3. SAFETY REQUIREMENTS

◆ Be sure to read this User Manual before using the device. The device should not be used by
persons who are not familiar with this manual.
◆ This device is not intended for use by people (including children) of reduced physical, sensory or
mental abilities, or lack of experience and knowledge, unless they are supervised or instructed by
a person responsible for their safety.
◆ Minors must be supervised to ensure that they do not play with the Device.
◆ Before you start working with the Device, prepare your workplace. There should be no foreign
objects in the working area of the device. The working area must be illuminated.
◆ To prevent cuts, do not touch the cutting edge of the blade with your hands. It is recommended
that you wear cut-resistant gloves when handling the machine.
◆ Do not leave unattended the device prepared for operation, as well as an uncased knife blade in
the access area of children and animals.

4. CONSTRUCTION

6
5
4
3
2
20
19
9
8
7
15
1
16
17
18
11
12
13
14
(fig. 1)
10
1. Stand
2. Damping-spacer
3. Ball-handle
4. Movable abrasive stop
5. Abrasive holder
6. Clamp, 2 pcs.
7. Stationary abrasive stop
8. Bushing-coupling
9. Hinge unit
10. Stroke limiter
11. Fixating handle
12. Adjusting knob
13. Movable body
14. Frame
15. Folding mechanism button
16. Removable parking
17. Lever
18. Arched rack
19. Rigid fixation screw
20. Thumbscrew М3х5х12
