Liquiline M OM42
Two-wire transmitter for Ex and non-Ex areas
Analog sensors: pH/ORP / Conductivity / Concentration / Resistivity
Digital sensors: pH/ORP / Oxygen / Conductivity
Application
Liquiline M OM42 is a modular two-wire transmitter for all
areas of process engineering.
andDepending on the ordered version, Liquiline has one or two
analog current outputs or it can be connected to field buses as
per FOUNDATION Fieldbus, PROFIBUS PA and Hart protocol
The extremely robust, corrosion-resistant plastic version and
the hygienic stainless steel version are designed for the
following applications:
• Chemical processes
• Pharmaceuticals industry
• Foodstuff technology
• Applications in hazardous locations
TIIA3C/01/en
Your benefits
• Cost-saving:
– Simple commissioning with Quick Setup
Navigator (multifunction button)
– Thanks to Memosens technology, a calibration in
the plant is not required.
– Predictive maintenance system detects when a
sensor has to be cleaned, calibrated or replaced
– Less storage thanks to modular design
• Safe:
– Active display of cable interruption with Memosens
Version
– User-guided commissioning, graphic display and
plain text guidance
– Approvals: ATEX, FM, CSA, NEPSI
– Code-protected commissioning and calibration
• Industry solutions:
– Modular concept: sensor module replaceable
– Asset management (Fieldcare, W@M)
