B14355-R4-TY-UC-ENG-3105
WARNING
DO NOT INSTALL THE ACTUAL
SMOKE
ALARM
RENOVATED BUILDINGS UNTIL ALL
WORK IS COMPLETED (INCLUDING
FLOOR
BUILDING
CLEANED
(Excessive dust & debris from building work can
contaminate the smoke chamber and cause
problems).
An installed smoke alarm must be removed or
covered fully (with a plastic bag or similar)
before renovations begin.
©Ei Electronics 2008
10 YEAR SMOKE ALARM
WITH 10 YEAR LITHIUM BATTERY BUILT-IN
INSTRUCTION LEAFLET
Contains vital information on unit operation and installation.
Read and retain carefully. If you are just installing the unit, this
leaflet MUST be given to the householder.
OPTICAL SMOKE ALARM
MODELS:
Ei 3105TY STANDARD
Ei 3105TYC (with INTERCONNECT)
Ei 3105TYH (with HUSH)
Ei 3105TYCH (with INTERCONNECT
& HUSH)
21/12/10
1:30 PM
IN
NEW
COVERINGS)
HAS
BEEN
1
Page 1
OR
AND
FULLY
P/N B14355 Rev4
