- Page 1 IM3132 04/2020 REV00 ® POWERTEC i400S OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-263 Bielawa, Poland www.lincolnelectric.eu...
-
Page 2: Table Of Contents
12/05 THANKS! For having choosen the QUALITY of the Lincoln Electric products. Please Examine Package and Equipment for Damage. Claims for material damaged in shipment must be notified immediately to the dealer. For future reference record in the table below your equipment identification information. Model Name, Code & Serial Number can be found on the machine rating plate. -
Page 3: Technical Specifications
Technical Specifications NAME INDEX POWERTEC ® i400S K14241-1 INPUT Input Voltage U EMC Class Frequency 400V ± 15% 3-phase 50/60Hz Input Power at Rated Cycle Input Amperes I 1max 15 kVA @ 50% Duty Cycle (40°C) 0,90 Efficiency Idle Power RATED OUTPUT Duty Cycle 40°C Open Circuit Voltage... -
Page 4: Electromagnetic Compatibility (Emc)
This machine has been designed to operate in an industrial area. The operator must install and operate this equipment as described in this manual. If any electromagnetic disturbances are detected the operator must put in place corrective actions to eliminate these disturbances with, if necessary, assistance from Lincoln Electric. WARNING Provided that the public low voltage system impedance at the point of common coupling is lower than: ... -
Page 5: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. - Page 6 CYLINDER MAY EXPLODE IF DAMAGED: Use only compressed gas cylinders containing the correct shielding gas for the process used and properly operating regulators designed for the gas and pressure used. Always keep cylinders in an upright position securely chained to a fixed support. Do not move or transport gas cylinders with the protection cap removed.
-
Page 7: Intoduction
Intoduction ® POWERTEC i400S inverter source have The complete packaging includes the following items: connected with wire feeder LF52Ds. Signal from the Inverter source; power source will be displayed on wire feeders user USB with Operator’s Manual; interface. For communication, inverter source-wire ... - Page 8 Controls and Operational Features Figure 2. Figure 1. 6. Supply Plug: for gas heater kit (see “Accessories 1. Power Switch ON/OFF (I/O): Controls the input Suggested” chapter). power. Make sure the power source is properly connected to the mains supply before turning power 7.
- Page 9 Transport & Lifting WARNING Falling equipment can cause injury and damage to unit. ® POWERTEC i400S Figure 3. 14. Fuse F1: Use the 2A/400V (6,3x32mm) low blow fuse. Welding Cables Connection Insert the plug of the work lead into the socket [2]. The other end of this lead connect to the work piece with the work clamp.
- Page 10 We respond to our customers be lost. based on the best information in our possession at that time. Lincoln Electric is not in a position to warrant or Any noticeable damage should be reported immediately guarantee such advice, and assumes no liability, with and repaired.
-
Page 11: Weee
12/05 Part List reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. -
Page 12: Accessories Suggested
Accessories Suggested K14186-2 LF 52Ds GRD-400A-70-xM* Ground cable 400A/70 mm²; x=5/10/15 m K14196-1 OUTPUT CONNECTION KIT K14201-1 CABLE MANAGEMENT KIT K14176-1 GAS HEATER KIT (POWERTEC ® INTERCONNECTION CABLE K14198-PG-30M-S CABLE PACK 5PIN G 95MM2 30M (SHIPYARD) K14198-PG-40M-S CABLE PACK 5PIN G 95MM2 40M (SHIPYARD) English English... -
Page 13: Connection Configuration
Connection configuration Figure 5 English English...
