3
WIRING CAMERA
AND TESTING
1. Press and hold the orange tabs, then insert one
end of the provided motor connection wire into
the connectors. Each strand can connect to any
connector.
2. On the garage door opener, locate the terminals
that wire to the wall control. Twist each wire strand
to the motor connection wire, then connect the paired
strands back to their original terminal.
Wall Control Wire
5
Motor Connection Wire
Make sure the paired strands are properly
connected to their original terminal.
If you haven't connected to the wall control,
check your garage door opener's user manual for
wall control wiring instructions to locate the right
terminals.
Model T8453 can wire up to 2 garage doors.
Follow the steps above to wire the camera to the
other garage door opener.
Garage Door Opener 1 Garage Door Opener 2
6
