- Page 1 Wedge Interface Guide Decision Data Series...
- Page 2 The information contained herein is proprietary and is provided solely for the purpose of allowing customers to operate and/or service Intermec manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Intermec.
- Page 3 Decision Data Series Wedge Interface Guide This guide covers these workstations: Decision Data 3596 HP 700/32 Decision Data 3597 HP 700/43 Decision Data 3697...
-
Page 4: Power Supply
HP 700/92 HP 700/94 HP 700/96 Workstation Power supply and jumper setting Decision Data 3596 The reader requires an external power supply to Decision Data 3597 work with these workstations. Set the PCB HP 700/32 jumper to connect pins 2 and 3 on the reader’s HP 700/44 rear panel. -
Page 5: Configuring The Reader
If the reader emits a different beep sequence, refer to the Wedge Reader User’s Manual, Section 2, for beeper identification. To set workstation configuration to: Decision Data 3596, 3597, 3697 83-Key Keyboard Decision Data 3596, 3597, 3697 102-Key Keyboard Decision Data 3596, 3597, 3697... - Page 6 Wedge Interface Guide To set workstation configuration to: HP 700/32 ANSI US Keyboard HP 700/32 ANSI French Keyboard HP 700/32 ANSI German Keyboard HP 700/32 ANSI Italian Keyboard HP 700/32 ANSI Spanish Keyboard HP 700/43 US Keyboard HP 700/43 Canadian/French Canadian Keyboard Scan this label: *$+TA413*...
- Page 7 To set workstation configuration to: HP 700/43 Danish Keyboard HP 700/43 Dutch Keyboard HP 700/43 Finnish/Swedish Keyboard HP 700/43 Flemish/French Keyboard HP 700/43 German Keyboard HP 700/43 Latin American Keyboard HP 700/43 Norwegian Keyboard Decision Data Series Scan this label: *$+TA336* *$+TA336* *$+TA342*...
- Page 8 Wedge Interface Guide To set workstation configuration to: HP 700/43 Spanish Keyboard HP 700/43 Swiss (French/German) Keyboard HP 700/43 UK Keyboard HP 700/44 US Keyboard HP 700/44 French Keyboard HP 700/44 German Keyboard HP 700/44 Italian Keyboard Scan this label: *$+TA340* *$+TA340* *$+TA337*...
- Page 9 To set workstation configuration to: HP 700/44 Spanish Keyboard HP 700/60 ANSI US Keyboard HP 700/60 PC US Keyboard HP 700/60 ANSI French Keyboard HP 700/60 PC French Keyboard HP 700/60 ANSI German Keyboard HP 700/60 PC German Keyboard Decision Data Series Scan this label: *$+TA427* *$+TA427*...
- Page 10 Wedge Interface Guide To set workstation configuration to: HP 700/60 ANSI Italian Keyboard HP 700/60 PC Italian Keyboard HP 700/60 ANSI Spanish Keyboard HP 700/60 PC Spanish Keyboard HP 700/92, 700/94, 700/96, 700/98 US Keyboard HP 700/92, 700/94, 700/98 Canadian/French Canadian Keyboard HP 700/92, 700/94, 700/98 Danish/Norwegian Keyboard...
- Page 11 To set workstation configuration to: HP 700/92, 700/94, 700/98 Dutch Keyboard HP 700/92, 700/94, 700/98 Finnish/UK Keyboard HP 700/92, 700/94, 700/96, 700/98 Flemish/French Keyboard HP 700/92, 700/94, 700/98 German Keyboard HP 700/92, 700/94, 700/98 Italian Keyboard HP 700/92, 700/94, 700/98 Latin American Keyboard HP 700/92, 700/94, 700/96, 700/98 Spanish Keyboard...
- Page 12 Wedge Interface Guide To set workstation configuration to: HP 700/92, 700/94, 700/98 Swedish Keyboard HP 700/92, 700/94, 700/98 Swiss (French/German) Keyboard HP 700/96 German Keyboard HP 700/96 Italian Keyboard Scan this label: *$+TA355* *$+TA355* *$+TA353* *$+TA353* *$+TA499* *$+TA499* *$+TA500* *$+TA500*...
- Page 13 Keyboard Equivalent Tables Several HP workstations use special keyboard mapping: • HP 700/43, 700/92, 700/96, and 700/98 use the map on the next page. • HP 700/32 uses standard ASCII mapping (Table A-3, Wedge Reader User’s Manual). • HP 700/44 uses standard PC mapping (Table A-1, Wedge Reader User’s Manual).
- Page 14 Wedge Interface Guide HP 700/43, HP 700/92, 700/96, and HP 700/98 Keyboard Mapping ASCII Character Keystroke + Num Left Enter Left Extend Char/ Scroll Lock - Num Ins Char Del Char Ins Line Del Line Scroll Down →⎪ (tab) Caps Lock ⎪←...
- Page 15 blank...
- Page 16 Corporate Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com Decision Data Series Wedge Interface Guide *054288-003* P/N 054288-003...
