Saramonic SmartRig II Manual

Audio Adapter
The SmartRig II from Saramonic is an easy solution
to connect professional microphones/guitars with
your iPhone, iPad, iPod touch and Android devices
User Manual
SmartRig II PRODUCT INTRODUCTION
General Introduction
The SmartRig II from Saramonic is an easy solution to
connect professional microphones/guitars with your
iPhone, iPad, iPod touch and Android devices.
As a high-quality microphone preamp, SmartRig II allows
you to use professional stage microphones or high-end
studio microphones to create music with your iOS or
Android devices.
Simply plug the microphone into the standard XLR
connector of SmartRig II and connect it to your device with
the 3.5mm output cable.
The provided gain control thumbwheel makes it easy to set
precise levels. Processed sound can be monitored through
a 3.5mm headphone out
Highlights
• Combo 1/4" (6.35mm) and XLR
• Power/Phantom power provided by 9V battery
• +48V phantom power
• 3.5mm headphone output for monitoring
• +48V/OFF/ON switch
• Gain control
• Power/Phantom power provided by 9V battery
s
.
input
Specifications
Frequency Response 20Hz to 20kHz (+/-1.5dB)
Noise -98 dB full band, phantom power ON
Maximum output level 2 Vrms
Distortion 0.025% THD
Phantom max current 13mA
Dimensions L 88 x W 41 x H 42 mm
Weight 75g ( 2.57oz. )
Product Structure
