Chapter 2 — Spare Parts

Panel Module, Left (PD42)

Callout Part Number
1 1-207132-001
2 141-000112-902
3 1-971163-900
4 151-000026-902
5 1-207133-001
6 1-207134-001
7 1-207144-001
8 160-000186-000
8
8
7
2
6
Description
Panel module, left (PD42)
Cable
Console board
Label-taken sensor kit
Front panel with overlay assembly
Overlay, front panel
Button Display
LCD PCB assembly with cable
Screw
(4 places)
4
5
1
Remarks
Complete unit.
Display console board to main board.
Including cable.
Comes with one button only (requires 5).
EasyCoder PD41 and PD42 Printer Spare Parts Catalog
Screw
(4 places)
3
