SmartLock UNRD Series Installation Manual

Installation Guide
Model Type Code: UNRD
Visit www.smartlockfitting.com for video guide
! CAUTION
1. CLOSELY FOLLOW INSTALLATION GUIDE TO PREVENT ANY
INSTALLATION MISTAKES.
2. DO NOT REMOVE POSITIONING STRIP PRIOR TO ASSEMBLY.
3. DO NOT REUSE FITTING.
4. DO NOT USE TUBE WITH DAMAGES 2 INCHES FROM THE
TUBE END.
5. DO NOT BEND TUBE AFTER CONNECTION IS MADE.
6. DO NOT USE OTHER THAN FOR INTENDED PURPOSE.

Larger Tube

Larger Nut

P ace the Marking Gauge over the Tube,
1
using the guideline. Mark a line on the
Larger Tube
Insert the Larger Tube into the
2
Larger Nut until the Tube stops.
1
3
Ensure the marked line is visible on
the Larger Tube.
4
Remove the Larger Positioning Strip.
Union Reducer
214-304-2083
sales@smartlockfitting.com
www.smartlockfitting.com

Marking Gauge

Larger Positioning Strip

Body

and the Smaller Tube .
1
*Must start with the Larger Tube.
1
Smaller Positioning Strip

Smaller Nut

1
2

Smaller Tube

2
