CLEAN IN G THE MOTORIZED N OZZLE & BLOCKAGES
The brush roll may accumulate debris
such as strings, hair and fibers. This type
of debris can wrap around the brush and
diminish its ability to clean effectively.
CAUTION
Risk of injury. Brush may start
unexpectedly. Disconnect pow er nozzle
from w and before cleaning or servicing.
Brush Roll Manual Cleaning
1. M ake sure the vacuum cleaner is turned
off. Remove the wand and the hand
vacuum from the motorized nozzle and
set aside.
2. Turn the nozzle over to access the brush
roll. As shown below, press and push the
tab on the left hand side of the nozzle
to the left and hold it. This will unlock
the brush roll.
3. W ith the tab pushed to the left, simply
lift the brush roll out of the nozzle
housing. Clean off debris and anything
wrapped around the brush roll. Use a
pair of scissors to remove threads, etc.
4. Place the brush roll back into the
housing by aligning the hexagon end of
the brush roll into the right end of the
nozzle. Then push the unlock tab to the
left and hold it. Align the square end
of the brush roll with the left end of the
nozzle and insert it into place. Release
the tab to lock the brush roll.
Brush Roll Reset
If the brush roll is blocked or overloaded,
the unit will automatically stop power.
Switch the unit off and remove the
obstruction.
Hose Blockage Removal
1. To clean out the hose, press the wand
release button on the motorized nozzle,
and pull the motorized nozzle away
from the wand.
W and Release Button
- 15 -
