Electrolux 27 SINGLE OVEN Manual

Installation INSTRUCTIONS
ELECTRIC BUILT-IN
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER
IMPORTAT NOTE TO INSTALLER:
tions completely and carefully. Be sure to leave these instructions with
the consumer.
IMPORTANT NOTE TO CONSUMER:
use and care book for future reference. Observe all governing codes
and ordinances. Save these instructions for local inspectors.
Your new wall oven has been designed to fit a limited variety of cutout
sezes to make the job of installing easier. The first step of your installa-
tion should be to measure your current cutout dimensions and compare
them to the cutout dimensions for your model shown on page 2. You
will find the extent of cabinet work that will be necessary.

1. CARPENTRY

Refer to Figures 1 and 2 for the dimensions applicable to
your model oven, and the space necessary to receive the
oven. The oven support surface may be solid plywood or
similar material, however the surface must be level from
side to side and from front to rear.
capable of supporting a weight of approximately 125
lbs.
2. ELECTRICAL REQUIREMENTS
Connect oven to a power supply having the required
electrical rating. See the rating plate located on the
internal side of the oven left hand side trim.
Wiring and overload protection for the incoming power
supply must conform to local canadian electrical code
(plus provincial code if applicable).
capable of supporting a weight of approximately 125
lbs.
Recycled Paper
27" SINGLE OVEN MODELS
Floor must be
Floor must be
Before you begin - read these instruc-
Keep these instructions with your

3. INSTALLATION

WARNING: The wall oven can tip when the door is
open. The anti-tip screws supplied with the wall oven
must be used to secure the appliance onto the cabinet to
prevent tipping and injury to persons.
The anti-tip screws are enclosed in the literature package
supplied with the wall oven.
CAUTION: Wait at least three (3) hours after receiving
this built-in oven before switching the power on to
prevent possible damage to the built-in oven control at
power on.
- 1 -
(following on page 3)
318064308 (9805) Rev. B
Printed in Canada
