Kenmore Go CSV DS4020 Use & Care Manual page 14

EMPTYIN G DUST CUP AN D CLEAN IN G FILTER
2. Remove the HEPA filter and pre-filter
basket from the dust cup.
HEPA Filter
Pre-filter Basket
Dust Cup
3. Brush loose debris from HEPA filter and
pre-filter basket and then rinse with
warm water. Set both filters aside and
allow to air dry for 24 hours.
IMPORTAN T:
filter must dry completely before reuse.
4. Place the pre-filter basket back into the
dust cup, then place the HEPA filter back
into the pre-filter basket.
The HEPA filter and pre-
5. To reassemble the dust cup to the hand
vacuum, align the tabs on the dust cup
with slots in the hand vacuum. O nce
aligned, attach the dust cup to the hand
vacuum until you hear a click.
- 14 -
