Qualcast
46cm Petrol Hand Push
Lawnmower
Assembly Manual
Important
- Please read these instructions fully before starting assembly
These instructions contain important information that will help you get the best from
your lawnmower, ensuring it is assembled correctly and safely.
If you need help or have damaged or missing parts, call the Customer Helpline on 0845 034 2279
prior to returning product to store.
Scan to watch
our new quick
start videos!
Complete Product Support &
Aftersales Service 7 days a week.
Do you need help with this product?
Instead of returning your product please
call 0845 034 2279 7 days a week.
Email: support@gardenservicecentre.co.uk
Or visit www.gardenservicecentre.co.uk
This does not affect your statutory rights.
XSS46B
Sep 2012 Rev A
Advertisement
Table of Contents
Related Manuals for Qualcast XSS46B
Summary of Contents for Qualcast XSS46B
- Page 1 Qualcast 46cm Petrol Hand Push Lawnmower Assembly Manual XSS46B Scan to watch our new quick start videos! Complete Product Support & Aftersales Service 7 days a week. Do you need help with this product? Instead of returning your product please call 0845 034 2279 7 days a week.
- Page 2 Contents Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols Safety Information .............................3 Warning Symbols ............................3 The following warning symbols appear throughout this assembly manual and indicate the appropriate safety measures you should take when assembly and operating the lawnmower. General Safety ..............................3 This symbol indicates there is a danger of serious personal injury or death if you do not observe the Personal Safety ............................3...
- Page 3 In the Box Assembly Tools Parts Preparing to assemble the lawnmower WARNING! Always take care when removing the packaging to prevent damage to you or to the Main mower deck Grass collecting Spanner & philips Lower handle fixing (with upper handle lawnmower.
- Page 4 Assembly Assembly Step 2 Step 4 2a Lift the upper handle, align it with the lower handle, making sure the cables are not twisted, and 4. Ensure that the cable clips supplied are used to fix the cable to the Lower Handle. fasten the two handles together by using the bolts and handle tension knobs included in box.
- Page 5 Qualcast 46cm Petrol Hand Push Lawnmower Operation and Maintenance Manual XSS46B Scan to watch our new quick start videos! Complete Product Support & Aftersales Service 7 days a week. Do you need help with this product? Instead of returning your product please call 0845 034 2279 7 days a week.
-
Page 6: Table Of Contents
Contents Safety Information Important - Please read these instructions fully before operating or maintaining Warnings Symbols Safety Information .............................3 Warning Symbols ............................3 The following warning symbols appear throughout this manual and indicate the appropriate safety measures you should take when operating and maintaining the lawnmower. General Safety ..............................4 Preparation ..............................4 Read instruction handbook before operating this machine. -
Page 7: Safety Information
Safety Information Safety Information Important - Please read these instructions fully before operating or maintaining Important - Please read these instructions fully before operating or maintaining General Safety Operation WARNING! Keep this operating and maintenance manual in a safe place for reference at a later a) Do not operate the engine in a confined space where dangerous carbon monoxide fumes can date. -
Page 8: Maintenance And Storage
Safety Information Preparing to Operate the Lawnmower Important - Please read these instructions fully before operating or maintaining Step 1 - Filling with Engine Oil Maintenance and Storage a) Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition; b) Never store the equipment with petrol in the tank inside a building where fumes can reach an open flame or spark;... -
Page 9: Step 2 - Filling With Engine Fuel
Preparing to Operate the Lawnmower Operating the Lawnmower Step 2 - Filling with Engine Fuel Step 1 - Setting the Cutting Height CAUTION! Always use clean, fresh unleaded petrol. Purchase fuel in quantities that can be used within 30 days. Never mix oil with petrol. CAUTION! Do not fill into the base of neck to allow for fuel expansion. -
Page 10: Step 3 - Mowing
Operating the Lawnmower Operating the Lawnmower Step 2 - Starting the Engine (continued) Step 3 - Mowing WARNING! Always observe the strictest safety procedures when using the lawnmower. Carefully read the safety instructions of this manual before using the lawnmower. Start the engine and allow it run .See ”Step-2 Starting the engine”... -
Page 11: Step 4 - Emptying The Grass Bag
Operating the Lawnmower How to Replace the Blade Step 4 - Emptying the Grass Bag Replacing the Blade WARNING! Before you remove the grass collection bag, stop the engine and wait until the blade stops completely. WARNING! Always empty the grass bag when you have finished the mowing, even if it is not full. Stored grass residues are a fire hazard. -
Page 12: Storing The Lawnmower
Storing the Lawnmower Maintenance Step 1 - Storing the Lawnmower for Short Periods Maintenance Schedule The lawnmower can be stored for short periods of time (less than 15 days) without performing Performing routine maintenance correctly on your lawnmower will ensure you get years of trouble any storage maintenance. -
Page 13: Step 4 - Changing The Oil
Maintenance Maintenance Step 1 - Cleaning (continued) Step 3 - Cleaning or Replacing Air Filter 1a The lawn mower should be thoroughly cleaned after every use, especially the underneath and the blade mount. To do so, tip the lawn mower onto its left side (the opposite side to the oil filling socket). Dirt and grass is easiest to remove immediately after you have finished mowing the grass. -
Page 14: Troubleshooting
Troubleshooting Technical Data General Troubleshooting Technical Data Table CAUTION! Always switch off the engine and pull the ignition cable before starting any inspection Property Value or adjustment work. Engine type Single cylinder 4-stroke Engine displacement 148cc CAUTION! If, after making an adjustment or repair to the engine, you let it run for a few minutes, remember that the exhaust and other parts will get hot. -
Page 15: Guarantee
Please note that our devices have not been designed for use in commercial, trade or industrial Type of Product: Petrol lawnmower Model Number: XSS46B applications. Consequently, the guarantee is invalidated if the equipment is used in commercial, Cat / Article Number :7071214 trade or industrial applications or for other equivalent activities.
