XAZ61 1
AM/FM CASSETTE PLAYER
WITH CD/MD CHANGER CONTROL
•
LECTEUR DE CASSETTE AM/FM AVEC
COMMANDE DE CHANGEUR CD/MD
•
RADIO DE AM/FM Y REPRODUCTOR DE
CASETES CON CONTROL DE CAMBIADOR DE
DISCOS COMAPCTOS/MINIDISCOS
Clarion Co., Ltd.
PE-1717B
All Rights Reserved. Copyright © 2001: Clarion Co., Ltd.
2001/1 (D·C)
280-7626-00
Printed in China /
Imprimé en Chine
/ Inpreso en China
Advertisement
Table of Contents
Related Manuals for Clarion XAZ611
Summary of Contents for Clarion XAZ611
- Page 1 RADIO DE AM/FM Y REPRODUCTOR DE CASETES CON CONTROL DE CAMBIADOR DE DISCOS COMAPCTOS/MINIDISCOS Clarion Co., Ltd. PE-1717B All Rights Reserved. Copyright © 2001: Clarion Co., Ltd. 2001/1 (D·C) 280-7626-00 Printed in China / Imprimé en Chine / Inpreso en China...
-
Page 2: Table Of Contents
Thank you for purchasing this Clarion product. Please read this owner’s manual in its entirety before operating this equipment. After reading this manual, be sure to keep it in a handy place (e.g., glove compartment). Check the contents of the enclosed warranty card and keep it carefully with this manual. -
Page 3: Features
Touch-n-Go Flip Down Detachable Aluminum Face Controller for Optional DSP / EQ, TV Tuner and DVD Deck Modules Capability to Read CD TEXT Data from Clarion Compatible CD Changer BEAT EQ with 3 Adjustment Modes CeNET with Balanced Audio Line Transmission and Dynamic Noise Canceling ®... -
Page 4: Controls
Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre. Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas. XAZ611 4. NOMENCLATURE Note: • Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold). -
Page 5: Remote Control
When pressed and held for 1 second: Disc random play. Switches reception band. Moves preset channels up and down. No function. Preset scan. When pressed and held for 2 seconds: Auto store. No function. Switches between TV and VTR. XAZ611... -
Page 6: Operations
2. Each time you press FNC button 3, the mode of operation changes in the following order: XAZ611 Note: Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold). Radio mode... -
Page 7: Adjusting The Balance
The factory default setting is “0”. (Adjustment range: F12 to R12) 3. When the adjustment is complete, press A-M button @ several times until the function mode is reached. Basic Operations button select XAZ611... -
Page 8: Radio Operations
2. Press and hold LD button @ for 1 second or longer to turn off the loudness effect. “LD” goes off in the display. XAZ611 Radio Operations FM reception For enhanced FM performance the tuner includes signal actuated stereo control, En- hanced Multi AGC, Impulse noise reduction circuits and Multipath noise reduction circuits. -
Page 9: Manual Tuning
Recalling a station with ISR In any mode, press ISR button 9 to turn on the radio function and tune the selected radio sta- tion. “ISR” appears in the display. Press ISR but- ton 9 again to return to the previous mode. XAZ611... -
Page 10: Tape Operations
1. Press Play/pause button # to pause tape playback. “PAUSE” appears in the display. 2. Press Play/pause button # again to resume tape playback. XAZ611 Ejecting a tape 1. Press OPEN button 1 to access the cassette Eject button & behind the FLIP DOWN PANEL. -
Page 11: Dolby Noise Reduction System
• Tapes on which there is much noise between se- lections. • Tapes on which there are long pauses in the middle of selections. • Tapes on which there are less than 4 seconds of blank space between selections. XAZ611... -
Page 12: Other Handy Functions
5. Press the right or left side of SEARCH button % to move the cursor. XAZ611 6. Press DISP button 0 to select a character. Each time you press DISP button 0, the char-... -
Page 13: Message Display
3. Turn the Rotary knob $ clockwise or coun- terclockwise as needed and select from “SENS HIGH”, “SENS MID” or “SENS LOW”. The factory default setting is “SENS MID”. 4. Press ADJ button 2 to return the previous mode. Other Handy Functions XAZ611... -
Page 14: Operations Of Accessories
1. Display the CD-text title (disc or track). 2. Press TITLE button 2. The title scrolls. XAZ611 Selecting a CD Each of the Direct button 8 corresponds to a disc loaded into the magazine. -
Page 15: Random Play
“DISC” and “RDM” light in the dis- play and the disc random play starts. 2. To cancel the disc random play, press and hold RDM button 6 again. “DISC” and “RDM” go off from the display and normal play resumes from the current track. XAZ611... -
Page 16: Md Changer Operations
Track-up 1. Press the right side of SEARCH button % to move ahead to the beginning of the next track. XAZ611 2. Each time you press the right side of SEARCH button %, the track advances ahead to the beginning of the next track. -
Page 17: Tv Operations
Watching a video The TV tuner has a VTR input terminal to which 1 external device can be connected. Connect a 12V video cassette player (VCP) or video cas- sette recorder (VCR) to the TV tuner input termi- nal. 1. Press RDM button 6 to select VTR. - Page 18 If there are not 6 stations with good reception, stations previously stored in memory remain and only the strong stations are stored into memory. XAZ611 1. Press BND button ! and select the desired TV band (TV1 or TV2). 2. Press and hold AS button 4 for 2 seconds or longer.
-
Page 19: Ac Processor Operations
STD mode/G.EQ operations Note: • The adjustment made in standard mode is not re- flected in the adjustment in professional mode. On the contrary, the adjustment made in professional mode is not reflected in the adjustment in easy mode. XAZ611... - Page 20 You can give a title to the user memory. For the inputting method of titles, refer to the subsec- tion “Entering titles” in section “Operations common to each mode”. XAZ611 STD mode/DSF operations DSF effect ON/OFF When the “DSF” indication ¥ is lit in the display, the DSF effect is set to “ON”.
- Page 21 When “P.EQ” is unlit, the P.EQ effect is set to OFF. Note: • If the P.EQ effect is set to OFF, the adjustment made in “P.EQ operations” is not reflected in the music source. XAZ611...
-
Page 22: Digital Radio / Dab Operations
You can give a title to the user memory. For the inputting method of titles, refer to the subsec- tion “Entering titles” in section “Operations common to each mode”. XAZ611 Note: Be sure to read this chapter referring to the front diagrams of chapter “3.CONTROLS” on page 5 (unfold). -
Page 23: Seek Tuning
Switching ON the AF function AF function between RDS and DAB When the same programme is broadcast by both RDS and DAB, and this function is ON, the main unit switches to receiving the broadcast with the better reception automatically. XAZ611... - Page 24 INFO standby mode. Cancelling INFO standby mode To cancel INFO standby mode, press and hold ISR button 9 for 1 second or longer. XAZ611 Information select This is a function for selecting INFORMATION ON or OFF in Information interrupt mode.
-
Page 25: Emergency Broadcast
Listening to DVD Press FNC button 3 and select the DVD mode. Adjust the volume Turning the Rotary Knob $ clockwise increases the volume; turning it counterclockwise de- creases the volume. Other operations refer to DVD deck’s owner’s manual. XAZ611... -
Page 26: Troubleshooting
Sound quality is Playback head is dirty. poor. DOLBY NR button 6 is not pressed. XAZ611 Cause Replace with a fuse of the same amperage. If the fuse blows again, consult your store of purchase. Consult your store of purchase. -
Page 27: Error Displays
MD changer. This is a failure of MD changer’s mecha- nism and consult your store of purchase. Replace with a non-scratched, non-warped disc. Eject the disc then reload it properly. Load a pre-recorded MD in the MD changer. Measure XAZ611... -
Page 28: Specifications
Dolby B NR: 67 dB Notes: • Specifications comply with EIA Standards. • Specifications and design are subject to change without notice for further improvement. XAZ611 Audio Maximum Power Output: 180 W (45 W Continuous Average Power Output: 17 W...
