Connection Without Cable Box Or DBS Receiver
Antenna or cable
Connect
the aerial.
RF cable
(not
supplied)
With antenna or cable (no cable box), wait for clock and
channels to be set automatically.( pg. 17, "Plug & Play Set")
For more information, see the instruction manual. (
ANTENNA
IN
OUT
Connect
your TV.
RF cable
(supplied)
Plug to the
AC outlet.
OUTPUT
Video
Audio (L)
Audio (R)
Audio/Video cable
(supplied)
INPUT
Video
Aucio (L)
Audio (R)
RF
AC outlet
TV
pg. 16, "Basic Connection")
