- Page 1 MOVING WASH STROBE USER MANUAL...
-
Page 2: Safety Instructions
STATEMENT The product has well capability and intact packing when leave factory. All of the users should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also cannot be responsible for any malfunction & problem owing to ignore the manual. -
Page 3: Installation
Please contact the nearest authorized technical assistance center. Always use the same type of spare parts. DO NOT touch any wire during operation as high voltage might be causing electric shock. - Page 4 PMMA high quality and high output optic Power Consumption: 700w Power Voltage: AC 100-260V, 50/60Hz Control DMX Channel:34/54 Channels Control Protocol: DMX512/RDM Pan/Tilt Pan / Tilt : Infinite Rotation Pan/Tilt Resolution: 8/16 bit Magnetic coded reset system is adopted Construction Display:2.4 inch 180°reversible colorful TFT Display...
-
Page 5: Display & Menu
4. DISPLAY & MENU Display: MENU To select the programming functions DOWN To go backward in the selected functions UP To go forward in the selected functions ENTER To confirm the selected functions Set DMX Address Code 1 Press "Menu" to "Set DMX Address", and press "ENTER" keys to enter 2 Show "Set DMX Address DMX Address:001", Press the "UP and... - Page 6 0 - 255 Tilt 0 - 255 Focus 0 - 255 0 - 255 Green 0 - 255 Blue 0 - 255 White 0 - 255 Address Setting from 001 - 512 1.Yes 2.No 1.Yes 2.No Tilt Forward or 1.Yes...
-
Page 7: Dmx Channel List
Strobe1： 0--255 Red2：0-- Greed2： 0--255 Blue2：0- White2:0-- Strobe2:0- Alone 45 channels channel mode 25 channels channel Channel mode Channel 5. DMX CHANNEL LIST Model 1 - CH54 Channel Function Description Value CH-1 Pan adjustment 0 --- 255 CH-2 Pan fine... - Page 8 Strobe from fast to slow 16--214 Random strobe 215--225 CH-9 Dimmer From dark to bright 0-255 Model - 1 0 --- 49 Model - 2 50 --- 99 Model - 3 100--- 149 Model - 4 150--- 255 CH-10...
- Page 9 R down,G 100%,B0% 36----55 R 0%,G 100%,B up 56----75 R 0%,G100%,B up 76----95 R up,G0%,B100% 96----115 R 100%,G0%,B down 116----135 R 100%,G up,B up 136----155 R100%,G down,B100% 156----175 R100%,G 176----195 100%,B100%,W100% 2800K 196----200 3200K 201----205 3500K 206----210 4000K 211----215...
- Page 10 Static Pattern -10 90 --- 99 Static Pattern -11 100--- 109 Static Pattern -12 110--- 119 Static Pattern -13 120--- 129 Static Pattern -14 130--- 139 Static Pattern -15 140--- 149 Static Pattern -16 150--- 159 Dynamic Pattern -1...
- Page 11 Dynamic pattern 16 160--255 CH-52 Patterns Select pattern scene 0--255 translation (work with CH Pattern auto No function 0--9 run speed forward run fast to slow 10--132 (work with CH Reverse run slow to fast 133--255 CH-53 No function...
- Page 12 CH-11 Zoom Angle from big to small 0 --- 255 CH-12 CH-13 Green CH-14 Blue 6*60w CH-15 White wash face From dark to bright 0 --- 255 No function 0----15 R 100%,G up,B0% 16----35 R down,G 100%,B0% 36----55 R 0%,G 100%,B up...
- Page 13 Pattern -3 30 --- 39 Pattern -4 40 --- 49 Pattern -5 50 --- 59 Pattern -6 60 --- 69 Pattern -7 70 --- 79 Pattern-8 80 --- 89 Pattern -9 90 --- 99 Pattern -10 100 --- 109...
- Page 14 Forward run from fast to 10--132 Pattern auto run slow speed(w ork Reverse fun from slow to fast 133-255 with CH31) No function 0 --- 79 Reset 80 --- 99 100 --- 255 CH-34 Reset 6. Shape 7. Trouble shooting Following are a few common problems that may occur during оperation.
- Page 15 2. Measure the mains voltage on the main connector. 3. Check the power on LED. B. Not responding to DMX controller 1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly. 2. If the DMX LED is on and no response to the channel, check the address settings and DMX polarity.
