COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL
A brand of DSQN
Web: www.saramonic.com
Email: info@saramonic.com
Audio Adapter
The SARAMONIC SR-AX101 is a 2-channel XLR audio
adapter ideal for any compact camcorder or DSLR
camera with a built-in microphone jack. It enables you
to acquire professional audio from XLR outputs into a
camcorder that has a 3.5mm (1/8") audio input.
User Manual
SR-AX101
Advertisement
Related Manuals for Saramonic SR-AX101
Summary of Contents for Saramonic SR-AX101
-
Page 1: Audio Adapter
SR-AX101 Audio Adapter The SARAMONIC SR-AX101 is a 2-channel XLR audio adapter ideal for any compact camcorder or DSLR camera with a built-in microphone jack. It enables you to acquire professional audio from XLR outputs into a camcorder that has a 3.5mm (1/8") audio input. -
Page 2: Product Introduction
The SR-AX101 is simple to set up and use. With the trim control knobs for each channel, you can adjust the recording levels. It’s a compact and economical way to add excellent audio to your camcorder. - Page 3 LINE/MIC LINE/MIC Switches Switches Mono/Stereo Switch GND1/GND2 Ground Switch Balanced Stereo Output XLR Inputs Auxiliary Mini-Jack Input...
- Page 4 1.3 Highlights 1.3.5 LINE / MIC Switches ※ Select LINE or MIC levels 1.3.1 Inputs The MIC level is for microphones or wireless system. ※ One 1/8" (3.5 mm) Auxiliary Mini-Jack Input The LINE level is for mixers and other audio devices with a line level output. ※...
- Page 5 2 Quick Start Guide g) In case of any distortion, you should initially set the LEFT and RIGHT trim a) Attach the SR-AX101 to the base of the camera. Spin counter-clockwise to controls fully clockwise. When test recording, you could adjust the knobs tighten up the adapter with the camera.
- Page 6 3.5 Wherever you purchased our products, you will be served very well at local retailer. 3.2 Saramonic International will repair or replace the product that under the warranty for free during the one-year valid period, but customers should 3.6 Saramonic International reserves all the rights for the ultimate pay for shipping and insurance charges for returning the product to interpretation.
