- Page 1 GS-HA013 BATTERY POWERED PORTABLE HEADPHONE AMPLIFIER PRODUCT DETAILS 6 BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. ENGLAND. TEL: +44 (0) 1622 753662 Visit our Website at www.glensound.co.uk FAX: +44 (0) 1622 762330...
- Page 2 Glensound Electronics Ltd Thank you for choosing a new Glensound product. All rights reserved. Information contained in this manual is subject to change without notice, if in doubt please contact us for the latest product information. If you need any help with the product then we can be contacted at: Glensound Electronics Ltd 1 –...
-
Page 3: Product Warranty
PRODUCT WARRANTY: All equipment is fully tested before dispatch and carefully designed to provide you with trouble free use for many years. We have a policy of supporting products for as long as possible and guarantee to be able to support your product for a minimum of 10 years. For a period of one year after the goods have been despatched the Company will guarantee the goods against any defect developing after proper use providing such defects arise solely from faulty materials or... - Page 4 Emissions: EN55103.1 Immunity: EN55103.2 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR RoHS DIRECTIVE EC directive 2002/95/EC restricts the use of the hazardous substances listed below in electrical and electronic equipment.
-
Page 5: Table Of Contents
GLENSOUND GS-HA013 Handbook Contents Issue 1 Description Page No. Contents PRODUCT WARRANTY: ............................ 3 OVERVIEW ................................6 SIMPLIFIED BLOCK DIAGRAM ........................7 FRONT PANEL CONTROLS ..........................8 1) Power On Switch ............................8 2) Power On LED ............................. 8 3) A Volume Control ............................9 4) A Routing Switch ............................ -
Page 6: Overview
OVERVIEW The Glensound GS-HA013 portable headphone amplifier has been designed to withstand the rigours of regular outside broadcast use by sound engineers and production personel. It’s features expand on the very popular original GS-HA001 which it superceeds. The headphone amplifier is powered from a single 9V PP3 battery and can also be powered by an external power supply (not inlcuded but available as an extra). -
Page 7: Simplified Block Diagram
SIMPLIFIED BLOCK DIAGRAM Page 7 of 15... -
Page 8: Front Panel Controls
The power on switch turns the headphone amplifier on/off. In the down position it I son and in the up position the GS-HA013 is off. To turn on the GS-HA013 must either have a battery fitted or an external power supply connected. -
Page 9: A Volume Control
If you would like the volume control to be able to completely attenuate then this can accommodated by Glensound prior to shipping. 4) A Routing Switch This switch selects which (or both) sources the A headphone output is derived from. -
Page 10: Right Side Panel Controls
RIGHT SIDE PANEL CONTROLS 8) A Course 9) B Course 10) Phase 11) Input Gain Gain Revers switch Select switch 8/9) A & B Course Gain Controls This pre-set potentiometer adjusts the input gain of the incoming signal, to get it to the correct use for the headphone amplifier. -
Page 11: Rear Panel Controls
REAR PANEL CONTROLS 12) 3.5mm 13) 6.35mm 14) A\STEREO 15) B XLR Headphone Headphone XLR Input Input Jack Jack 16) DC Input 12) 3.5mm Headphone Jack This is a standard 3.5mm TRS jack socket. It is wired in parallel with the rear panel 6.35mm &... -
Page 12: B Input
Or it accepts an unbalanced stereo source and routes this to both the A and B sides of the headphone amplifier. 15) B Input This audio input is a normal balanced circuit. It is either routed internally to the ‘B’ side of the headphone amplifier or if the input select switch on the side of the unit is set to ‘UNBALANCED STEREO’... -
Page 13: Left Side Panel Controls
LEFT SIDE PANEL CONTROLS 18) Battery 17) Battery Compartment Compartment Catch 17) Battery Compartment This is the compartment that houses the PP3 9 Volt battery. 18) Battery Compartment Catch Use this little indent to lift the battery compartment to enable it to slide outwards when changing the battery. -
Page 14: Wiring Information
WIRING INFORMATION 1. Standard wiring info STANDARD XLR AUDIO PINOUTS: 1: Ground/ Earth 2: INPHASE/ POSITIVE/ MIC + 3: MATE/ NEGATIVE/ MIC - XLR SOCKET (FEMALE) STANDARD HEADPHONE WIRING: RING TIP: A/ LEFT Ear RING: B/ RIGHT Ear SLEEVE: Common/ Earth SLEEVE 2. -
Page 15: Specification
SPECIFICATION AUDIO INPUT: BALANCED INPUT IMPEDANCE >50K Ohms UNBALANCED STEREO INPUT IMPEDANCE >22K Ohms (On each side) INPUT GAIN RANGE -20dBu to +8dBu FREQUENCY RESPONSE -1dBu @ 20Hz & 20kHz NOISE -54dBu (RMS 22-22kHz) @ Max Gain -85dBu (RMS 22-22kHz) @ Min Gain HEADPHONE OUTPUT: HEADPHONE IMPEDANCE 200 Ohms to 2K Ohms HEADPHONE LEVEL RANGE -20dBu to +10dBu...
