SNOWJOE Sunjoe SWJ801E-SJB Operator's Manual page 5

Know Your Electric Pole Chain Saw
Read the owner's manual and safety instructions carefully before operating the pole chain saw. Compare the illustration below
to the pole chain saw in order to familiarize yourself with the location of the various controls and adjustments. Save this manual
for future reference.
THE BACK SIDE OF THE HANDLE
8 7
9
11
10
Technical Data
Rated Voltage
Power
Bar/Chain Length
Telescopic Shaft
4
5
6
1. 8 in. guide bar
2. 8 in. cutting chain
3. Oil tank cap
4. Telescoping cam-lock
5. Soft grip
6. Telescopic pole
7. On/Off switch
8. Safety lock button
120 V ~ 60 Hz
7 A
8 in. (20.3 cm)
5.6 ft to 8.7 ft
(1.7 m to 2.7 m)
Overhead Reach
Cutting Thickness
Oil Tank Capacity
Weight
5
2
3
13
12
9. Handle
10. Appliance cord
11. Extension cord restraint hook
12. Hex key allen wrench + blade
screwdriver
13. Bar sheath
14. Sprocket cover
15. Sprocket cover bolt
15 ft (4.6 m)
Max: 7.5 in. (19 cm)
Recommended: 6.5 in. (16.5 cm)
2.0 fl oz (60 ml)
7 lbs (3.2 kg)
1
15
14
