  • Page 1 DES-1100-10MP ANUAL MART WITCH V1.0...

  • Page 2: Table Of Contents

    D-Link Web Smart Switch User Manual Table of Content Getting Started..................3 WEB Configuration..................4 Home...........................4 System........................5 Power Over Ethernet....................6 LED Power Saving......................8 Fundamentals......................9 Security........................19 Statistics........................20 Advanced........................21 Product Specification................25 External Interfaces...................25 Port Functions....................25 PoE Functions....................25 Push Button.....................26 Power Supply –External Adaptor..............26...

  • Page 3: Getting Started

    D-Link Web Smart Switch User Manual Getting Started Fig. Front panel of DES-1100-06MP Power on the Switch:  Power on the Switch before plug in any Ethernet cable, system will go through Power-On-Self-Test (POST) with LEDs lighting in Green or Amber. Then, after completing the POST, LEDs will stay at the state as the table below..

  • Page 4: Web Configuration

    D-Link Web Smart Switch User Manual WEB Configuration Home Fig. Web page of “Home” “Home -> System Information”, “Home -> POE Configuration” and  “Home -> Basic Configuration” expose most of the important information which Installer or Network Administrator may need for realizing the status and configuration in a quick glance.

  • Page 5: System

    D-Link Web Smart Switch User Manual System In this page, user can re-set the IP address of this Switch device. Also you can give  your Switch an easily-remembered name in “System”-> “System Configuration”-> “Description”. In “System”-> “System Configuration”-> “Web Configuration”, set “Idle ...

  • Page 6: Power Over Ethernet

    D-Link Web Smart Switch User Manual Power Over Ethernet “Power Over Ethernet ” -> “POE Configuration” -> “System Level“ ->  “System PoE Operation” Disable and Apply will stop all POE activity of this Switch device. Default of “System PoE Operation” is Enable (of course, this is a POE Switch, isn’t it?) “Power Over Ethernet ”...
  • Page 7 D-Link Web Smart Switch User Manual decision. The smaller the port number is, the higher the priority is. For instance, port 1 and port2 share the same priority “middle”, port1 priority will be higher than port2. Default setting here applies the same priority to every port, meaning port1...
  • Page 8 D-Link Web Smart Switch User Manual Power Over Ethernet Enable “Power Over Ethernet ” -> “POE Power Delay” -> “ PoE Powering  Timer Delay” -> “Delay” and set “Powering delay time” will postpone the port to feed power to PD. At most, a port can delay 300 seconds before its...

  • Page 9: Led Power Saving

    D-Link Web Smart Switch User Manual LED Power Saving User can turn on or turn off LEDs of the front panel, except POWER LED. This  green feature helps energy saving. If user sets “off”, meaning the LEDs of the front panel are turned off. However, in the WEB GUI, user still can see the LED lighting reflecting the real network connection.

  • Page 10: Fundamentals

    D-Link Web Smart Switch User Manual Fundamentals In general application, these parameters are automatically negotiated between  Switch and Client via IEEE802.3 standard. Note that Disable “Fundamentals” -> “Port ” -> “Port Configuration” ->  “Link” will only disable the data path of that port. No impact on POE function. If user wants to disable POE function, go to “Power Over Ethernet”...
  • Page 11 D-Link Web Smart Switch User Manual Fundamentals “Fundamentals” -> “VLAN ” ->“VLAN Mode ” can select one of the three  VLAN modes. They are “Port Base VLAN”, “Tag Base VLAN”, and “IP Surveillane VLAN”. Default VLAN mode is Port Base.
  • Page 12 D-Link Web Smart Switch User Manual Fundamentals Default VLAN mode is Port Base. Click “VLAN ” ->“ Port Base ” to complete  other settings. What is Port Base VLAN?  Ports that are assigned to a VLAN group will send and receive broadcast and multicast traffic within this virtual LAN only.
  • Page 13 D-Link Web Smart Switch User Manual Fundamentals What is Tag Base VLAN  VLAN membership in a tagged VLAN is determined by information within the frames that are received on a port. The VLAN information within an Ethernet frame is referred to as a tag which contains the VID (VLAN ID). When the switch receives a frame with a VLAN tag, referred to as a tagged frame, the switch forwards the frame only to those ports that share the same VID.
  • Page 14 D-Link Web Smart Switch User Manual Fundamentals What is IP Surveillance Base VLAN?  Enable IP Surveillance VLAN, the port 01 ~ port 04 video stream can be carried only to the Destination port 05 or 06 individually. Source port (port 01~04) is not allowed to communicate to each other.
  • Page 15 D-Link Web Smart Switch User Manual Fundamentals “Fundamentals” -> “QoS” ->”Priority Queue Configuration” -> ”First-In-  First-Out”: The first packet put into the queue will be firstly switched out. “Fundamentals” -> “QoS” ->”Priority Queue Configuration” -> “All-High-  Before-Low” After all packets in the high-priority queue are switched out, packet in the low- queue can be then processed.
  • Page 16 D-Link Web Smart Switch User Manual Fundamentals “Fundamentals” -> “QoS” -> “CoS Setting (Port, 802.1p, IP TOS/DS)”  This Switch provides 2 priority queues, High and Low, for packet store-and- forward. This Switch provides 3 types of Class of Service, Port based, 802.1p based, and IP TOS/DS Based.
  • Page 17 D-Link Web Smart Switch User Manual Fundamentals Note, the port in Blocked mode (loop is detected) will also be “Disabled”. If “Auto Recover Function” is NOT enabled, meaning user needs to “manually” enable the port. Go page “Fundamental” -> “Port” -> “Port Configuration“ to enable the port.
  • Page 18 D-Link Web Smart Switch User Manual If user wants to enable “Auto Recover Function”, user can also set “Recover  Time ” which is the time interval before the blocked port is re-activated. (In case the port was in blocked state caused by loop condition.)
  • Page 19 D-Link Web Smart Switch User Manual Fundamentals “Fundamentals” -> “Loop Free” -> “STP”  Refer to “http://en.wikipedia.org/wiki/Spanning_Tree_Protocol” for STP protocol detail.
  • Page 20 D-Link Web Smart Switch User Manual Fundamentals Note that, in one Link Group, if any counter port of link partner does not support LACP, or LACP handshake does not success on the specific member port, packet won’t be transmitted or received at that port.
  • Page 21 D-Link Web Smart Switch User Manual “Fundamentals” -> “Trunking” -> “Activity”  “Active” LACP port is capable of processing and sending LACP control frames. This allows LACP compliant devices to negotiate the aggregated link so the group may be changed dynamically as needs require. “Passive” LACP port cannot...

  • Page 22: Security

    D-Link Web Smart Switch User Manual Security Change “Security” -> “Administrator” -> “Username” “Password” for  logging into WEB GUI will take effect only after “Apply & Reboot” the Switch. For security concern, Enable “Security” -> “WEB Access Control” -> “State”...

  • Page 23: Statistics

    D-Link Web Smart Switch User Manual Statistics The “Statistics” -> “FDB Table” (Forwarding Database) table is to store the  MAC addresses that have been learned and which the ports that MAC address was learned on. “Statistics”  “Packet Counter” records 4 kinds of packet count. They are ...

  • Page 24: Advanced

    D-Link Web Smart Switch User Manual Advanced “Advanced” -> “Port” -> “Port Mirroring” copies packets entering (Rx)  or/and exiting (Tx) a port (source port) and sends the copies to a local interface (Destination Port) for monitoring purpose. “Advanced” -> “Port” -> “Broadcast Storm Control” ->“Threshold”...
  • Page 25 D-Link Web Smart Switch User Manual Advanced “Advanced” -> “Port” -> “Bandwidth Control”  To control the bandwidth of Switch port, here provides the method to set the bandwidth by selecting “Tx Rate” (Transmit), “Rx Rate” (Receive) and “Resolution”. Then, the multiplied result comes to “Tx Bandwidth” and “Rx Bandwidth”...
  • Page 26 D-Link Web Smart Switch User Manual Advanced “Advanced” -> “DHCP Relay” -> “DHCP Relay Agent” ->”DHCP Relay  Hops Count Limit” allows the maximum number of hops (routers) that the DHCP messages can be relayed through to be set. If a packet’s hop count is more than the hop count limit, the packet is dropped.
  • Page 27 D-Link Web Smart Switch User Manual Advanced “Advanced” -> “IGMP Snooping” is the process of listening to Internet Group  Management Protocol (IGMP) network traffic. This feature allows a network switch to listen in on the IGMP conversation between host and router. By...

  • Page 28: Product Specification

    D-Link Web Smart Switch User Manual Product Specification 1. External Interfaces  4 10/100-T ports + 2 10/100/1000-T ports FE ports support PoE, 5 GE port does not support PoE.)  Per port LED indicators.  System and POE LED indicators.

  • Page 29: Push Button

    D-Link Web Smart Switch User Manual PoE output power capacity Maximum output: 30Watt per port. 1. Support PoE and PoE+. (IEEE 802.3af /at standard.) 2. Automatically discover the connection of PD device. 3. Automatically disable port if the port current is over 720mA.

  • Page 30: Power Supply -External Adaptor

    D-Link Web Smart Switch User Manual 5. Power Supply –External Adaptor Items Specifications Total Electrical Power 120W AC Input Voltage 100V ~ 240V, 50/60Hz DC Output +54V: 2.22A (Max) 6. System Information Items Specifications Power Consumption 13.4W MTBF 7 years or more...
