- Page 1 Alternative Wood Blinds Collection Simple Cordless with Tilt Automation III Installation Instructions Rev. B 5/3/22...
-
Page 2: Table Of Contents
GETTING STARTED CONTENTS GETTING STARTED ............................3 Product View - Simple Cordless with Automation III ..................3 Tools and Fasteners Needed ..........................4 Unpack the Blind ..............................4 INSTALLATION ..............................5 Installation Overview .............................. 5 Mounting Types and Window Terminology ......................5 STEP 1 —... -
Page 3: Getting Started
GETTING STARTED Product View - Simple Cordless with Automation III Valance End Bracket Spacer Block Power Intermediate Bracket Cable Bracket Spacer Block Intermediate Bracket Transceiver (If Required) Assembly Control 2" or 4" Button 12V Battery Extension Wand Brackets (Optional) Headrail Bracket Shim (Optional) Valance Splice (If Required) -
Page 4: Tools And Fasteners Needed
® Thank you for purchasing the Kirsch Alternative Wood Blinds Collection. With proper installation, operation, and care, your new blinds will provide years of beauty and performance. Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation. -
Page 5: Installation
INSTALLATION INSTALLATION Installation Overview Two end brackets are used to mount horizontal blinds. Wider blinds also require one or two ■ intermediate brackets, as shown in the tables below. Intermediate Bracket Chart Intermediate Bracket Bracket Intermediate Width of Blind Brackets Up to 48"... -
Page 6: Attach The End Brackets
INSTALLATION INSTALLATION Attach the End Brackets With inside or ceiling mounts, attach the two end brackets flush against the sides of the window casement or to the ceiling. Choose the most appropriate of the following ■ mounting methods: Side/Top Mount (Inside mount only): Mount the ➤... -
Page 7: Mount The Installation Brackets - Outside Mount
INSTALLATION INSTALLATION Mount the Installation Brackets — Outside Mount Mark To attach the end brackets, a flat vertical surface of at least 1¾" is required. Mark the End Bracket Locations Mark where the ends of the headrail will be located. ■... -
Page 8: Step 2 - Connect The Power Cable, If Applicable
INSTALLATION INSTALLATION ", 2", and 2 " Slat Sizes Extension Brackets (Optional) Attach 2" or 4" extension brackets to the mounting surface in the same locations where the end brackets would be attached. Use the provided screws to mount each extension ■... -
Page 9: Step 3 - Install The Blind
INSTALLATION INSTALLATION STEP 3 — Install the Blind Adding Projection for the Valance The magnetic valance clips have a projection adjustment feature. The clips offer two projection positions. When the clips are fully compressed, the narrowest projection is ⁄ ”. The widest projection is ⁄... - Page 10 INSTALLATION INSTALLATION Attach the Corner Clips (If Required) Miters Meet If the valance came with returns, connect the returns to the valance using the corner clips provided. Valance Notch The notches on the rear of the valance and returns fit into the grooves of the corner clips. ■...
-
Page 11: Step 4 - Connect The Power Source, If Applicable
INSTALLATION INSTALLATION Open the End Brackets (If Necessary) To open the end brackets, insert a flat blade screwdriver between the bottom of the cover and the quick ■ release tab, and twist. You can also push up on the bottom of the end bracket to release the locking tab. ➤... - Page 12 INSTALLATION INSTALLATION Rechargeable Battery Wand Install the Rechargeable Battery Mount Decide where you want to install the rechargeable battery mount. This may be mounted behind the headrail, or in any desired ■ location near the window covering. A satellite battery mount may be installed in any orientation. Make sure the provided cable is long enough to connect the satellite battery mount and the blind.
- Page 13 INSTALLATION INSTALLATION 18V DC Power Supply Power cable NOTE: When power is connected to the motor, a blue LED inside the control button housing from blind motor will flash to indicate the blind is ready for operation. Plug the power cable from the blind motor into the extension cable. ■...
-
Page 14: Attach The Valance With Magnetic Valance Clips To The Headrail
INSTALLATION INSTALLATION Attach the Valance with Magnetic Valance Clips Align the valance to the headrail. ■ Hold the valance securely from the front side with both hands. ■ Position the clips to the top-front lip of the headrail until it is level and in position. ■... -
Page 15: Attach The Simple Cordless Hold-Down Brackets
INSTALLATION INSTALLATION Attach the Simple Cordless Hold-Down Brackets Lower the blind and place the pins from the hold-down brackets into the bottom rail end caps. ■ Mark the screw holes on the mounting surface. ■ Check that the hold-down brackets are aligned and attach them using the two screws provided. ■... -
Page 16: Operating The Automation App And Automation Iii Remote
The Automation App is required to program Automation III shades, remotes, and gateways. The App is compatible with Apple® and Android™ smartphones and tablets. For more information regarding setup and operation using the Automation App, refer to https://www.kirsch.com/window-coverings-product-manuals. Automation III Gateway The Automation III Gateway is used to control shades in larger projects as well as integrate Automation III shades with third- party integration systems. -
Page 17: Troubleshooting
Wand Install the batteries according to the instructions on the battery wand label. Press the cap on until it latches. NOTE: Kirsch recommends AA alkaline batteries for use with our battery- Latch Squeeze powered blinds. These will provide more than one year operation, depending on usage. - Page 18 There are two methods for charging the rechargeable battery wand — the dual charging station or the single charger. CAUTION: Rechargeable battery wand can only be charged with Kirsch provided charging options — alternative charging devices may result in permanent damage.
- Page 19 INSTALLATION TROUBLESHOOTING Problem The blind does not operate using the control button. Solution Unplug the power cable from the motor, then plug it back in. A blue LED light inside the control button housing should flash to indicate the motor has power. Check that the batteries in the battery wand, satellite battery wand, or C-size satellite battery wand are correctly inserted and fresh.
-
Page 20: Care
■ Cleaning Procedures Like any fine furnishings, Kirsch Alternative Wood Blinds Collection should be cleaned regularly to keep them looking new. ® Recommended Cleaning Methods Dust regularly. Use a soft clean cloth, chemically-treated dust cloth, or dusting mitt. Lower the blind to its full length, tilt the ■... -
Page 21: Child Safety
INSTALLATION CHILD SAFETY... -
Page 22: Declarations
Kirsh®, One Duette Way, Broomfield, CO 80020, USA Kirsch hereby declares that the PV40 is in compliance with the essential requirements and other relevant provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU and Radio Equipment Directive (RED) 2014/53/EU. A copy of the DoC can be obtained online:... -
Page 23: Warranty
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. © 2020 Kirsch Custom Window Coverings. All rights reserved. All trademarks used herein are the property of Kirsch or their respective owners. 07/20...
