Sauder 423742 Manual

L-shaped desk
Hide thumbs

Advertisement

Quick Links

Download this manual
CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE RETAILER.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
L-Shaped Desk
Coral Cape Collection | Model 423742
Sauder.com
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-445-1527
.
For all your
newfangled gadgetry.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-28
Français pg 29-32
Español pg 33-36
Lot # 533402
Purchased: __________________
10/10/19

Advertisement

loading

Related Manuals for Sauder 423742

Summary of Contents for Sauder 423742

  • Page 1 Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays) For all your newfangled gadgetry. L-Shaped Desk NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Coral Cape Collection | Model 423742 PLEASE READ AND KEEP FOR FUTURE REFERENCE. Sauder.com English pg 1-28 Français pg 29-32 Español pg 33-36...
  • Page 2 Table of Contents Assembly Tools Required Part Identification No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identification Assembly Steps 5-28 Français 29-32 Skip the power trip. This time. Español 33-36 Safety 37-38 Warranty Page 2 www.sauder.com/service 423742...
  • Page 3 LARGE DRAWER BOTTOM (1) FRAME BRACE (1) SMALL DRAWER FRONT (1) RIGHT END FRAME (1) BB DRAWER BOX FRAME BRACE (2) SMALL DRAWER BACK (1) RIGHT UPRIGHT FRAME (1) SMALL LEFT DRAWER SIDE (1) TOP UPRIGHT FRAME BRACE (2) 423742 www.sauder.com/service Page 3...
  • Page 4 GOLD 1-3/8" HEX HEAD SCREW - 33 GOLD 7/8" HEX HEAD SCREW - 16 BLACK 1-7/8" HEX HEAD SCREW - 2 SILVER 3/4" MACHINE SCREW - 4 GOLD 1-3/8" FLAT HEAD SCREW - 8 BLACK 7/16" FLAT HEAD SCREW - 24 Page 4 www.sauder.com/service 423742...
  • Page 5 Push six LARGE HIDDEN CAMS (5) completely in the holes of the TOP UPRIGHT (C), and ENDS (E and F). Arrow Hole Arrow (6 used) The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. 423742 www.sauder.com/service Page 5...
  • Page 6 Meet Parts (A and B). These components have been engineered to be lighter, stronger, faster… well ok. Not technically faster. But definitely makes for a sturdier L-Shaped Desk that’ s easier to assemble and friendlier to the environment. Page 6 www.sauder.com/service 423742...
  • Page 7 å NOTE: The SMALL EXTENSION SLIDES will be used later for the DRAWERS. hole Open end Use these holes. Groove Groove Open end BLACK 7/16" FLAT HEAD SCREW Open end (6 used in this step) 423742 www.sauder.com/service Page 7...
  • Page 8 å NOTE: The LARGE EXTENSION SLIDES will be used later for the DRAWERS. hole Open end Use these holes. Groove Open end Groove BLACK 7/16" FLAT HEAD SCREW (6 used in this step) Open end Page 8 www.sauder.com/service 423742...
  • Page 9 Fasten a TOP BRACE (Y) to the SMALL TOP (A). Tighten four GOLD 1-3/8" HEX HEAD SCREWS (15) using the Just think. The sooner L-WRENCH (11). you do this, the sooner you do something else. GOLD 1-3/8" HEX HEAD SCREW (4 used in this step) 423742 www.sauder.com/service Page 9...
  • Page 10 Insert two WOOD DOWELS (8) into the SMALL TOP (A). å Fasten the TOP UPRIGHT (C) to the SMALL TOP (A). Tighten two LARGE HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the TOP insert into the holes in the TOP UPRIGHT. Page 10 www.sauder.com/service 423742...
  • Page 11 Step 7 å Fasten a BRACE (W) to the SMALL TOP (A). Tighten two GOLD 1-3/8" HEX HEAD SCREWS (15) using the L-WRENCH (11). GOLD 1-3/8" HEX HEAD SCREW (2 used in this step) 423742 www.sauder.com/service Page 11...
  • Page 12 GOLD 1-3/8" HEX HEAD SCREWS (15) using the L-WRENCH (11). å Fasten the LEFT END FRAME (X) to the BRACES (W and Y). Tighten four GOLD 1-3/8" HEX HEAD SCREWS (15) using the L-WRENCH (11). GOLD 1-3/8" HEX HEAD SCREW (6 used in this step) Page 12 www.sauder.com/service 423742...
  • Page 13 Step 9 å Fasten the BRACE (Z) to the LEFT END FRAME (X). Tighten two GOLD 7/8" HEX HEAD SCREWS (16) using the L-WRENCH (11).. GOLD 7/8" HEX HEAD SCREW (2 used in the BRACES) 423742 www.sauder.com/service Page 13...
  • Page 14 Fasten the ENDS (E and F) to the LARGE TOP (B). Tighten four LARGE HIDDEN CAMS. å NOTE: Be sure the WOOD DOWELS in the LARGE TOP insert into the holes in the ENDS. Groove (4 used) Page 14 www.sauder.com/service 423742...
  • Page 15 Step 11 å Slide the BACK (D) into the grooves in the ENDS (E and F). å NOTE: Be sure the BACK slides into the LARGE TOP groove. 423742 www.sauder.com/service Page 15...
  • Page 16 NOTE: Be sure the WOOD DOWELS in the BOTTOM insert into the holes in the ENDS. BLACK 1-1/2" HEX HEAD SCREW å NOTE: Be sure the BOTTOM groove inserts into the BACK. (4 used in this step) (4 used) Page 16 www.sauder.com/service 423742...
  • Page 17 Fasten the FRAMES (S and T) to the LARGE TOP (B). Tighten four GOLD 1-3/8" HEX HEAD SCREWS (15) using the L-WRENCH (11). GOLD 1/2" HEX HEAD SCREW (4 used in the BRACES) GOLD 1-3/8" HEX HEAD SCREW (4 used in the FRAMES) 423742 www.sauder.com/service Page 17...
  • Page 18 å Fasten a BRACE (U) to the FRAME (T). Tighten two GOLD (8 used in the BRACES) 1-3/8" HEX HEAD SCREWS (15) using the L-WRENCH (11). GOLD 1-3/8" HEX HEAD SCREW (4 used in this step) Page 18 www.sauder.com/service 423742...
  • Page 19 GOLD 7/8" HEX HEAD SCREWS (16) using the L-WRENCH (11). GOLD 1-3/8" HEX HEAD SCREW (2 used in this step) For support, place packing foam and magazines here. GOLD 7/8" HEX HEAD SCREW (4 used in the BRACES) 423742 www.sauder.com/service Page 19...
  • Page 20 L-WRENCH (11). GOLD 1-3/8" HEX HEAD SCREW (5 used for the BRACES) (2 used) GOLD 7/8" HEX HEAD SCREW BLACK 1-7/8" HEX HEAD SCREW (2 used in the FRAME) (2 used for the TOP UPRIGHT) Page 20 www.sauder.com/service 423742...
  • Page 21 Fasten the remaining BRACE (U) to the LARGE TOP (B), and FRAMES (T and V). Tighten six GOLD 1-3/8" HEX Side Step: Make HEAD SCREWS (15) using the L-WRENCH (11). nachos. (Optional, but recommended.) GOLD 1-3/8" HEX HEAD SCREW (6 used in this step) 423742 www.sauder.com/service Page 21...
  • Page 22 Push eight SMALL HIDDEN CAMS (6) into the DRAWER SIDES (K, L, P, and Q). Arrow Hole Arrow The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. (8 used) Page 22 www.sauder.com/service 423742...
  • Page 23 Fasten the SMALL EXTENSION SLIDES (4) to the SMALL DRAWER SIDES (K and L). Use six BLACK 7/16" FLAT HEAD SCREWS (20). Open end Use these holes. BLACK 7/16" FLAT HEAD SCREW (6 used in this step) Open end Open end 423742 www.sauder.com/service Page 23...
  • Page 24 Fasten the LARGE EXTENSION SLIDES (2) to the LARGE DRAWER SIDES (P and Q). Use six BLACK 7/16" FLAT HEAD SCREWS (20). Open end Use these holes. Open end Open end BLACK 7/16" FLAT HEAD SCREW (6 used in this step) Page 24 www.sauder.com/service 423742...
  • Page 25 Fasten the SMALL DRAWER FRONT (H) to the SMALL DRAWER SIDES (K and L). Tighten four SMALL HIDDEN CAMS. å NOTE: Be sure the DRAWER BOTTOM (M) inserts into the groove of the DRAWER FRONT (H). 423742 www.sauder.com/service Page 25...
  • Page 26 Fasten the LARGE DRAWER FRONT (N) to the LARGE DRAWER SIDES (P and Q). Tighten four SMALL HIDDEN CAMS. å NOTE: Be sure the DRAWER BOTTOM (R) inserts into the groove of the DRAWER FRONT (N). Page 26 www.sauder.com/service 423742...
  • Page 27 Fasten the PULLS (9) to the DRAWER FRONTS (H and N). Use four SILVER 3/4" MACHINE SCREWS (18). Hey! It's starting to look å Push the FILE GLIDES (12) to the LARGE DRAWER SIDES (P and Q). like something! SILVER 3/4" MACHINE SCREW (4 used in this step) 423742 www.sauder.com/service Page 27...
  • Page 28 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. And to celebrate, why not share your success story at sauder.com or (18 used) Page 28 www.sauder.com/service...
  • Page 29 Modèle 423742 Bureau en L Utilisez les instructions d’ a ssemblage en français avec les NOUS CONTACTER EN PREMIER schémas étape par étape du manuel d’instruction en anglais. AVANT D'EFFECTUER TOUT RETOUR AU MAGASIN. Chaque étape en français correspond à la même étape en Nous faisons de notre mieux pour nous assurer que votre meuble anglais.
  • Page 30 Ensuite, enfiler la cartouche interne de la GLISSIÈRE D'EXTENSION vers l'intérieur pour trouver les autres trous qui sont alignés sur les trous dans l'EXTRÉMITÉ. Faire tourner une VIS dans ces trous. REMARQUE : Les GRANDES COULISSES D'EXTENSION seront utilisées ultérieurement pour les TIROIRS. Page 30 www.sauder.com/service 423742...
  • Page 31 CADRE (V). Serrer cinq VIS TÊTE HEX 35 mm DORÉES (15) à l’ a ide de la Clé en L (11). Fixer l'ENTRETOISE (Z) au CADRE (V). Serrer deux VIS TÊTE HEX 22 mm DORÉES (16) à l’ a ide de la CLÉ EN L (11). 423742 www.sauder.com/service Page 31...
  • Page 32 Décoller les APPLIQUÉS de la FICHE D'APPLIQUÉS (10) et coller les sur chaque EXCENTRIQUE ESCAMOTABLE. REMARQUE : Prière de lire les informations importantes sur la sécurité figurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. Page 32 www.sauder.com/service 423742...
  • Page 33 (JUEGO DE EXTENSIÓN SE MUESTRA su referencia futura. Si POR SEPARADO) PANEL SUPERIOR GRANDE........1 necesita ponerse en contacto con Sauder en RIEL DE EXTENSIÓN GRANDE ......2 PARAL SUPERIOR ............1 cuanto a esta unidad, DORSO .................1 CORREDERA DE EXTENSIÓN GRANDE ...2 refiérase al número...
  • Page 34 EXTREMO. Atornille un TORNILLO dentro de estos agujeros. NOTA: Las CORREDERAS DE EXTENSIÓN GRANDES se utilizarán más tarde para los CAJONES. Page 34 www.sauder.com/service 423742...
  • Page 35 HEXAGONAL de 35 mm (15) utilizando la LLAVE EN L (11). Fije la RIOSTRA (Z) al MARCO (V). Apriete los dos TORNILLOS DORADOS DE CABEZA HEXAGONAL de 22 mm (16) utilizando la LLAVE EN L (11). 423742 www.sauder.com/service Page 35...
  • Page 36 EXCÉNTRICO ESCONDIDO visible. NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. Page 36 www.sauder.com/service 423742...
