Clarion MAX678RVD Owner's Manual & Installation Manual
  1. Manuals
  2. Brands
  3. Clarion Manuals
  4. Car Video System
  5. MAX678RVD
  6. Owner's manual & installation manual
Clarion MAX678RVD Owner's Manual & Installation Manual

Clarion MAX678RVD Owner's Manual & Installation Manual

2-din dvd multimedia station with cenet & 7-inch touch panel control
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's manual & Installation manual
Mode d'emploi et manuel d'installation
Benutzerhandbuch & Installationshandbuch
Manuale dell'utente e manuale di installazione
Gebruikershandleiding en installatiehandleiding
Manual de instrucciones y de instalación
Ägar- & installationshandbok
Manual do utilizador e manual de instalação
Betjeningsvejledning og installationsvejledning
MAX678RVD
2-DIN DVD MULTIMEDIA STATION WITH CeNET &
7-inch TOUCH PANEL CONTROL
STATION MULTIMEDIA DVD 2 DIN AVEC COMMANDE PAR
ECRAN TACTILE 7 pouces & CeNET
2-DIN DVD-MULTIMEDIA-STATION MIT CeNET und
7-Zoll-TOUCHSCREEN-STEUERUNG
STAZIONE MULTIMEDIALE DVD A 2 DIN DOTATA DI CeNET E
PANNELLO DI CONTROLLO A SFIORAMENTO DA 7 POLLICI
2-DIN DVD MULTIMEDIA STATION MET CeNET &
7-inch TOUCH PANEL BEDIENING
EQUIPO DVD MULTIMEDIA 2-DIN CON CeNET y
PANEL DE CONTROL TÁCTIL DE 7 pulgadas
2-DIN DVD MULTIMEDIA-STATION MED CeNET &
7-tums PEKSKÄRM
ESTAÇÃO MULTIMÉDIA DE DVD 2 DIN COM CeNET E
CONTROLO DE PAINEL DIGITAL DE 7 polegadas
2-DIN DVD MULTIMEDIESTATION MED CeNET og
7" BERØRINGSPANEL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAX678RVD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clarion MAX678RVD

Summary of Contents for Clarion MAX678RVD

  • Page 1: Controls

    Manual de instrucciones y de instalación Ägar- & installationshandbok Manual do utilizador e manual de instalação Betjeningsvejledning og installationsvejledning MAX678RVD 2-DIN DVD MULTIMEDIA STATION WITH CeNET & 7-inch TOUCH PANEL CONTROL STATION MULTIMEDIA DVD 2 DIN AVEC COMMANDE PAR ECRAN TACTILE 7 pouces & CeNET...

  • Page 2: Names Of Buttons

    OBS! Apparaten innehåller laserkomponenten som avger laserstrålning överstigande gränsen för laserklass 1. VAROITUS Suojakoteloa si saa avata. Laite sisältää laserdiodin, joka lähettää näkymätöntä silmille vaarallista lasersäteilyä. MAX678RVD...

  • Page 3: Table Of Contents

    ∗In addition to the above conditions, the system check function can be performed from the GENERAL menu in the ADJUST mode. •You can change the media sources. MAX678RVD Contents 1. FEATURES ... 4 Expanding Systems... 4 2. CONTROLS ... 5 Names of Buttons... 6 3.
  • Page 4 • Keep pressing this button more than 1 second [SRC] button • Press this button to display the Source menu to mute the sound in the DVD PLAYER/iPod/ screen to switch the mode. changer modes. • Press this button to mute the sound in the [+], [–] buttons...

  • Page 5: Outline Of Button And Touchkey Operation

    (Preset List screen) •Selects desired station. (Option Menu) (PTY Preset List screen) (PTY Item List screen) Note: ∗ 1:These images indicate the buttons to press or keys to touch. ∗ 2:External equipment not connected with CeNET is not displayed. MAX678RVD...
  • Page 6 ∗Screen during DVD mode when motorcar moving. Note: ∗ 3:When displaying movies in DVD video mode, touching the screen surface will cause the DVD PLAYER mode screen to be displayed. MAX678RVD ∗3 (DVD PLAYER mode screen) (Option menu) (DVD SETUP menu)

  • Page 7: Features

    Outline of Button and Touchkey Operation Adjusting audio feature settings ●When no surround decoder is connected (ADJUST mode menu) (AUDIO menu) (BAL/FAD screen) (AUDIO EXT. menu) (BAL/FAD) MAX678RVD...
  • Page 8 Outline of Button and Touchkey Operation ●When the 5.1 ch Surround Decoder is connected (ADJUST mode menu) (AUDIO menu) (STATUS screen) MAX678RVD (AUDIO EXT. menu) (STATUS) (SPEAKER SEL menu) (SPEAKER SEL)
  • Page 9 Adjusting the other system settings (ADJUST mode menu) (MONITOR menu) (MONITOR ADJ) (Monitor Adjust screen) Bright Color ∗Switched by touching this key repeatedly. (“Hue” is not displayed when displaying PAL images.) (GENERAL menu) (WALL COLOR) (WALL COLOR screen) Dimmer MAX678RVD...

  • Page 10: Inserting The Batteries

    • Do not short-circuit, disassemble or heat batteries. • Do not dispose of batteries into fire or flames. • Dispose of spent batteries properly. MAX678RVD Signal transmitter Operating range: 30˚ in all directions [ MUTE ] [ VOLUME ] [ P.TIME ]...

  • Page 11: Functions Of Remote Control Unit Buttons

    Functions of Remote Control Unit Buttons You can use the remote control unit to control the MAX678RVD. When the 2-ZONE function is ON, the controls work upon the selected zone. Note: • The steering wheel remote control operations work upon the MAIN zone even when the SUB zone is selected.

  • Page 12: Ipod Mode

    CD modes. [SUB TITLE] button • Press to display subtitles in the DVD video mode. MAX678RVD [ANGLE] button • Press to switch the ANGLE function in the DVD video mode when the Angle mark is displayed. (This button is available only on multiple angles DVDs and when the ANGLE function in the SET UP menu is set to ON.)
  • Page 13 • Controls sound volume for MAIN zone source. [MUTE] button • Controls audio mute function for MAIN zone source. [TA] button Not supported. CD changer mode • This mode is disabled when MAIN zone is set to an external equipment other than the CD changer. MAX678RVD...

  • Page 14: Cautions On Handling

    The surface is easily scratched, so do not rub it with hard objects. MAX678RVD • The remote control unit may not work if the remote control sensor is exposed to direct sunlight.

  • Page 15: Handling Discs

    If you try to play such a disc, you may not be able to get it back out of the DVD player or it may damage the DVD player. • Do not use discs that have large scratches, are misshapen, cracked, etc.

  • Page 16: Dolby Digital

    • The number of recorded subtitle languages are indicated by the icon shown below. MAX678RVD Multi-story function When a DVD video contains more than one story for a film, you can select the story you wish to enjoy.

  • Page 17: Dvd Video System

    Digital Theater Systems, Inc. • “iPod” is for legal or rightholder-authorized copying only. Do not steal music. • Windows Media™, and the Windows trademarks, or registered trademarks of Microsoft Corporation in the United States and/ or other countries. ® logo are MAX678RVD...

  • Page 18: Operations

    1. When in the TUNER, VISUAL, TV or DAB mode, press the [p] button to turn the mute on and off. When in the DVD PLAYER, iPod or changer mode, keep pressing the [p] button more than 1 second to turn the mute on and off.

  • Page 19: Adjusting The Audio

    3-2. Touch the [[] or []] key to adjust to the balance level. • The factory default setting is “0”. (Adjustment range: left 13 to right 13) [[]: Emphasises the sound from the left speakers. []]: Emphasises the sound from the right speakers. MAX678RVD...

  • Page 20: Adjusting The Monitor

    GAIN: –6 to 6 (The factory default setting is “0”.) FREQ.: 8kHz, 12kHz (The factory default setting is “12kHz”.) MAX678RVD Adjusting the non fader output volume You can adjust the volume output from the unit’s non fader output terminal. 2-1. Touch the [[] or []] key of the NON FADER VOL item to adjust to desirable level.
  • Page 21 “PAL”). Changing the colour of the background picture 2-1. Touch the []] key of the WALL COLOR item to display the WALL COLOR screen. 2-2. Touch the desired Colour you wish to set (The factory default setting is “CYAN”). MAX678RVD...

  • Page 22: Adjusting The General

    * In the following sections, only the details regarding adjustments are described, procedures to select items are skipped. MAX678RVD Setting the BEEP The sound heard when you make operations is called “beep”. The unit can be set up so that it does not produce this beep sound.
  • Page 23 Make the following settings when an external device is connected to the Visual terminal. Note: • This function is not available when the Clarion navigation system (NAX963HD) is connected. • When the navigation system is connected, use the monitor lock function. Locking the monitor locks the screen size in F.WIDE mode (full wide), and...
  • Page 24 Basic Operations Setting the anti-theft function (CATS) “CATS” is the acronym of “Clarion Anti-Theft System”. When you set a PIN code (called as “Personal Code”), a theft is prevented by disabling the operation of the unit at the theft. In addition, set the BLINK LED function in the GENERAL menu to [ON] to improve the effect of the CATS function (see page 26).

  • Page 25: Zone Function

    You can control the operation modes for the SUB zone. 4. Press the [SRC] button, and touch the [MAIN] key to return to the MAIN zone. 5. To turn the 2-ZONE function off, touch the [2 ZONE] key on the Source menu. MAX678RVD...
  • Page 26 Note: • The steering wheel remote control operations work upon the MAIN zone even when the SUB zone is selected. MAX678RVD Front monitor lock OFF Visual Visual...

  • Page 27: Listening To The Radio

    3. Tune into a station. Quick tuning: Touch and hold the [X] or [x] key for more than 1 second to tune in a station. Step tuning: Touch the [X] or [x] key to manually tune in a station. MAX678RVD...

  • Page 28: Manual Memory

    2 seconds will store the current station to the preset memory. 3. Touch the [List] key to return to the previous screen. MAX678RVD Manual memory 1. Touch the [Band] key to select the desired band. (FM or AM (MW/LW)) 2.

  • Page 29: Radio Data System Operations

    BBC R2 is being received. • The REG function ON/OFF setting is enabled only when the AF function is ON. 1. Touch the [ON] or [OFF] key of the REG item to turn the function on or off. MAX678RVD...

  • Page 30: Rds Operations

    1. When “TP” is not displayed, press the [TA] button. “TA” is displayed on the screen, and this unit automatically searches for a TP station. MAX678RVD Note: • If no TP station is received, this unit continues the search operation. Pressing the [TA] button again makes the “TA”...
  • Page 31 Science Varied Pop Music Rock Music Easy Listening Music Light Classical Music Serious Classical Music Other Music Weather Finance Children’s Programmes Social Affairs Religion Phone In Travel Leisure Jazz Music Country Music National Music Oldies Music Folk Music Documentary MAX678RVD...

  • Page 32: Displaying Radio Text

    4. Touch the [Back] key to return to the previous screen. MAX678RVD Volume setting of TA, emergency broadcast (ALARM) and PTY The volume for TA, ALARM and PTY interrupts can be set during TA, ALARM or PTY interrupt.

  • Page 33: Dvd Video Player Operations

    Selecting the DVD SETUP menu 1. Press the [SRC] button, and touch the [DVD PLAYER] key. The DVD PLAYER mode screen is displayed. 2. Touch the [Option] key to display the Option menu. 3. Touch the [Setup] key to display the DVD SETUP menu.

  • Page 34: Dvd Video Player Operations

    • When a disc with view restrictions is inserted, you will be prompted to input a password. The disc will not be viewable until the correct password is entered. MAX678RVD Setting up the country code Set up the country number for setting up of the parental level.
  • Page 35 6569 7166 • The contents that the parental level restricts 8665 vary with the country code. 8969 8985 7079 7173 7176 8374 NC-17 (NO ONE 17 AND UNDER ADMITTED) (RESTRICTED) PG-13 (PARENTS STRONGLY CAUTIONED) (PARENTAL GUIDANCE SUGGESTED) (GENERAL AUDIENCES) MAX678RVD...

  • Page 36: Ejecting A Disc

    Note: • For your safety, the MAX678RVD has a safety function which turns off the picture when the car is moving, so only the audio can be heard. The picture can only be watched when the car is stopped and the parking brake is applied.

  • Page 37: Operating The Dvd Menu

    Showing the DVD PLAYER mode screen The DVD PLAYER mode screen is used to control the playback mode from the screen. 1. Touch the screen. The DVD PLAYER mode screen is displayed.

  • Page 38: Stopping Playback

    When this button is pressed again within about 3 seconds, playback starts from the beginning of the previous chapter. • The unit may return to the DVD PLAYER mode screen when the [F] or [R] button is pressed. Fast forward and fast backward 1.

  • Page 39: Using The Title Menu

    3. Perform the same operation to turn off the repeat playback. TOP function The TOP function resets the DVD player to the first chapter of the current title. 1. Press the [BAND] button to play back the first chapter (chapter No. 1).

  • Page 40: Switching Angles

    On discs in which two or more audios or audio languages have been recorded, you can switch among the audio languages during playback. 1. Showing the DVD PLAYER mode screen, touch the [Option] key. 2. Touch the [Audio] key during playback.

  • Page 41: Watching A Video Cd

    1 second, and then 20-time faster 3 seconds later. Releasing the button resumes the normal speed playback. • The unit may return to the menu screen when the button is pressed. * No audio is reproduced during fast forward and fast backward operation. MAX678RVD Track Playback direction...

  • Page 42: Listening To A Cd

    2 seconds, playback starts from the beginning of the previous track. TOP function The TOP function resets the DVD player to the first track of the disc. 1. Press the [BAND] button to play back the first track (track No. 1).

  • Page 43: Fast Forward And Fast Backward

    4. Touch the [Back] key to return to the previous screen. Displaying CD titles This unit can display title data for CD-text CDs. 1. Touch the [Title] key. 2. Touch the [X] key of the Disc, Artist, or Track item to cause the respective display to scroll once. MAX678RVD...
  • Page 44 Playing files with a format not supported will be skipped, and the scan, random and repeat playback mode may be cancelled. MAX678RVD ●Logical format (File system) 1. When writing an MP3/WMA file on a disc, please select “ISO9660 level 1 or level 2 (without including expansion format)”...

  • Page 45: Pausing Playback

    2. Input the number for the track or folder that you want to play back with [0] to [9] key. 3. Touch the [ENT] key. When you select the folder number, playback starts from track 1 of the input folder number. 4. Touch the [Back] key. MAX678RVD...
  • Page 46 4. Touch the [Back] key to return to the previous screen. Displaying CD titles 1. Touch the [Title] key. 2. Touch the [X] key of the Folder, Track, Album, Artist or Title item to cause the respective display to scroll once. MAX678RVD...

  • Page 47: Other Functions

    A title of a channel stored for the presets 1 to 6 or a channel number is displayed. 3. Touch the desired title key (1 to 6) to select. The selected broadcast station or disc is played. 4. Touch the [Back] key to return to the previous screen. MAX678RVD...

  • Page 48: Other Functions

    • The factory default setting is “[F.WIDE]”. Note: • This function is not available while you are driving. • Switch to the DVD PLAYER (DVD video or video CD)/VISUAL/TV mode you see. 1. Touch the screen to display the mode menu, then touch “Display size”...

  • Page 49: Accessories

    In this condition, the iPod cannot be played even if attached to the MAX678RVD. Also, the MAX678RVD’s recharging function cannot be used to recharge the iPod. As a result, when the iPod’s battery...
  • Page 50 ●Option menu screen operation keys List keys Play mode menu List keys Audio Books menu MAX678RVD Play mode menu • Uses to switch the shuffle mode and repeat mode. List keys • Displays the corresponding list screen. [Podcasts], [Artists], [Albums], [Genres], [Playlists], [Audio Books], [Composers] and [Songs] are available.
  • Page 51 Note: • “AUDIO ONLY” is displayed when the motorcar is moving. • Image data may not be played back according to the status of the iPod. MAX678RVD...

  • Page 52: Visual Operations

    Switching to the VISUAL mode Note: • For your safety, the MAX678RVD has a safety function which turns off the picture when the car is moving, so only the audio can be heard. The picture can only be watched when the car is stopped and the parking brake is applied.
  • Page 53 The disc random play selects and plays individual tracks or discs automatically in no particular order. 3. To cancel the play, touch the key of the function to cancel. 4. Touch the [Back] key to return to the previous screen. MAX678RVD...

  • Page 54: Manual Tuning

    Watching TV Note: • For your safety, the MAX678RVD has a safety function which turns off the picture when the car is moving, so only the audio can be heard. The picture can only be watched when the car is stopped and the parking brake is applied.

  • Page 55: Setting The Tv Diver

    2. Touch the [TV AREA] key to display a list of country name. 3. Touch the [c] or [C] key to scroll the list. 4. Touch the desired Country Name key to select a country. 5. Touch the [Back] key to return to the previous mode. MAX678RVD...

  • Page 56: Service Scan

    M1, M2 and M3) can be preset in the Preset keys. 3. Press the [R] or [F] button to recall the stored programme. MAX678RVD Seek tuning 1. Press the [BAND] button or touch the [Band] key to select the desired band (M1, M2 or M3).
  • Page 57 1. To call the DLS stored in the DLS memory, touch the desired preset [1] to [6] key. The DLS data in the DLS memory is displayed up to 128 characters. 2. To cancel the DLS mode and return to the previous display, touch the [Back] key. MAX678RVD...

  • Page 58: Navi Operations (Nax973Hd/Nax963Hd, Etc.)

    Note: • Hereafter in this section, the Navigation system will be called as “NAVI”. • When the Clarion NAVI NAX963HD is connected, the following functions are available: • Showing the NAVI display • Operation by using the panel side buttons •...

  • Page 59: Connecting Other Company's Image Equipment

    It is possible to change between the AV display and the external equipment display using the [MAP] button. 1. To switch from the AV screen to the NAVI screen, press the [MAP] button. 2. To return to the AV screen, press the [MAP] button again. MAX678RVD...

  • Page 60: Ch Surround Decoder Operations

    * In the following sections, only the details regarding settings are described, procedures to select setting items are skipped. MAX678RVD ●SPEAKER SEL (speaker selection) This function determines centre speaker, surround speaker and subwoofer connection. 3-1. Touch the []] key of the SPEAKER SEL item to show the submenu.

  • Page 61: Ch Surround Decoder Operations

    This function sets the dynamic range compression. 3-1. Touch the [C] key to display the next menu screen. 3-2. Touch the [MAX], [STD] or [MIN] key of the DRC item to select respective item. The default value is “MAX”. MAX678RVD...
  • Page 62 Note: • If the P.EQ effect is set to OFF, the adjustment made in “P.EQ” is not reflected in the music source. MAX678RVD Setting and storing P.EQ Properties 1. Press the [ADJ] button, and touch the [AUDIO] key. 2. Touch the []] key of the P.EQ item to display the submenu.
  • Page 63 3-2. Touch the [[] or []] key to adjust the balance level. [[] key: Emphasises the sound from the left speakers. []] key: Emphasises the sound from the right speakers. Touch the [Back] key to return to the previous screen. MAX678RVD...

  • Page 64: Troubleshooting

    Disc cannot play with The view is limited. the display “PARENTAL VIOLATION” shown. MAX678RVD Cause Replace with a fuse of the same amperage. If the fuse blows again, consult your store of purchase. Consult your store of purchase. Turn off the power and open the operation panel.
  • Page 65 This is not a failure, but a phenomenon peculiar to a liquid crystal panel (The liquid crystal panel is produced according to technology with very high precision. Note that, though there are effective pixels of 99.99% or more, pixel missing or normally lit pixels account for 0.01%). Measure MAX678RVD...

  • Page 66: Error Displays

    If an error display other than the ones described above appears, press the Reset button. If the problem persists, turn off the power and consult your store of purchase. * When the Reset button is pressed, titles, etc. stored in memory are cleared. MAX678RVD Cause This is a failure of DVD deck’s mechanism and consult your store of purchase.

  • Page 67: Specifications

    178 mm Note: • Specifications comply with JEITA Standards. • Specifications and design are subject to change without notice for further improvement. 82.3 mm Height 3 (RGB) 234) 100 mm Height 160 mm 28.8 mm Height 155 mm 100 mm MAX678RVD...

  • Page 68: Installation And Wire Connection Manual

    3. GENERAL CAUTIONS 1. Do not open the case. There are no user- serviceable parts inside. If you drop anything into the unit during installation, consult your dealer or an authorized Clarion service centre. MAX678RVD 6 Bag for accessories (No. 2)

  • Page 69: Cautions On Installation

    When the fan motor vent is covered with leads or mounting bracket, it may cause a malfunction. Be sure not to cover it when wiring leads. (Figure 5) Fan motor vent Figure 5 MAX678RVD Damage...

  • Page 70: Installing The Main Unit

    *1: Position the face panel with its wide edge at the bottom. Fit the edge into the groove of the main unit. MAX678RVD 2. Wire as shown in Section 7 (see page 77). 3. Reassemble and secure the unit in the dashboard and set the face panel and centre panel.

  • Page 71: Installing The Main Unit In A Toyota Vehicle

    Typical Mounting Brackets Example 2 Affix the screws to the ● marks. 8-Hexagonal screw (M5 × 8) Mounting bracket (1 pair for the left and right sides) Example 3 MAX678RVD...

  • Page 72: Cautions On Wiring

    Fuse (15A FUSE) Fuse holder Figure 8 MAX678RVD 5. Connect the CeNET extension cable fully and securely until it locks. When the CeNET extension cable is pulled, hold the slide cap part and pull it towards you. (Figure 9)

  • Page 73: Wire Connection

    Non fader output terminal (2-ZONE output terminal) Visual input terminal iPod Connector cable (CCA-670) (or) iPod with video Connector cable (CCA-673) Connect to the video of visual input terminal. 4-Channel Amplifier Rear monitor Wireless Headphone (WH143H/ WH253H) VTR etc. MAX678RVD...
  • Page 74 *3: Connecting the PHONE MUTE Terminal The lead included with the unit must be connected to the specified position of the vehicle’s connector in order to use the “Mobile phone interrupt setting” function (see page 27). MAX678RVD ∗3 ∗1 Description...

  • Page 75: Connecting The Accessories

    Parking brake 2. Pass the Parking brake signal lead through, and fold it back in the direction of the arrow. Parking brake signal lead Stopper Parking brake signal lead Parking brake lead (Grass-green) MAX678RVD...

  • Page 76: Sample System

    (Black) (DVH943N) CeNET Cable (included the Changer) Set the [SLAVE/STAND ALONE] switch to the [SLAVE] position. STAND SLAVE ALONE MAX678RVD Yellow RCA video cable (included the TV tuner) Non fader output RGB cable (included the NAX963HD) 4-Channel Amplifier RCA cable...
  • Page 77 Clarion Co., Ltd. All Rights Reserved. Copyright © 2007: Clarion Co., Ltd. QZ-6071E Printed in Hungary / Imprimé en Hongrie / Gedruckt in Ungarn Stampato in Ungheria / Gedrukt in Hongarije / Impreso en Hungría 280-8509-00 2007/2 (HUN-YI) Tryckt i Ungern /...
