Sauder 423731 Instruction Booklet

5-shelf bookcase with doors

Hide thumbs

page of 28

/ 28
Bookmarks

Quick Links

Download this manual

sauder.com

BEFORE MAKING ANY RETURNS TO THE STORE.

sauder.com/service

Visit

Prefer the phone? Give us a ring at

Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)

5-Shelf Bookcase

with Doors

Model 423731

Share your journey!

to order replacement parts, view video assembly tips, or chat with a live rep.

1-800-445-1527

Deep shelves for

tall tales.

NOTE: THIS INSTRUCTION

BOOKLET CONTAINS IMPORTANT

SAFETY INFORMATION.

PLEASE READ AND KEEP FOR

FUTURE REFERENCE.

English pg 1-18

Français pg 19-21

Español pg 22-24

Lot # 531892

Purchased: __________________

07/22/19

Need help?

Do you have a question about the 423731 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sauder 423731

Page 1 5-Shelf Bookcase NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. with Doors PLEASE READ AND KEEP FOR FUTURE REFERENCE. Model 423731 English pg 1-18 Français pg 19-21 Español pg 22-24 Share your journey! Lot # 531892 07/22/19 Purchased: __________________...
Page 2 UPPER END MOLDING (2) LOWER RIGHT END (1) DOOR (2) DOOR ADJUSTABLE SHELF (1) LOWER LEFT END (1) ADJUSTABLE SHELF MOLDING (2) LARGE BACK (1) TOP (1) VALANCE (1) SMALL BACK (1) BOTTOM (1) SHELF MOLDING (1) Page 2 www.sauder.com 423731...
Page 3 Part Identiﬁ cation 423731 www.sauder.com Page 3...
Page 4 APPLIQUE CARD - 4 TACK GLIDE - 4 BUMPER CARD - 1 SILVER 1-1/2" FLAT HEAD SCREW - 4 SILVER 11/16" MACHINE SCREW - 4 SILVER 1/2" PAN HEAD SCREW - 16 FURNITURE TIPPING RESTRAINT KIT - 1 Page 4 www.sauder.com 423731...
Page 5 D), TOP (E), BOTTOM (F), SHELF (G), and ADJUSTABLE SHELVES (H). (37 used) Arrow Arrow Arrow Arrow Hole Arrow The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. 423731 www.sauder.com Page 5...
Page 6 Turn thirty-seven CAM SCREWS (2) into the exact holes å shown in the ENDS (A, B, C, and D), SHELF (G), SHELF MOLDINGS (J and L), VALANCE (K), BASE (M), and UPPER END MOLDINGS (N). (37 used) Do not use the through holes. Page 6 www.sauder.com 423731...
Page 7 H I D i t h f a c S u r Edge with HIDDEN CAMS I D D u t H i t h o f a c S u r Edge with HIDDEN CAMS 423731 www.sauder.com Page 7...
Page 8 SILVER 1-1/2" FLAT HEAD SCREWS (10). Finished edge S u r f a c i t h H I D D E N Edge with HIDDEN CAMS SILVER 1-1/2" FLAT HEAD SCREW (4 used in this step) Page 8 www.sauder.com 423731...
Page 9 H I D D E N Edge with HIDDEN CAM I D D u t H i t h o f a c S u r Edge with HIDDEN CAMS 423731 www.sauder.com Page 9...
Page 10 Step 6 Fasten the LOWER ENDS (C and D) to the SHELF (G). å Tighten four HIDDEN CAMS. Just think. The sooner you do this, the sooner you do something else. Page 10 www.sauder.com 423731...
Page 11 (46 used in this step) Do not fasten NAILS along this edge until the LARGE BACK (P) is overlapping the SMALL BACK (Q). The LARGE BACK (P) will overlap the SMALL BACK (Q) along the SHELF (G). 423731 www.sauder.com Page 11...
Page 12 Fasten the SHELF MOLDING (L) to the SHELF (G). å Tighten three HIDDEN CAMS. Fasten the BASE (M) to the LOWER ENDS (C and D) and å BOTTOM (F). Tighten ﬁ ve HIDDEN CAMS. Curved edge Curved edge These surfaces should be even. Page 12 www.sauder.com 423731...
Page 13 Step 9 With your hammer, gently tap the TACK GLIDES (7) into the å bottom edges of the LOWER ENDS (C and D) and BASE (M). 423731 www.sauder.com Page 13...
Page 14 Fasten an ADJUSTABLE SHELF MOLDING (J) to one of å the ADJUSTABLE SHELVES (H). Tighten three HIDDEN CAMS. Repeat this step for the remaining ADJUSTABLE å SHELF (H) and ADJUSTABLE SHELF MOLDING (J). These surfaces should be even. Page 14 www.sauder.com 423731...
Page 15 O) onto the METAL PINS in the ENDS (A, B, C, and D). Peel the BUMPERS from the BUMPER CARD (8) and stick them å onto the center of the DOOR ADJUSTABLE SHELF (O). (12 used) 423731 www.sauder.com Page 15...
Page 16 Step 12 Fasten the HINGES (4) to the DOORS (I). Use eight å SILVER 1/2" PAN HEAD SCREWS (12). SILVER 1/2" PAN HEAD SCREW (8 used in this step) Page 16 www.sauder.com 423731...
Page 17 SILVER 1/2" PAN HEAD SCREWS (12). Fasten the PULLS (5) to the DOORS (I). Use four SILVER å 11/16" MACHINE SCREWS (11). SILVER 1/2" PAN HEAD SCREW (8 used in this step) SILVER 11/16" MACHINE SCREW (4 used in this step) 423731 www.sauder.com Page 17...
Page 18 Use the 5/8" screw through the small hole in a bracket and into the back edge of the TOP (E). Small hole No load 25 lbs. 25 lbs. 30 lbs. To cover HIDDEN CAMS 25 lbs. 40 lbs. Page 18 www.sauder.com 423731...
Page 19 Modèle 423731 Bibliothèque 5 tablettes avec portes Utilisez les instructions d’ a ssemblage en français avec les NOUS SOMMES LA POUR VOUS AIDER! schémas étape par étape du manuel d’instruction en anglais. Nous faisons de notre mieux pour nous assurer que votre meuble Chaque étape en français correspond à...
Page 20 Fixer la BASE (M) aux EXTRÉMITÉS INFÉRIEURES (C et D) et au Serrer quatre EXCENTRIQUES ESCAMOTABLES. DESSOUS (F). Serrer cinq EXCENTRIQUES ESCAMOTABLES. ÉTAPE 6 Fixer les EXTRÉMITÉS INFÉRIEURES (C et D) à la TABLETTE (G). Serrer quatre EXCENTRIQUES ESCAMOTABLES. Page 20 www.sauder.com 423731...
Page 21 TABLETTE RÉGLABLE DE PORTE (O). Ceci complète l'assemblage. Nettoyer avec un tissu humide. Essuyer. ÉTAPE 12 Fixer les CHARNIÈRES (4) aux PORTES (I). Utiliser huit VIS TÊTE GOUTTE DE SUIF 13 mm ARGENTÉES (12). 423731 www.sauder.com Page 21...
Page 22 EXCÉNTRICO ESCONDIDO ......37 su referencia futura. Si necesita ponerse en EXTREMO IZQUIERDO SUPERIOR ....1 BIELA DE EXCÉNTRICO ........37 contacto con Sauder en EXTREMO DERECHO INFERIOR .....1 ESPIGA DE METAL ..........12 cuanto a esta unidad, EXTREMO IZQUIERDO INFERIOR ....1 BISAGRA ................4 reﬁ...
Page 23 Fije la MOLDURA DE ESTANTE (L) al ESTANTE (G). Apriete tres PASO 5 EXCÉNTRICOS ESCONDIDOS. Fije los EXTREMOS INFERIORES (C y D) al FONDO (F). Apriete cuatro EXCÉNTRICOS ESCONDIDOS. PASO 6 Fije los EXTREMOS INFERIORES (C y D) al ESTANTE (G). Apriete cuatro EXCÉNTRICOS ESCONDIDOS. 423731 www.sauder.com Page 23...
Page 24 ESTANTE AJUSTABLE DE PUERTA (O). Esto completa el ensamblaje. Limpiar con un trapo húmedo. Seque con un paño. PASO 12 Fije las BISAGRAS (4) a las PUERTAS (I). Utilice ocho TORNILLOS PLATEADOS DE CABEZA REDONDA de 13 mm (12). Page 24 www.sauder.com 423731...
Page 25 Les téléviseurs peuvent être un téléviseur. cet eff et. particulièrement lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. 423731 www.sauder.com Page 25...
Page 26 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 26 www.sauder.com 423731...
Page 27 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
Page 28 Walmart.com in the product detail page. General Conformity Certiﬁ cate 1. This certiﬁ cate applies to the Sauder Global Sourcing Product identiﬁ ed by this Instruction Book. 2. This certiﬁ cate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
