LD-E Laser Displacement Operating
Chapter 1: Product Profile ................................................... 1-1
1.1 Packaging ........................................................................................ 1-1
1.2 Part Names and Functions .............................................................. 1-1
1.3 Installation ....................................................................................... 1-2
Chapter 2: Settings and Measurements ......................... 2-1
2.1 Display Operation ............................................................................ 2-1
Chapter 3: Software Operation .......................................... 3-1
3.1 Communication Setting ................................................................... 3-1
Chapter 4: Communication Setting .................................. 4-1
4.1 Communication Address .................................................................. 4-1
4.2 Communication Protocol ................................................................. 4-4
Chapter 5: Specifications .................................................... 5-1
Chapter 6: Safety Precautions ........................................... 6-1
Chapter 7: Warranty .............................................................. 7-1
Laser Displacement Operating Manual
Manual
Table of Contents
V1.0
Advertisement
Table of Contents
Related Manuals for Delta LD-100E-M22
Summary of Contents for Delta LD-100E-M22
-
Page 1: Table Of Contents
LD-E Laser Displacement Operating Manual V1.0 Table of Contents Chapter 1: Product Profile ........... 1-1 1.1 Packaging ..................1-1 1.2 Part Names and Functions .............. 1-1 1.3 Installation ..................1-2 Chapter 2: Settings and Measurements ......2-1 2.1 Display Operation ................2-1 Chapter 3: Software Operation .......... -
Page 2: Chapter 1 Product Profile
Chapter 1 Product Profile Chapter 1 Product Profile 1.1 Packaging The following is included: Laser displacement and cable (optional) Laser label Simple instruction sheet Laser Label Description Laser Radiations: Class 2 Product Maximum Output: <1mW Pulse Duration: 0.5ms max. Wave Length:655nm, IEC 60825-1:2014 1.2 Part Names and Functions ◎... -
Page 3: Installation
Chapter 1 Product Profile ◎ Laser Indicator Indicator Color Description Laser indicator Blue light Start (laser on) Green light Yellow light Negative Red light Negative Laser indicator Negative 1.3 Installation ◎ Dimension (unit: mm) LD-E Operation Manual... - Page 4 Chapter 1 Product Profile ◎ Wiring Instructions LD-E Operation Manual...
- Page 5 Chapter 1 Product Profile ◎ Caution on Mounting Direction For best product performance, please note the following instructions when installing products. When products cling to devices, install the products in parallel with the devices to assure product performance. When the shape of an inspection object is extrusive, ensure the product's lighting route is vertical to the inspection object's path to assure product performance.
-
Page 6: Chapter 2 Settings And Measurements
Chapter 2 Settings and Measurements Chapter 2 Settings and Measurements 2.1 Display operation ◎ Display instruction LD-E Operation Manual... - Page 7 Chapter 2 Settings and Measurements Basic teaching (2 point teaching) The teaching point of second point is greater than the first point 2 hysteresis (Hys) size. 1. In a state of background, press 2. When there is a detection object, press When the object can be detected When the object cannot be detected LD-E Operation Manual...
- Page 8 Chapter 2 Settings and Measurements Single point teaching (window comparison mode) Single point teaching is used for the distance between the reference plane of the detection object, the method of setting the upper and lower limits, and the output between the upper and lower limits. After the reference plane of the detection object is taught ...
- Page 9 Chapter 2 Settings and Measurements 2 point teaching (window comparison mode) Execute 2 point teaching and set the reference value. First, come to the advanced setting, set the detection output to _P_2 (2-point teaching) When executing, use detection objects with different distances (P-1, P-2) ...
- Page 10 Chapter 2 Settings and Measurements 3 point teaching (window comparison mode) Before executing 3 point teaching, set the reference value 1_SL between 1 time and 2 time and set the reference value 2_SL between 2 time and 3 time. First, come to the advanced setting, set the detection output to _P_3 (3-point teaching) ...
- Page 11 Chapter 2 Settings and Measurements ◎ Set the zero value The operation on the main screen is as follows <Set the zero value> Press the up button and down button at the same time for 3 seconds. <Remove the zero value> Press the up button and down button at the same time for 6 seconds.
- Page 12 Chapter 2 Settings and Measurements Median filter Median filter window frame setting: setting “ ”: window frame size 1, “ ”: window frame size, “ ”: window frame size 5, “ ”: window frame size 7, “ ”: window frame size 9, “ ”: window frame size 11, “...
- Page 13 Chapter 2 Settings and Measurements bps “ ” : 19200 bps, “ ”: 14400 bps, “ ” : 9600 bps Communication Communication format setting : format setting “ ” : ASCII,8,N,1 “ ” : ASCII,8,O,1 “ ” : ASCII,8,E,1 “ ”...
- Page 14 Chapter 2 Settings and Measurements Steps LD-E Operation Manual...
- Page 15 Chapter 2 Settings and Measurements LD-E Operation Manual 2-10...
- Page 16 Chapter 2 Settings and Measurements LD-E Operation Manual 2-11...
- Page 17 Chapter 2 Settings and Measurements ◎ Analog output The analog output range is 4-20mA. Distance from the closest distance to the farthest distance (absolute distance). ◎ Digital output timer function setting LD-E Operation Manual 2-12...
-
Page 18: Chapter 3 Software Operation
Chapter 3 Software Operation Chapter 3 Software Operation 3.1 Communication Setting ◎ Install the laser displacement and installation file Next Next LD-E Operation Manual... - Page 19 Chapter 3 Software Operation Next Close LD-E Operation Manual...
- Page 20 Chapter 3 Software Operation ◎ Open desktop shortcut file Function Language area area Operating area Information area Area Description Each function display. Function Communication setting, real-time data, real-time data waveform, waveform acquisition, parameter setting and reading. Language switch. English, Traditional Chinese, Simplified Chinese. Language Laser displacement information display.
- Page 21 Chapter 3 Software Operation ◎ Communication setting operation area Connection settings Scanning Connection settings Connect after setting up according to the communication format Step1: Set up the port Step2: Select RTU/ASCII mode Scanning Step3: Select the station number range Step4: Start scanning ◎...
- Page 22 Chapter 3 Software Operation ◎ Real-time data operation area Start Start to read the data, and the data will be read according to the selected LD. Zero The LD is reset to zero. Reset to zero The default value is reset to zero. The default values are different for each model. LD-E Operation Manual...
- Page 23 Chapter 3 Software Operation ◎ Real-time graphics operation area Set the station number of the laser displacement, and only one data can Station No. be displayed at a time. Displacement Display the absolute displacement of the laser Storage quantity setting Can store the relationship between time and location Save Start saving...
- Page 24 Chapter 3 Software Operation ◎ Wave operation area Exposure setting X-Y axis range adjustment Capture mode Set the station number of the laser displacement er, and only one data can Station No. be displayed at a time. Wave Center Display wave weight position Shutter Level Show exposure Can be set to use manual or automatic exposure, manual exposure can set...
- Page 25 Chapter 3 Software Operation ◎ Parameter reading and writing operation area LD-E Operation Manual...
-
Page 26: Chapter 4: Communication Setting
Chapter 4 Communication Setting Chapter 4 Communication Setting 4.1 Communication Address ◎ RS485 Communication Mode Baud Rate Supported: 9,600, 14400, 19200, 38400, 57600, 115200bps ◎ Communication Mode Supported: 8,N,1、8,N,2、8,O,1、8,O,2、8,E,1、8,E,2、7,O,1、7,E,1、7,O,2、 ◎ 7,E,2 Communications Protocol: Modbus RTU, ASCII ◎ Communication Address Supported: 1 to 127 ◎... - Page 27 Chapter 4 Communication Setting 0x0E: ASCII, 7, O, 2 0x0F: ASCII, 7, E, 1 0x10: ASCII, 7, E, 2 Displacement absolute position output: 1004H~1005H (R) LD-100E: 65000~135000um (03H) Absolute position LD-220E: 120000~320000um LD-500E: 300000~700000um Relative position of displacement = Absolute 1006H~1007H (R) (03H) Relative position...
- Page 28 Chapter 4 Communication Setting 0x0F: Window size 15 0x01: Normal output mode (Default) Output delay 0x02: Off-delay 1014H (R/W) (03H,06H) mode setting 0x03: On-delay 0x04: One-shot Range: 1015H (R/W) (03H,06H) Output delay time 0x0000~0x03E8: (0~1000ms) 0x05 (Default value) Action output 0x01: Normally closed (Default value) 1016H (R/W) (03H,06H)
-
Page 29: Communication Protocol
Chapter 4 Communication Setting 4.2 Communication protocol ASCII Mode Read Command Read Command Response Write Command Write Command Response ’：’ ’：’ ’：’ ’：’ ADR 1 ‘0’ ADR 1 ‘0’ ADR 1 ‘0’ ADR 1 ‘0’ ADR 0 ‘1’ ADR 0 ‘1’... -
Page 30: Chapter 5 Specifications
Chapter 5 Specifications Chapter 5 Specifications Detection Model Repeatability Interface Detection method distance LD-100E-M22 65~135 mm 70μm Digital I/O LD-220E-M22 120~320 mm 200μm Modbus Triangular measurement (300~500mm)300μm LD-500E-M22 300~700 mm RS485 (500~700mm)600μm Features (all models) Laser Displacement Detection method Triangular measurement... - Page 31 Chapter 5 Specifications Input surge protection, Output surge protection Operating -10ºC ~ 50 ºC Temperature Storage Temperature -25 ºC ~ 65 ºC Ambient Humidity 30~85% Enclosure Rating IP67 Ambient Light 3000 lux or less Resistance Vibration Resistance 10~55 Hz, 1.5mm, 3 axes for 2 hours Insulating Resistance 20 MΩ...
-
Page 32: Chapter 6 Safety Precautions
Chapter 6 Safety Precautions Chapter 6 Safety Precautions ◎ Caution of laser displacement If you do not use, control, adjust, or perform operations as required, there is the possibility of exposure to radiation. Due to the possibility of human injury (eyes, skin, etc.), please be sure to observe the followings. ... -
Page 33: Chapter 7 Warranty
Chapter 7 Warranty Chapter 7 Warranty All products from Delta Electronics Inc. undergo detailed inspection before shipment. If you have any problems, please contact your local branch or distributor and detail the failure. ◎ Warranty Term This Limited Warranty shall last for twenty four months from shipment to purchaser.
