Clarion XD516 Owner's Manual

Clarion am/fm cd player with cd changer control radio am/fm-lecteur cd owner's manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Enlarged version

11. ESPECIFICACIONES

Sintonizador de FM

Generales

Game de frecuencias: 87,9 MHz a 107,9 MHz

Tensión de alimentación: 14,4 V CC (permisible

Sensibilidad útil: 11 dBf

de 10,8 V a 15,6 V), negativo a masa

Sensibilidad a 50 dB de silenciamiento: 17 dBf

Consumo de corriente: Menos de 15 A

Selectividad de canal alternativo: 75 dB

Impedancia de los altavoces: 4

Separación estéreo (1 kHz): 35 dB

a 8

)

Respuesta en frecuencia (±3 dB): 30 Hz a 15 kHz

Peso: 3,97 lb. (1,8 kg)

Dimensiones:

7 " (178 mm) de anchura

Sintonizador de AM

altura

6-1/8 " (155 mm) de fondo

Respuesta en frecuencia: 530 kHz a 1.710 kHz

Sensibilidad útil: 25 µ V

(178 mm)

Reproductor de discos compactos

Sistema: Sistema de audio de discos compactos

Discos utilizables: Discos compactos

Respuesta en frecuencia: 10 Hz a 20 kHz (

1dB)

Relación señal-ruido: 100 dB (1 kHz) IHF-A

7-3/8"

Gama dinámica: 95 dB (1 kHz)

(188 mm)

Distorsion armónica: 0,01%

Notas:

Audio

•

Las especificaciones están de acuerdo con las nor-

mas de la EIA.

Salida de potencia máxima:

•

Las especificaciones y el diseño están sujetos a cam-

200 W (50 W

4 ch)

bio sin previo aviso por motivo de mejoras.

Salida de potencia media continua:

18 W

4, con 4

, 20 Hz a 20 kHz,1% de

distorsión armónica total

Acción de control de graves (30 Hz):

13 dB

Acción de control de agudos (10 kHz):

10 dB

Salida de línea (con CD, 1 kHz, 10 k ): 1,8 V

Clarion Co., Ltd.

2001/1 (D

•

Printed in China /

Imprimé en Chine

/ Impreso en China

(permisible de

2 " (50 mm) de

Contents

English

1. PRECAUTIONS...........................................................2

2. CONTROLS.................................................................3

(50 mm)

3. BUTTON TERMINOLOGY ..........................................4

4. FEATURES..................................................................5

5. HANDLING COMPACT DISCS...................................6

6. DCP .............................................................................7

7. REMOTE CONTROLL ................................................8

8. OPERATION..............................................................10

9. TROUBLESHOOTING ..............................................16

10.ERROR DISPLAYS ...................................................17

11.SPECIFICATIONS.....................................................18

2-1/4"

(58 mm)

Table des matières

Français

1. PRÉCAUTIONS.........................................................19

2. COMMANDES.............................................................3

3. NOMENCLATURE DES TOUCHES .........................20

4. CARACTÉRISTIQUES..............................................21

5. MANIPULATION DES DISQUES COMPACTS ........22

6. CLAVIER DE COMMANDE AMOVIBLE (DCP) .......23

7. TÉLÉCOMMANDE....................................................24

8. FONCTIONNEMENT.................................................26

9. DÉPISTAGE DES PANNES ......................................32

10.AFFICHAGE DES ERREURS...................................33

11.SPÉCIFICATIONS.....................................................34

Índice

Español

1. PRECAUCIONES......................................................35

2. CONTROLES ..............................................................3

3. NOMENCLATURA DE LOS BOTONES ...................36

4. CARACTERÍSTICAS ................................................37

5. MANEJO DE LOS DISCOS COMPACTOS ..............38

6. PANEL DE CONTROL DESMONTABLE (DCP) ......39

7. CONTROLADOR REMOTO......................................40

8. OPERACIÓN .............................................................42

9. SOLUCIÓN DE PROBLEMAS..................................48

10.INDICACIONES DE ERROR ....................................49

11.ESPECIFICACIONES ...............................................50

PE-2386B

280-7596-00

1. PRECAUTIONS

Owner's manual

Mode d'emploi

1. When the inside of the car is very cold and

Manual de instrucciones

the player is used soon after switching on

the heater, moisture may form on the disc

or the optical parts of the player and proper

playback may not be possible. If moisture

forms on the disc, wipe it off with a soft

cloth. If moisture forms on the optical parts

of the player, do not use the player for about

one hour and the condensation will disap-

pear naturally to allow normal operation.

2. Driving on extremely bumpy roads which

cause severe vibration may cause the

sound to skip.

3. This unit uses a precision mechanism.

Even in the event that trouble arises, never

open the case, disassemble the unit, or

lubricate the rotating parts.

XD5 16

USE OF CONTROLS, ADJUSTMENTS, OR PERFORMANCE OF PROCEDURES OTHER THAN

THOSE SPECIFIED HEREIN, MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

AM/FM CD PLAYER

THE COMPACT DISC PLAYER SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE

WITH CD CHANGER CONTROL

EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.

•

RADIO AM/FM-LECTEUR CD

AVEC PILOTAGE DE CHANGEUR CD

•

RADIO AM/FM Y REPRODUCTOR CD

CON CONTROL DE CAMBIADOR DE CD

Bottom View of Source Unit

INFORMATION FOR USERS:

CHANGES OR MODIFICATIONS TO THIS PRODUCT WILL VOID THE WARRANTY AND WILL

VIOLATE FCC APPROVAL.

This equipment has been tested and found to

comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reason-

able protection against harmful interference in

a residential installation. This equipment gen-

erates, uses, and can radiate radio frequency

energy and, if not installed and used in accor-

dance with the instructions, may cause harmful

interference

radio

communications.

However, there is no guarantee that interfer-

ence will not occur in a particular installation. If

this equipment does cause harmful interfer-

ence to radio or television reception, which can

be determined by turning the equipment off

and on, the user is encouraged to consult the

dealer or an experienced radio/TV technician

for help.

CAUTION

DRX5675

MODEL

12V

GROUND

AM 530-1710kHz/FM 87.9-107.9MHz

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.

OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND

(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,

INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED

OPERATION.

THIS PRODUCTION COMPLIES WITH DHHS RULES 21 CFR

SUBCHAPTER J APPLICABLE AT DATE OF MANUFACTURE.

CLARION CO.,LTD.

50 KAMITODA,TODA-SHI,SAITAMA-KEN,JAPAN

MANUFACTURED:

286- 324-00

SERIAL No.

Clarion Co.,Ltd.

MADE IN CHINA

PE-2310B

Be sure to unfold and read the next page.

Veuillez déployer et vous référer à la page suivante.

Cerciórese de desplegar y de leer la página siguiente.

XD516

Table of Contents

Need help?

Do you have a question about the XD516 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarion XD516

Page 1 Acción de control de agudos (10 kHz): 10 dB Salida de línea (con CD, 1 kHz, 10 k ): 1,8 V Clarion Co., Ltd. PE-2386B All Rights Reserved. Copyright © 2001: Clarion Co., Ltd. 280-7596-00 2001/1 (D • Printed in China / Imprimé...
Page 2: Button Terminology
Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre. Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas. XD516 3. BUTTON TERMINOLOGY Note: • Be sure to read this chapter referring to the front diagrams of chapter 2. CONTROLS on page 3 (unfold).
Page 3: Flip Down Panel
4. When closing the FLIP DOWN PANEL, do not press the Open button 1. 5. Strong impacts to the operating or display section can cause damage or deformation. 6. If the flip down panel does not open fully, gently open it with your hand. XD516...
Page 4: Handling Compact Discs
Do not use commercially available CD protection sheets or discs equipped with stabilizers, etc. These • may get caught in the internal mechanism and damage the disc. XD516 Note on Compact Discs mark. Never stick labels on the surface of the compact disc or mark the surface with a pencil or pen.
Page 5: Removing The Dcp
• The connector connecting the unit and the DCP is an extremely important part. Be careful not to damage it by pressing on it with fingernails, screwdrivers, etc. Note: • If the DCP is dirty, wipe off the dirt with a soft, dry cloth only. XD516...
Page 6: Inserting The Batteries
• Do not short-circuit, disassemble or heat batteries. • Do not dispose of batteries into fire or flames. • Dispose of spent batteries properly. XD516 Receiver for remote control unit Operating range: 30 in all directions Signal transmitter ¡ ¢...
Page 7: Functions Of Remote Control Unit Buttons
When pressed and held for 1 second: Disc scan play. Repeat play. Repeat play. When pressed and held for 1 second: Disc repeat play. Random play. Random play. When pressed and held for 1 second: Disc random play. CD changer XD516...
Page 8: Adjusting The Balance
–6 to +6) 3) When the adjustment is complete, press A-M button 2 several times until the function mode is reached. XD516 Adjusting the Treble 1) Press A-M button 2 and select “TREB”. 2) Turning the Rotary knob # clockwise empha- sizes the treble;...
Page 9: Radio Mode Operations
BND button ! for 1 second or longer. When the “MANU” display is off, the Seek Selection function is on. 3) Press the SRCH Left/Right button @, then when it selects the station in which there is a broadcast, it automatically stops. ® XD516...
Page 10: Preset Memory Function
1) Press the FNC button 3, then select the radio mode. 2) Select the radio station which you want to store in the memory. XD516 3) Press and hold the ISR button 4 for 2 sec- onds or longer. Recalling ISR Press the ISR button 4 then the display will show “ISR”, then the radio station previously...
Page 11: Cd Mode Operations
: To fast-backward Pressing the SRCH Left/Right button for 1 second or longer will move forward or backward 5 times faster than normal play, and pressing it for 3 seconds or longer will do the operation 30 times faster. XD516...
Page 12: Repeat Play
“RDM”, then the entire tracks on the disc will be played at random. Press the RDM button 6 again to disengage the unit from random play. XD516 CD Changer Mode Operations Listening to the Disc Press the FNC button 3 and select the CD changer mode, then the CD starts playing.
Page 13 Switching Magazine This function can be used only when the con- nected CD changer can store a multiple number of magazines. Every time the MAG button ! is pressed, the next magazine will be selected. ” and XD516...
Page 14: Troubleshooting
XD516 Cause Replace with a fuse of the same amperage. If the fuse blows again, consult your store of purchase. Consult your store of purchase.
Page 15: Error Displays
Replace with a non-scratched, non-warped disc. Eject the disc then reload it properly. This is a failure of CD changer’s mechanism and consult your store of purchase. Replace with a non-scratched, non-warped disc. Eject the disc then reload it properly. XD516...
Page 16: Specifications
± Bass Control Action (30 Hz): Treble Control Action (10 kHz): Line Output (with CD 1 kHz, 10 k ): 1.8 V XD516 General Power Supply Voltage: 14.4 V DC (10.8 V to 15.6 V allowable), negative ground Current Consumption: Less than 15 A Speaker Impedance: 4 Ω...
