Saramonic SR-AX100 User Manual

Audio Adapter

The SR-AX100 is a 2-channel audio adapter for shooting
videos with any DSLR camera or camcorder. It provides a
compact dual-mic mounting and audio mixing solution.
User Manual
1.2.4 Mono /Stereo Switch
• select mono or stereo output mode.
The Mono mode is for one mono microphone recording, it could send
the mono audio signal to each channel and mix them together to output
stereo audio signal.
The Stereo mode is for one stereo microphone or two mono microphones
recording, it provide two separate channels of audio.
1.2.5 Three Integrated Mounting Shoes
• Attach a variety of mics or wireless receivers.
1.2.6 Passive Operation Requires No Batteries
1.2.7 Compact Shaped With Die-cast Aluminum Chassis
SR-AX100
1 Product Introduction
1.1 General Introduction
The SARAMONIC SR-AX100 is a 2-channel audio adapter ideal for shooting
videos with any DSLR camera or camcorder. This adapter provides you
with a compact dual-mic mounting and audio mixing solution, which
allows you to easily mount and control two mics or wireless receivers. It
requires no batteries or power source.
1.2 Highlights
1.2.1 Inputs
• One stereo 1/8" (3.5 mm) Mini-Jack Input to connect stereo mic.
• Two mono 1/8" (3.5 mm) Mini-Jack Inputs to connect mono mics.
1.2.2 Output
• One stereo 1/8" (3.5 mm) Mini-Jack outputs audio signal from the
adapter to the camera.
1.2.3 Dual Trim Control Knobs
• Adjust the signal of each channel to the optimum recording levels.
1.3 Specifications
Input Level
Gain
Frequency Response
Dimensions
Weight
MIC setting: -35 dBu minimum
Unity
20 Hz to 20 kHz (+/- 0.5 dB)
L 76.0 x W 59.5 x H 55.0 mm
153g ( 5.4 oz. )
