2BT COMPANY LTD D210 90M-HD302380R DIODE , ZENER ,1/2W, 3.6V ZJ3.6B/HOMI(H.K) CVDZJ3.6BT COMPANY LTD D300,301 00D9430209400 DIODE , RECT 1N4003 CVD1N4003SRT D302 90M-HD302410R DIODE , ZENER ,1/2W, 8.2V ZJ8.2B/HOMI(H.K)
  • Page 83 CRQT7CJ2R2 RY30 943682000780S RELAY , 12V G4W-1112P-US-TV812VDC CSL1A017ZE RY31 00MLY10090010 RELAY SDT-S-109DMR HSL1D016ZE z T301 943101101900S TRANS , SUB MM8077/U CLT5K008ZU z T301 943101101910S TRANS , SUB MM8077/N CLT5K008ZE z T301 943101101920S TRANS , SUB MM8077/H CLT5K008ZH 943652000630S FUSE(326Series, 250V/12A) KBA2F1202TLUY 90M-FS001430R FUSE(218Series, 250V/6.3A)
