CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
5-Shelf Bookcase
Model 423399
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-445-1527
.
The stories of your life.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-14
Français pg 15-17
Español pg 18-20
Lot # 530610
Purchased: __________________
06/24/19
Advertisement
Related Manuals for Sauder 423399
Summary of Contents for Sauder 423399
- Page 1 Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays) The stories of your life. 5-Shelf Bookcase NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Model 423399 PLEASE READ AND KEEP FOR FUTURE REFERENCE. English pg 1-14 Français pg 15-17 Español pg 18-20...
- Page 2 HIDDEN CAM - 46 CAM SCREW - 46 METAL PIN - 12 TACK GLIDE - 4 CAM COVER - 18 FURNITURE TIPPING RESTRAINT KIT - 1 NAIL - 46 SILVER 1-1/2" FLAT HEAD SCREW - 4 Page 2 www.sauder.com 423399...
- Page 3 LOWER LEFT END (1) TOP (1) BOTTOM (1) SHELF (1) ADJUSTABLE SHELF (3) ADJUSTABLE SHELF MOLDING (3) VALANCE (1) SHELF MOLDING (1) BASE (1) UPPER END MOLDING (2) LOWER END MOLDING (2) LARGE BACK (1) SMALL BACK (1) 423399 www.sauder.com Page 3...
- Page 4 ENDS (A, B, C, and D), TOP (E), BOTTOM (F), SHELF (G), and ADJUSTABLE SHELVES (H). Arrow (46 used) Arrow Arrow Arrow Hole The arrow in the HIDDEN CAM must point toward the Arrow hole in the edge of the board. Page 4 www.sauder.com 423399...
- Page 5 Step Step 2 Turn forty-six CAM SCREWS (2) into the ENDS (A, B, C, å and D), SHELF (G), SHELF MOLDINGS (J and L), VALANCE (K), BASE (M), and END MOLDINGS (N and O). 423399 www.sauder.com Page 5...
- Page 6 H I D i t h f a c S u r Edge with HIDDEN CAMS I D D u t H i t h o f a c S u r Edge with HIDDEN CAMS Page 6 www.sauder.com 423399...
- Page 7 SILVER 1-1/2" FLAT HEAD SCREWS (11). S u r f a c i t h H I D D E N Edge with HIDDEN CAMS SILVER 1-1/2" FLAT HEAD SCREW (4 used in this step) 423399 www.sauder.com Page 7...
- Page 8 HIDDEN CAMS S u r f a c i t h H I D D E N I D D u t H i t h o f a c S u r Edge with HIDDEN CAMS Page 8 www.sauder.com 423399...
- Page 9 (46 used in this step) Do not fasten NAILS along this edge until the LARGE BACK (P) is overlapping the SMALL BACK (Q). The LARGE BACK (P) will overlap the SMALL BACK (Q) along the SHELF (G). 423399 www.sauder.com Page 9...
- Page 10 Fasten the VALANCE (K) to the TOP (E) and UPPER å ENDS (A and B). Tighten fi ve HIDDEN CAMS. Fasten the UPPER END MOLDINGS (N) to the UPPER å ENDS (A and B). Tighten six HIDDEN CAMS. These surfaces should be even. Page 10 www.sauder.com 423399...
- Page 11 Fasten the SHELF MOLDING (L) to the SHELF (G). å Tighten three HIDDEN CAMS. Fasten the LOWER END MOLDINGS (O) to the LOWER å ENDS (C and D). Tighten six HIDDEN CAMS. These surfaces should be even. These surfaces should be even. 423399 www.sauder.com Page 11...
- Page 12 If you're doing this to help a friend, don't With your hammer, gently tap the TACK GLIDES (4) into the å leave without a bite. bottom edges of the LOWER ENDS (C and D) and BASE (M). Page 12 www.sauder.com 423399...
- Page 13 Using your hammer, gently tap a CAM COVER (5) onto each visible HIDDEN CAM in the ENDS (A, B, C, and D). å Use the 5/8" screw through the small hole in a bracket and into the back edge of the TOP (A). Small hole (18 used) To cover HIDDEN CAMS (12 used) 423399 www.sauder.com Page 13...
- Page 14 This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. å And to celebrate, why not share your success story at walmart.com or No load 25 lbs. These surfaces should be even. 25 lbs. 30 lbs. 25 lbs. 40 lbs. Page 14 www.sauder.com 423399...
- Page 15 Modèle 423399 Bibliothèque avec 5 tablettes Utilisez les instructions d’ a ssemblage en français avec les NOUS CONTACTER EN PREMIER schémas étape par étape du manuel d’instruction en anglais. AVANT D'EFFECTUER TOUT RETOUR AU MAGASIN. Chaque étape en français correspond à la même étape en Nous faisons de notre mieux pour nous assurer que votre meuble anglais.
- Page 16 Répéter cette étape pour le GRAND ARRIÈRE (P). ÉTAPE 4 REMARQUE : Le GRAND ARRIÈRE (P) va chevaucher le PETIT ARRIÈRE (Q). Fixer la TABLETTE (G) aux EXTRÉMITÉS SUPÉRIEURES (A et B). Utiliser quatre VIS TÊTE PLATE 38 mm ARGENTÉES (11). Page 16 www.sauder.com 423399...
- Page 17 REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. 423399 www.sauder.com Page 17...
- Page 18 EXCÉNTRICO ESCONDIDO ......46 su referencia futura. Si necesita ponerse en EXTREMO IZQUIERDO SUPERIOR ....1 BIELA DE EXCÉNTRICO ........46 contacto con Sauder en EXTREMO DERECHO INFERIOR .....1 ESPIGA DE METAL ..........12 cuanto a esta unidad, EXTREMO IZQUIERDO INFERIOR ....1 TACHUELA DESLIZANTE ........4 refi...
- Page 19 PASO 4 NOTA: El DORSO GRANDE (P) se solapará con el DORSO PEQUEÑO (Q). Fije el ESTANTE (G) a los EXTREMOS SUPERIORES (A y B). Utilice cuatro TORNILLOS PLATEADOS DE CABEZA PERDIDA de 38 mm (11). 423399 www.sauder.com Page 19...
- Page 20 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 20 www.sauder.com 423399...
- Page 21 Les téléviseurs peuvent être un téléviseur. cet eff et. particulièrement lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. 423399 www.sauder.com Page 21...
- Page 22 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 22 www.sauder.com 423399...
- Page 23 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
- Page 24 Walmart.com in the product detail page. General Conformity Certifi cate 1. This certifi cate applies to the Sauder Global Sourcing Product identifi ed by this Instruction Book. 2. This certifi cate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
