Summary of Contents for D-Link EasySmart DES-1100-16

Page 1 Коммутаторы D-Link DES-1100-26/A1A: Инструкция пользователя...
Page 2 Ver. 1.10...
Page 3: Table Of Contents
D-Link Web Smart Switch User Manual Table of Contents Table of Contents ............................. i About This Guide............................. 1 Terms/Usage..............................1 Copyright and Trademarks ..........................1 Product Introduction ........................... 2 DES-1100-16 ..............................2 Front Panel ..............................2 Rear Panel..............................2 DES-1100-24 ..............................2 Front Panel ..............................
Page 4 D-Link Web Smart Switch User Manual Configuration Backup & Restore ......................20 Function Tree ............................... 21 Device Information............................ 22 System > System Settings ........................22 System > Port Settings..........................23 System > Trap Settings For SmartConsole....................24 System > Password Access Control ......................25 L2 Features >...
Page 5: About This Guide
Reproduction in any manner whatsoever without the written permission of D-Link Corporation is strictly forbidden. Trademarks used in this text: D-Link and the D-LINK logo are trademarks of D-Link Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation. Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.
Page 6: Product Introduction
D-Link Web Smart Switch User Manual Product Introduction Thank you and congratulations on your purchase of D-Link EasySmart Switch Products. D-Link's next generation EasySmart Ethernet switch series blends plug-and-play simplicity with exceptional value and reliability for small and medium-sized business (SMB) networking. All models are housed in a new style rack-mount metal case with easy-to-view front panel diagnostic LEDs.
Page 7: Rear Panel
D-Link Web Smart Switch User Manual Power LED: The Power LED lights up when the Switch is connected to a power source. Link/Act/Speed LED (Ports 1-24): Flashing: Indicates a network link through the corresponding port. Blinking: Indicates that the Switch is either sending or receiving data to the port.
Page 8: Rear Panel
D-Link Web Smart Switch User Manual Rear Panel Figure 6 – DES-1100-26 Rear Panel Power: Connect the supplied AC power cable to this port.
Page 9: Hardware Installation
D-Link Web Smart Switch User Manual Hardware Installation This chapter provides unpacking and installation information for the D-Link EasySmart Switch. Step 1: Unpacking Open the shipping carton and carefully unpack its contents. Please consult the packing list located in the User Manual to make sure all items are present and undamaged.
Page 10 D-Link Web Smart Switch User Manual Figure 8 – Attach the mounting brackets to the Switch Then, use the screws provided with the equipment rack to mount the switch in the rack. Figure 9 – Mount the Switch in the rack or chassis...
Page 11: Step 3 - Plugging In The Ac Power Cord
D-Link Web Smart Switch User Manual Step 3 – Plugging in the AC Power Cord Users may now connect the AC power cord into the rear of the switch and to an electrical outlet (preferably one that is grounded and surge protected).
Page 12: Getting Started
This chapter introduces the management interface of D-Link EasySmart Switch. Management Options The D-Link EasySmart Switch can be managed through any port on the device by using the Web-based Management or through any PC using the SmartConsole Utility. Each switch must be assigned its own IP Address, which is used for communication with Web-Based Management.
Page 13: Login Web-Based Management
Figure 14 – Logon Dialog Box SmartConsole Utility The SmartConsole Utility included in the installation CD is a program for discovering D-Link Smart Switches and EasySmart Switches within the same L2 network segment connected to your PC. This tool is only for computers running Windows 7, Vista, XP, and 2000 in both 32 and 64-bit operating systems.
Page 14 .exe file. Follow the on-screen instructions to install the utility. Upon c ompletion, go to Start > Programs > D-Link SmartConsole Utility and open the SmartConsole Utility. Connect the Smart Switch to the sam e L2 network segment of your PC and use the SmartConsole Utility to discover the Smart Switches.
Page 15: Smartconsole Utility
D-Link Web Smart Switch User Manual SmartConsole Utility The D-Link SmartConsole Utility allows the administrator to quickly discover all D-Link Smart Switches and EasySmart Switches which are in the same domain of the PC, collect traps and log messages, and quick access to basic configurations of the switch.
Page 16: Log
D-Link Web Smart Switch User Manual NOTE: If the Group Interval is set to 0, IGMP Snooping must be disabled in the Switch or the switches will not be discovered. Click this icon to launch the Log window. Click View Log to show the events of the SmartConsole Utility and the device.
Page 17: File
D-Link Web Smart Switch User Manual File By clicking on this icon you will see below options: Figure 19 – SmartConsole File Monitor Save: Records the setting of the Device List as default for the next time the SmartConsole Utility is used.
Page 18: Device Configuration
D-Link Web Smart Switch User Manual Device Configuration The Device Configuration in the SmartConsole Utility has five icons: Device Settings Device Password Manager Multi Firmware Upgrade DHCP Refresh Web Access and the device buttons for the Device List. Device Settings Select a switch from the Device List.
Page 19: Add(+), Delete(-) And Discover The Device
D-Link Web Smart Switch User Manual Device Password Manager Select a switch from the Device List. Click on this icon to launch the Device Password Manager window. Here you can enter a new password and confirm it. Figure 22 – SmartConsole Device Password Manager Multi Firmware Upgrade The EasySmart switches’...
Page 20: Device List
D-Link Web Smart Switch User Manual Figure 25 – SmartConsole Add device Figure 26 – SmartConsole Delete device Device List This list displays all discovered Web Smart and EasySmart switches on the network. Figure 27 – SmartConsole Device List Definitions of the Device List features: Monitor: Check the Monitor box and the SmartConsole will collect the trap and log data from the device.
Page 21 D-Link Web Smart Switch User Manual Gateway: Displays the Gateway setting of the device. Device Group Interval: Displays the intervals (in seconds). This feature is not available for EasySmart switches. Firmware version: Displays the current Firmware version of this device.
Page 22: Configuration
Logout button, it will be seen as an abnormal exit and the login session will still be occupied. Finally, by clicking on the D-Link logo at the upper-left corner of the screen you will be redirected to the local D-Link website.
Page 23: Tool Bar > Save Menu
D-Link Web Smart Switch User Manual Tool Bar > Save Menu The Save Menu provides Save Configuration. Figure 29 – Save Menu Save Configuration Select to save the entire configuration changes you have made to the device to switch’s non-volatile RAM.
Page 24: Configuration Backup & Restore
D-Link Web Smart Switch User Manual Figure 34 – Tool Menu > Firmware upgrade Click Browse to browse your inventories for a saved firmware file. And then click Upgrade to restore the selected firmware file. CAUTION: Do not disconnect the PC or remove the power cord from device until upgrade is complete.
Page 25: Function Tree
D-Link Web Smart Switch User Manual Function Tree All configuration options on the switch are accessed through the Setup menu on the left side of the screen. Click on the setup item that you want to configure. The following sections provide more detailed description of each feature and function.
Page 26: Device Information
D-Link Web Smart Switch User Manual NOTE: DES-1100-26 supports one more function: VLAN-> Traffic Segmentation. Device Information The Device Information provides an overview of the switch which includes essential information such as firmware, hardware and IP address. It also offers an overall status of common software features: Port Mirroring: Click Setting >...
Page 27: System > Port Settings
D-Link Web Smart Switch User Manual Figure 39 – System > System Setting System > Port Settings In the Port Setting page, the status of all ports can be monitored and adjusted for optimum configuration. By selecting a range of ports (From Port and To Port), the Speed can be set for all selected ports, effective by clicking Apply.
Page 28: System > Trap Settings For Smartconsole
D-Link Web Smart Switch User Manual Flow Control: You can enable this function to mitigate the traffic congestion. Ports configured for full-duplex use 802.3x flow control, half-duplex ports use backpressure flow control. The default setting is disabled. DES-1100-26 Figure 41 – System > Port Setting Speed: Copper connections of Port1, Port2, …...
Page 29: System > Password Access Control
D-Link Web Smart Switch User Manual Figure 42 – System > Trap Setting Select the event message(s) to be sent out to the managing station. System Event: The system level messages contain: Device Bootup - System boot-up information Illegal Login - Events of incorrect password logins and records the IP of the source PC...
Page 30: L2 Features > Igmp Snooping
D-Link Web Smart Switch User Manual DES-1100-16/24 Figure 45- L2 Features > Port Trunking Settings DES-1100-26 Figure 46- L2 Features > Port Trunking Settings NOTE: On DES-1100-26, Port 1-4 can be aggregated for Trunk Group 1, Port 5-8 are for Group 2, and the uplink port 25-26 are for Group 3.
Page 31: L2 Features > Port Mirroring
D-Link Web Smart Switch User Manual By default, IGMP is disabled. If enabled, the EasySmart switch can recognize IGMP queries and reports sent between network stations or devices and an IGMP host. With IGMP snooping enabled, the EasySmart switch will forward multicast traffic only to the connections that have members attached.
Page 32: L2 Features > Loopback Detection
D-Link Web Smart Switch User Manual L2 Features > Loopback Detection The Loopback Detection function is used to detect the loop created by a specific port while Spanning Tree Protocol (STP) is not enabled in the network, especially when the down links are hubs or unmanaged switches.
Page 33 D-Link Web Smart Switch User Manual Figure 50 – L2 Features > Statistics menu Receive Packet & Transmit Packet: Number of packets received and transmitted successfully. Figure 51 – L2 Features > Statistics menu Transmit Packet & Collision: Number of transmit packets resulting in collision.
Page 34 D-Link Web Smart Switch User Manual Figure 52 – L2 Features > Statistics menu Receive Packet & Drop Packet: Number of receive packets resulting in drop packets. Figure 53 – L2 Features > Statistics menu Receive Packet & CRC Packet: Number of receive packets resulting in CRC error.
Page 35: Vlan > 802.1Q Vlan
D-Link Web Smart Switch User Manual Figure 54 – L2 Features > Statistics menu Refresh All: Refreshes the details collected and displayed. Clear All Counters: Resets the details displayed. VLAN > 802.1Q VLAN A VLAN is a group of ports that can be anywhere in the network, but communicate as though they were in the same area.
Page 36 D-Link Web Smart Switch User Manual Figure 55 – VLAN > 802.1Q VLAN > Default Setting Figure 56 – VLAN > 802.1Q VLAN > Add VID Figure 57 – VLAN > 802.1Q VLAN > Assign PVID Rename: Click to rename the VLAN group.
Page 37: Vlan > 802.1Q Management Vlan
D-Link Web Smart Switch User Manual Figure 58 – VLAN > 802.1Q VLAN > VLAN Table NOTE: When 802.1Q VLAN is enabled, the Port- Based VLAN settings will be reset to default. NOTE: When 802.1Q VLAN is disabled, its settings will be cleaned, and Management VLAN will be disabled simultaneously.
Page 38: Vlan > Port-Base Vlan
D-Link Web Smart Switch User Manual VLAN > Port-Base VLAN Port-Based VLANs are the simplest and most common form of VLAN. It assigns the appliance LAN ports to VLANs, effectively transforming the appliances. You can assign multiple ports to the same VLAN, or each port to a separate VLAN.
Page 39: Qos > 802.1P Default Priority (Qos Setting)
D-Link Web Smart Switch User Manual QoS > 802.1p Default Priority (QoS Setting) QoS is an implementation of the IEEE 802.1p standard that allows network administrators to reserve bandwidth for important functions that require a larger bandwidth or that might have a higher priority, such as VoIP (voice-over Internet Protocol), web browsing applications, file server applications or video conferencing.
Page 40: Qos > Storm Control
Based or 802.1p-Based. If port-based mode is selected, the packets will be prioritized as High or Low based on port settings. If 802.1p-Based is selected, D-Link Easy Smart Switches will refer to their 802.1p information for prioritization. QoS > Storm Control The Storm Control feature provides the ability to control the receive rate of broadcast, multicast, and unknown unicast packets.
Page 41: Qos > Bandwidth Control
D-Link Web Smart Switch User Manual Figure 65 – QoS > Storm Control Storm Control Type: User can select the different Storm type from Broadcast Only, Multicast & Broadcast, and Multicast & Broadcast & Unknown Unicast. Threshold (pps): If storm control is enabled (by default it is disabled), the threshold can be set from 0.8 to 12.6Kbits per second at 10Mbps speed, and 8 ~ 126Kbits per second at 100Mbps speed.
Page 42: Security > Mac Address Table > Static Mac
D-Link Web Smart Switch User Manual Figure 67 – QoS > Bandwidth Control From Port / To Port: A consecutive group of ports may be configured starting with the selected port. Type: This drop-down menu allows you to select between RX (receive), TX (transmit), and Both. This setting will determine whether the bandwidth ceiling is applied to receiving, transmitting, or both receiving and transmitting packets.
Page 43: Security > Mac Address Table > Dynamic Forwarding Table
D-Link Web Smart Switch User Manual Figure 68 – Security > Static Mac Address To initiate the removal of auto-learning for any of the uplink ports, click On to enable this feature, and then select the port(s) for auto learning to be disabled.
Page 44 D-Link Web Smart Switch User Manual Figure 69 – Security > Dynamic Forwarding Table...
Page 45: Appendix A - Ethernet Technology
D-Link Web Smart Switch User Manual Appendix A - Ethernet Technology This chapter will describe the features of the D-Link EasySmart Switch and provide some background information about Ethernet/Fast Ethernet/Gigabit Ethernet switching technology. Gigabit Ethernet Technology Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the same packet structure, format, and support for CSMA/CD protocol, full duplex, and management objects, but with a tenfold increase in theoretical throughput of over 100-Mbps Fast Ethernet and a hundredfold increase over 10-Mbps Ethernet.
Page 46: Appendix B - Technical Specifications
D-Link Web Smart Switch User Manual Appendix B - Technical Specifications Physical & Environment Hardware Specifications input, 100~240 VAC, 50/60Hz, Key Components / Performance internal universal power supply Switching Capacity: Acoustic Value: - DES-1100-16: 3.2Gbps - DES-1100-16/24/26: 0dB (Fan-less) - DES-1100-24: 4.8Gbps Operation Temperature 0~40°...
Page 47: Appendix C - Rack Mount Instructions
D-Link Web Smart Switch User Manual Appendix C – Rack mount Instructions Safety Instructions - Rack Mount Instructions - The following or similar rack-mount instructions are included with the installation instructions: A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.
