- Page 1 SR-AX107 The SARAMONIC SR-AX107 is a 2-channel XLR audio adapter with preamplifiers and phantom power, ideal for any DSLR cameras with a built-in microphone jack. COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL A brand of DSQN Web: www.saramonic.com User Manual Email: info@saramonic.com...
- Page 2 The SR-AX107 makes your recording work much easier. Level Meter allows you to verify the proper input levels in real time, the output signal can be adjusted by the level controls for optimum recording.
- Page 3 1.2 Product Structure XLR Inputs Level Meter Balanced LEFT and RIGHT XLR inputs Indicates the sound level in dB for each channel Battery Compartment Gain Switches Operates on one 9 volt battery ( not included ). Selects LOW for unity gain or HIGH for +20dB boost You could use an alkaline or lithium type battery for the longest operating type.
- Page 4 Monitor input jack For connecting AV cable to the camera Audio Output One stereo 1/8" (3.5 mm) mini-jack output Left and Right Control Knobs Adjust the signal of each channel to the optimum recording levels Volume Control knob M /S Switch Adjusts the headphone volume level Select mono or stereo output mode PHONES...
- Page 5 1.3 Product Structure Maximum Input Levels MIC 0 dB on the Level meter at -44 dBu input LINE 0 dB on the Level meter at +10 dBu input Output Level Nominal MIC levels Frequency Response 20 Hz to 20 kHz (+/- 0.5 dB) Less than 0.01% @ 1kHz, -30dBu input S/N Ratio 85 dB @ 1 Khz, -30 dBu inp...
- Page 6 Slide the drawer closed until it clicks into place. When using microphones and wireless systems, set to MIC for microphone. (2) Attach the SR-AX107 to the base of the camera. Spin counter-clockwise to tighten up the When using other audio devices, set to LINE for Line.
- Page 7 (2) Saramonic International will repair or replace the product that under the warranty for free When recording under stereo mode and set the AGC switch to off, a 20kHz sine wave will be during the one-year valid period, but customers should pay for shipping and insurance sent from left channel to the camera to turn off the AGC function.
- Page 8 Professional XLR microphones, wireless systems, other audio devices such as mixing boards. Any DSLR cameras with video making function. 5 Packing List One SR-AX107 main unit One signal transmission line AV cable User manual Warranty card COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL A brand of DSQN...
