Polar Star Special Edition Series
Ceiling/Ambient Light Rejecting (CLR®/ALR) Fixed Frame Screen
Product Description
The Polar Star® Special Edition Series is a fixed frame projection screen from EPV Screens. It has a
hand wrapped velvet covered frame and a tension system for attaching the material for improved flatness.
The screen material included is our award winning ISF Certified Polar Star® which is a front projection
material, precisely formulated for environments with minimal control over room lighting. It was designed
to enhance picture brightness, offer accurate color fidelity, and improve contrast levels. The Polar
Star® is best for family rooms, educational facilities, conference rooms, house of worship or any
applications in which incident light is a factor.
In order for the Polar Star® to maintain its projection qualities and optimum performance please refer to the list
below for proper maintenance and cleaning.
•
Use a dry microfiber cloth to remove dust from the screen's surface.
•
When cleaning, use a damp microfiber cloth with warm water to remove any marks.
•
Never rub or apply pressure when cleaning the surface.
•
Never attempt to use any solutions, chemicals or abrasive cleaners on the screen surface.
•
In order to avoid damaging the screen, avoid touching it directly with your fingers, pens/pencils or any
other sharp or abrasive objects.
JA12132021
USER'S GUIDE
V 2.1
www.epvscreens.com
U-00222
