Qualcast
46cm Petrol Self Propelled
Roller Lawnmower
Assembly Manual
Important
- Please read these instructions fully before starting assembly
These instructions contain important information that will help you get the best from your
lawnmower, ensuring it is assembled correctly and safely.
XSZ46R
Technical Support & Parts
0845 034 2279
www.gardenservicecentre.co.uk
Scan to watch
our instruction
videos!
Oct 2013 Rev A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XSZ46R and is the answer not in the manual?

Questions and answers

Related Manuals for Qualcast XSZ46R

Summary of Contents for Qualcast XSZ46R

  • Page 1 Qualcast 46cm Petrol Self Propelled Roller Lawnmower Assembly Manual XSZ46R Technical Support & Parts 0845 034 2279 www.gardenservicecentre.co.uk Scan to watch our instruction videos! Important - Please read these instructions fully before starting assembly These instructions contain important information that will help you get the best from your lawnmower, ensuring it is assembled correctly and safely.
  • Page 2 Contents Safety Information Important - Please read these instructions fully before starting assembly Warning Symbols Safety Information .............................3 Warning Symbols ............................3 The following warning symbols appear throughout this assembly manual and indicate the appropriate safety measures you should take when assembly and operating the lawnmower. General Safety ..............................3 This symbol indicates there is a danger of serious personal injury or death if you do not observe the Personal Safety ............................3...
  • Page 3 In the Box Assembly Tools Parts Preparing to assemble the lawnmower Main mower deck Lower handle Rope guide 1pc Socket spanner for (with upper handle) (attached to the spark plug 1pc WARNING! Lower handle fixing lower handle) Grass collecting knob with nut M8 - Always take care when removing the packaging to prevent damage to you or to the lawnmower.
  • Page 4 Assembly Assembly Step 3 Step 5 Lift the upper handle, and lock in place using the quick release lever and tensioning bolts that are Ensure that the cables clips supplied are used to fix the cable to the lower handle attached to the handle.
  • Page 5 Qualcast 46cm Petrol Self Propelled Roller Lawnmower Operation and Maintenance Manual XSZ46R Technical Support & Parts 0845 034 2279 www.gardenservicecentre.co.uk Scan to watch our instruction videos! Important - Please read these instructions fully before starting assembly These instructions contain important information that will help you get the best from your lawnmower, ensuring it is assembled correctly and safely.

  • Page 6: Table Of Contents

    Replacing Cutting Blade ..........................16 Do not run the engine in closed or poorly ventilated areas. List of Consumable Qualcast Parts ......................17 Troubleshooting ..............................18 Blade continues to rotate for a period after the machine is switched off. Do not touch the blade until all the machine components have been stopped completely.

  • Page 7: Safety Information

    Safety Information Safety Information Important - Please read these instructions fully before operating or maintaining Important - Please read these instructions fully before operating or maintaining General Safety Operation Safety WARNING! WARNING! - Keep this operating and maintenance manual in a safe place for reference at a later date. - Do not operate the engine in a confined space where dangerous carbon monoxide fumes can collect.

  • Page 8: Maintenance And Storage Safety

    Safety Information Preparing to Operate the Lawnmower Important - Please read these instructions fully before operating or maintaining Step 1 - Filling with Engine Oil Maintenance and Storage IMPORTANT! - The following procedures and adjustments must be performed before the engine is started. Do not WARNING! attempt to make any of these adjustments while the engine is running.

  • Page 9: Step 2 - Filling With Engine Fuel

    NOTE! Never use the lowest cutting height for the first cut of the season or in drought conditions. NOTE! The Qualcast 46cm Self Drive Roller Lawnmower has a maximum fuel capacity of 750ml. Only about one thirds of the grass height should be cut.

  • Page 10: Step 3 - Mowing

    Operating the Lawnmower Operating the Lawnmower Step 2 - Starting the Engine (continued) Failure to start If the engine won’t start after you have operated the starter several times, the engine may be flooded with excess fuel. Use following procedure to clear and start a flooded engine: A.

  • Page 11: Step 4 - Emptying The Grass Bag

    Operating the Lawnmower Maintenance Step 4 - Emptying the Grass Bag Storing the Lawnmower for Short Periods After mowing please follow the below actions prior to placing the lawnmower in storage. WARNING! • Allow the engine to fully cool. - Do not remove grass debris in the mower casing or on the blade by hand or with your feet. •...

  • Page 12: Maintenance Schedule

    Maintenance Maintenance Cleaning or Replacing Air Filter Maintenance Schedule WARNING! WARNING! Never run the engine without the air filter element installed. - Before you tip the lawn mower onto its side, completely empty the fuel tank using a petrol suction pump. - Never turn the mower upside down.

  • Page 13: Changing The Oil

    Spare blades and other parts can be purchased in store or via www.gardenservicecentre.co.uk - Always handle the blade with care- sharp edges could cause injury USE GLOVES. List of Consumable Qualcast Parts - Don’t hold the blade by hand directly.

  • Page 14: Troubleshooting

    Troubleshooting Technical Data General Troubleshooting Technical Data Table Property Value Engine type Single cylinder 4-stroke WARNING! Engine displacement 125cc - Always switch off the engine and pull the ignition cable before starting any inspection or Engine max. power 1.92kW/3600rpm adjustment work. Engine speed 3000rpm - If, after making an adjustment or repair to the engine, you let it run for a few minutes, remember...

  • Page 15: Guarantee

    2. Our guarantee covers problems caused by material or manufacturing defects, and will result in the repair of these defects or replacement of the device with a like for like or similar article. Model Number:XSZ46R Type of Product:Petrol lawn mower...
