Specifications

For the more technical-minded, here are some detailed
specifications for the MultiMix's operating levels.
Input Channels
Mic In Sensitivity Range:
Line In Sensitivity Range:
Mic / Line Gain Range:
Equalization
High Shelving:
Mid Bandpass/Band Reject: 2.5kHz, +/-15dB
Low Shelving:
Aux Send
Aux Send Gain Range:
Aux Returns
Aux Return:
Effects Level Gain Range:
Channel Levels
Channel Level Gain Range: -∞ to +10dB
Master Levels
Main Mix, Ctrl Room Gain
Range:
1/4" Inputs
Stereo Aux Return Level:
SERVICE MANUAL
-60dBu to -10dBu nominal, +5dBu
maximum
-40dBu to -10dBu nominal,+25dBu
maximum
+10 to +60dB
12kHz, +/-15dB
80Hz, +/-15dB
-∞ to +10dB
-∞ to +15dB
-∞ to +15dB
-∞ to +10dB
+4dBu nominal,+20dBu maximum
MODEL:MULTIMIX 6 FX
RCA Inputs
Tape In Level: -10dBV nominal, +5dBV maximum
1/4" Outputs
Main Mix, Ctrl Room,
Ext Aux Send Level: +4dBu nominal, +20dBu maximum
Headphone Output: 75 ohm output impedance
>105mW into 75 ohms,>40mW
into 600ohms
RCA Outputs
Tape Out Level: -10dBV nominal, +5dBV maximum

MultiMix-6FX Key Features

• 2 microphone/line inputs with up to 50dB of preamp
gain-gives a boost to microphones and instruments with
weak levels.
• 2 stereo line inputs-great for line-level instruments
• Internal digital effects processor with 100 preset
effects and an easy-to-read display–includes a variety
of reverbs, delays, choruses, flanges, a pitch transposer
and combinations of these.
• 3-band EQ per channel – a potent tool for sonically
shaping each channel to get that perfect mix.
• 1 post-fader aux send/effects send per channel - a
control for the signal being routed to an external device
or to the onboard effects processor.
