- Page 1 AOIP2M 2 Channel Dante Microphone Preamplifier PRODUCT DETAILS 6 BROOKS PLACE, MAIDSTONE, KENT, ME141HE. ENGLAND. TEL: +44 (0) 1622 753662 Visit our website at www.glensound.com FAX: +44 (0) 1622 762330...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with your product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This symbol is intended to highlight that This symbol is intended to warn that there are important operating & dangerous voltages within the product are maintenance instructions in the literature present and constitute a risk of electric accompanying this unit. -
Page 4: Product Warranty
PRODUCT WARRANTY All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or workmanship and... - Page 5 2 Channel Dante Microphone Preamplifier This declaration of conformity is issued under the sole responsibility of the manufacturer. This equipment is manufactured by Glensound Electronics Ltd of Brooks Place Maidstone Kent ME14 1HE is marked and conforms to the following Union harmonisation legislation:...
-
Page 6: Rohs Directive
RoHS DIRECTIVE RoHS 2 Directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment. This product conforms to the above directive and for these purposes, the maximum concentration values of the restricted substances by weight in homogenous materials are: Lead 0.1%... -
Page 7: Waste Electrical And Electronic Equipment Regulations 2006 (Weee)
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR Page 7 of 21... -
Page 8: Table Of Contents
GLENSOUND AOIP2M Handbook Contents Description Issue 1.0 02/09/22 Page No. Contents IMPORTANT SAFETY INSTRUCTIONS ................3 PRODUCT WARRANTY ...................... 4 ............................ 5 RoHS DIRECTIVE......................... 6 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) ..7 Handbook Contents ......................8 Overview ..........................9 AOIP2M Front Panel Layout ................... -
Page 9: Overview
Overview The Glensound AOIP2M is an analogue to digital converter with high quality Microphone Preamplifiers designed to connect microphones to a Dante® audio network. Dante® network audio is a common protocol for distributing high quality linear audio over standard IP networks and it is widely used by many audio equipment manufacturers. -
Page 10: Aoip2M Front Panel Layout
AOIP2M Front Panel Layout Input Gain control Mic activity Power LED Phantom power indicator Phantom power switch Power LED Power LED for power indication. Input Gain control Potentiometer for controlling microphone input gain. Mic activity Post-pot mic activity LEDs for monitoring Microphone level. Phantom power switch Press and hold for a few seconds to toggle +48V phantom power on for the selected Mic channel. -
Page 11: Aoip2M Rear Panel Layout
AOIP2M Rear Panel Layout Network RJ45 etherCON Network link LED Microphone USB connector DC Power inputs Input jack Microphone inputs Two high quality microphone preamplifiers. See the end of the manual for wiring information. DC Power Input jack A standard DC IN barrel jack connector for 12V 1A DC input. The center pin is 2.5mm. It is wired center pin + Volts. -
Page 12: Audio Block Diagram
Audio Block Diagram Page 12 of 21... -
Page 13: Connecting The Aoip2M To A Dante Network
Connecting The AOIP2M To A Dante Network The AOIP2M is a network audio device utilizing the reliable and versatile Dante audio over IP protocol. Dante is a proprietary system (although very widely used) the originators of which are Audinate. The information below is only meant as a very basic guide. Full details of the power of Dante network audio and instructions for using it can be found at www.audinate.com Getting Dante Controller... -
Page 14: Running Dante Controller
The format used for the factory name is: ‘AOIP2M-SN-XXXX’ Where ‘AOIP2M’ refers to the Glensound product i.e. AOIP2M The ‘SN-XXXX’ refers to the serial number of the AOIP2M which can be found printed on the rear or side of the unit. -
Page 15: Device Not Showing Up In Dante Controller
Device not showing up in Dante Controller If your Dante device does not show up in Dante Controller then the most likely issue is that the device’s IP Address is not appropriate for your network. A) It maybe that the device is set to obtain an IP address automatically using DHCP (this is the default configuration) and your network is setup for fixed IP addresses only and does not have a DHCP server. -
Page 16: Aes67 Mode
AES67 and therefore the AOIP2M can be set to AES67 mode for interaction with other AES67 devices. Please note however that Glensound are relying on Audinate’s AES67 interface and are unfortunately not able to provide full AES67 support for the unit. AES67 support should be sought directly from Audinate. -
Page 17: Receiving Aes67 Audio
Tick the AES67 Flow check box, then select channels to be included in the flow then click ‘Create’ Once set the flows can be seen in the transmit tab of the device view. Receiving AES67 Audio Once a compatible AES67 stream is detected on the network by Dante Controller the AES67 flows will appear in the Dante Transmitters section in the Routing tab. -
Page 18: Aes67 Restrictions
AES67 Restrictions AES67 flows can only be generated with the following constraints: • Multicast Only • Non-redundant • Destination address in range 239.nnn.0.0 to 239.nnn.255.255 (239.nnn/16), port 5004 • 48kHz sampling rate • 24 bit linear (L24) encoding • 1 msec packet time •... -
Page 19: Updating The Dante Firmware
Updating The Dante firmware The AOIP2M has Dante specific firmware that runs inside the Dante chipset, known as Ultimo. The Ultimo Chipset is a device supplied by Audinate that does most of the processing for the actual Dante/ AES67 network audio streams. There is one Ultimo Chipset in each AOIP2M. - Page 20 Caution! Audio will be interrupted during the device update B. Press update device A. Tick box to confirm Update is in progress A. Update finished. B. Press Tick box to continue reboot device Update finished, device will now reboot Page 20 of 21...
-
Page 21: Wiring Information
Wiring Information STANDARD XLR AUDIO PINOUTS: 1: Ground/ Earth 2: INPHASE/ POSITIVE/ MIC + 3: MATE/ NEGATIVE/ MIC - XLR SOCKET (FEMALE) Page 21 of 21...
